91 2020/2021 IEC EN TEST AND MEASUREMENT • The veribox contains resistors for the verfication of high r esistan- ce tester before use • 3 differ ent resistors with 3 separate test sockets Part Nr . 7100.VB2 V eribox Star…
90
2020/2021
IEC
EN
IEC
EN
7220.844.C
TEST AND MEASUREMENT
Pocket size, lightweight, surface resistance meter, includes carrying
bag, grounding cord and calibration certificate.
• Test range: 10
3
– 10
12
ohm
• Test voltage: open circuit voltage 100 V
• Operation: Battery operated
• Display: 12 LED display
• Probes: Built-in metal electrodes
(2 external probes connection possible)
Part Nr.
7100.SRM110.A Surface resistance meter SRM
®
110
SRM
®
110
Built-in bar electrodes
application examples
• two point probe adapter
• suitable for SRM
®
110 and SRM
®
200
Part Nr.
7220.410 SRM mini probe model 410
7220.844.C Calibration Unit for SRM mini probe model 410,
incl. calibration certifi cate, see page 93
SRM MINI PROBE MODEL 410
FOR SRM 110 AND SRM 200
Video
91
2020/2021
IEC
EN
TEST AND MEASUREMENT
• The veribox contains resistors for the verfication of high resistan-
ce tester before use
• 3 different resistors with 3 separate test sockets
Part Nr.
7100.VB2 Veribox
Starterkit for testing conductive an dissipative surfaces and
electrostatic fields/surface potentials
Includes:
• SRM
®
200
• EFM
®
51
• conductive carrying case
Part Nr.
7100.SRM200.SK51 SRM
®
200/EFM
®
51 Startertkit
VERIBOX
SRM
®
200/EFM
®
51 STARTERKIT
Metriso
®
B530
92
2020/2021
IEC
EN
IEC
EN
!
• For resistance to ground and point to point resistance
measurement
• Fitted with conductive silicone rubber electrode (R < 20 ohm)
• 63,5 mm Ø
• 2,27 kg weight
• Insulated handle
complies with
IEC 61340-4-1
IEC 61340-2-3
Part Nr.
7220.850 Probe model 850
7220.850.1 Insulated handle as spare part
PROBE MODEL 870
PROBE MODEL 850
ESD test point
label see page
140
• For resistance to ground and point to point resistance measurement
• Fitted with conductive silicone rubber with silver particles (R < 5 ohm)
• Ø 63,5 mm
• 2,27 kg weight
• Insulated handle
• 4 mm banana plug socket underneath the handle
complies with IEC 61340-4-1, IEC 61340-2-3
Part Nr.
7220.870 Probe model 870
7220.870.V.SET extension rod (3 pcs) with insulated handle
7220.870.G Insulated handle (replacement)
CONDUCTIVE CARRYING CASE FOR PROBES – UNEQUIPPED
• Suitable for the following probe models:
– Probe model 850
– Probe model 870
– Hand Held Probe model 45
– Empty compartment for cable etc.
Part Nr.
7220.K10 Conductive carrying case for probes – unequipped
TEST AND MEASUREMENT
