19 2020/2021 8 mm IEC EN 1307.B1.Q970.* 1307.B1.0650.0650.VC 1307.B1.0650.* ! ECOST A T ® ANTI-F A TIGUE MA TS Grounding box see page 76 ECOST A T ® ANTI-F A TIGUE MA TS „EASY WALKING“ Part Nr . Standard Sizes Colour 130…
18
2020/2021
14 mm
IEC
EN
!
Custom sizes available on request
ECOSTAT
®
ANTI-FATIGUE MATS
„EASY STANDING“
Anti-fatigue mats with optional yellow
bevelled edges or with interlocking system
Part Nr. Standard Sizes Colour
1306.B1.0650.0950 650 x 950 x 13 mm incl. 2 x 10 mm snap Black
1306.B1.Z Custom size on request Black
Static dissipative Anti-Fatigue material, for use in EPA´s with hard floors, improves worker comfort and productivity.
• Static dissipative PUR material
• Ergonomic
• Soft and Elastic
• Dome cell structure
• Improved standing comfort
• Heat and sound absorbent
• Improved Anti-Fatigue properties
• Possible extension by glueing
• Blister diameter: 14 mm
• Class B1
• Anti-skid and shock absorbent
• Bevel sides
• 10 mm snap connection
• Standard mats sizes
Custom sizes available on request
ECOSTAT
®
ANTI-FATIGUE MATS
19
2020/2021
8 mm
IEC
EN
1307.B1.Q970.*
1307.B1.0650.0650.VC
1307.B1.0650.*
!
ECOSTAT
®
ANTI-FATIGUE MATS
Grounding box
see page 76
ECOSTAT
®
ANTI-FATIGUE MATS
„EASY WALKING“
Part Nr. Standard Sizes Colour
1307.B1.0650.0940.VE End tile: 650 x 940 x 13 mm incl. 10 mm snap Black
1307.B1.0650.0910.VM Middle tile: 650 x 910 x 13 mm Black
1307.B1.0650.0650.VC Corner tile: 650 x 650 x 13 mm incl. 10 mm snap Black
1307.B1.Q970.Q635.VE End tile: 970 x 635 x 13 mm incl. 10 mm snap Black
1307.B1.Q970.Q610.VM Middle tile: 970 x 610 x 13 mm Black
1307.B1.Z Custom size on request Black
2821.AL.50 self-adhesive aluminium tape, 50 m/roll
Static dissipative Anti-Fatigue material, for use in EPA´s with hard floors, improves worker comfort and productivity.
• Static dissipative PUR material
• Ergonomic
• Soft and Elastic
• Dome cell structure
• Improved standing comfort
• Heat and sound absorbent
• Improved Anti-Fatigue properties
• Interlocking mats for large area, easy extension
• Custom size available on request
• Smallest configuration: 2 end tiles
• Blister diameter: 8 mm
• Class B1
• Anti-skid and shock absorbent
• Bevel sides
• 10 mm snap connection
• Standard mats sizes
Custom sizes available on request
application example
2821.AL.50
Alternative grounding
possible with a self-
adhesive aluminium tape
20
2020/2021
IEC
EN
max. 10 m
max 1.22 m
ECOSTAT
®
TABLE MATS
ECOSTAT
®
TABLE MATS
Part Nr. Colour Standard Sizes
1402.662.L* Beige 610 x 1220 mm
1402.662.S* Beige 610 x 900 mm
1402.662.R rolls: 1220 mm x 10 m
1402.662.R10 rolls: 1000 mm x 10 m
1402.662.R61 rolls: 610 mm x 10 m
1402.662.Z Custom sizes available on request
*rounded edges (radius approx. 43 mm)
Part Nr. Colour Standard Sizes
1402.663.L* Platinum grey 610 x 1220 mm
1402.663.S* Platinum grey 610 x 900 mm
1402.663.R rolls: 1220 mm x 10 m
1402.663.R10 rolls: 1000 mm x 10 m
1402.663.R61 rolls: 610 mm x 10 m
1402.663.Z Custom sizes available on request
*rounded edges (radius approx. 43 mm)
Part Nr. Colour Standard Sizes
1402.664.L* Green 610 x 1220 mm
1402.664.S* Green 610 x 900 mm
1402.664.R rolls: 1220 mm x 10 m
1402.664.R61 rolls: 610 mm x 10 m
1402.664.Z Custom sizes available on request
*rounded edges (radius approx. 43 mm)
Part Nr. Colour Standard Sizes
1402.665.L* Light blue 610 x 1220 mm
1402.665.S* Light blue 610 x 900 mm
1402.665.R rolls: 1220 mm x 10 m
1402.665.R10 rolls: 1000 mm x 10 m
1402.665.R61 rolls: 610 mm x 10 m
1402.665.Z Custom sizes available on
request
*rounded edges (radius approx. 43 mm)
• Two layer material
• Rugged synthetic rubber
• Resistant to solder and heat
• Abrasion resistant
• Elastic
• Volume conductive
• Thickness: 2 mm
• Includes 2 x 10 mm snap fastener and rounded edges*
Profi le
conductive
backing
