87 2020/2021 7110.600.SET .WT 7110.B530.SET .WT IEC EN TEST AND MEASUREMENT Part Nr . includes: 7110.B530. SET .WT (20 kg) 7110.600. SET .WT (20 kg) 7110.600 Aluminium case X X 7100.B530.G* High Resistance Meter Metriso …
86
2020/2021
7100.PGT120.TEST.10
7100.PGT120.TEST.12
7100.PGT120.TEST.13
7100.PGT120.TEST.16
7100.PGT.XK.V3
7100.PGT.XK.ID.V3
TEST AND MEASUREMENT
sample application
LABEL PRINTER
• Label printing for passed tests with test results and measurement
values from the data terminals DT2/DT3/TC18
(languages: German/English)
• If using a card reader for user identification, the name is shown
on the label.
Includes:
Label printer with power supplies,
2 label rolls with 310 pcs/roll (36 x 67 mm),
operating instructions (german/englisch)
Part Nr.
7100.PGT120.COM.D.2 Label printer
7100.PGT120.COM.D.3 Label rolls 36 x 67 mm, unit: 2 rolls
Part Nr. Qty.
7100.PGT120.TEST.10 Temperature / humidity sensor
7100.PGT120.TEST.12 USB-Relais-Modul, e. g. for switching a turnstile gate
7100.PGT120.TEST.13 Signal light (red/yellow/green) with acoustic sound
7100.PGT120.TEST.16 4-Port-USB-Hub
7100.PGT.XK.V3 HID-compatible USB card reader 1 pcs
7100.PGT.XK.ID.V3 ID card (LEGIC-Format) 10 pcs
ACCESSORIES FOR DATA TERMINAL
87
2020/2021
7110.600.SET.WT
7110.B530.SET.WT
IEC
EN
TEST AND MEASUREMENT
Part Nr. includes:
7110.B530.
SET.WT
(20 kg)
7110.600.
SET.WT
(20 kg)
7110.600 Aluminium case X X
7100.B530.G* High Resistance Meter Metriso
®
530B with connecting cables X
7100.3000.G* High Resistance Meter Metriso
®
3000 with connecting cables X
7100.3000.TF Temperature and humidity sensor Metriso
®
3000 X
7100.TF530* Thermo-Hygrometer TF-530 X
7220.45 Handheld probe model 45 X X
7220.840* Two-Point-Probe model 840 (Mini Probe) X X
7220.880* Ring probe model 880 X X
7100.SRM110* Surface Resistance Meter SRM 110 X X
7100.EFM51.CPS*
Electrostatic Field Meter with charged plate set X X
7100.EFM51.MK51
Measuring head MK51 for EFM51
®
X X
7100.WT5000.ML Connecting cable (Handheld probe/MK51) X X
7220.850 Probe model 850 (2 probes) X
7220.870 Probe model 870 (2 probes) X
7220.870.V.SET Extension rod for Probe model 870 (3 pcs.) X
2200.110 Grounding plug X X
7110.E8 8-socket grounding box X X
7100.2000.TR50 Cable reel, 50 m X X
7100.PGT100.102
Metal plate 400 x 300 x 2 mm incl. 10 mm snap with 4 mm banana plug adapter (2287.10.10)
X X
7220.880.6 Insulative plate 120 x 120 x 6 mm (2 pcs.) X X
7220.880.9 Probe made of stainless steel, Ø 120 mm X X
7220.880.L Guard cord, blue, 1,5 m X
* Measuring equipment including calibration certificate
ESD-AUDIT-KIT
The ESD-Audit-Kit includes the relevant test instruments for the verification of the ESD control elements according to IEC 61340-5-1 in an ESD
protected area (EPA)
Applications
• Evaluate packaging material
• Evaluate garments
• Measure flooring, working surface and furniture resistance
• Measure electrostatic fields
• Measure temperature and relative humidity
• Analyze Ionizers performance
• incl walking test function with EFM51 and
MK51 measuring head
Features
• Aluminium embossed conductive surface
• Dissipative foam inserts
• Removable, telescopic handle with castors
• ESD symbol
• Dimensions: 575 x 490 x 250 mm
• Tare: 7 kg
88
2020/2021
IEC
EN
IEC
EN
sample applications
Pocket size surface resistance meter with LCD display.
Includes conductive carrying case, grounding cord, USB-Cable,
calibration certificate and software for reading the saved test data.
• Integrated temperature- and humidity-sensor
• Test range: 10
3
- 10
12
ohm
• Test voltage: open circuit voltage 100 V
• Operation: Battery operated
• Display: LCD-Display
• Probes: Built-in electrodes with conductive rubber
• with memory and USB connection to PC
• 2 external probes connection possible
Part Nr.
7100.SRM200.K Surface Resistance Meter SRM
®
200
7100.SRM110.L connecting cables, 2 x 1 m
SRM
®
200
SRM
®
200 – VERIFICATION KIT
Built-in bar electrodes
with conductive rubber
TEST AND MEASUREMENT
Verification Kit for measuring conductive and dissipative surfaces.
Includes:
• 1 SRM
®
200 with various cables (Part Nr. 7100.SRM200.K)
• 2 Flat Probes Model 820
• 1 Mini Probe Modell 410
• 1 Hand-held probe Modell 45
• 2 connecting cables
• Calibration certificate
• Conductive carrying case
Part Nr.
7100.SRM200.VK SRM
®
200 – verifi cation kit
Video
