131 2020/2021 IEC EN DR Y -SHIELD TYPE A SHIELDING BAGS Part Nr . Bag sizes inner dim. Bags per unit 3715.DR.0426.A 102 x 660 mm 100 pcs 3715.DR.0626.A 152 x 660 mm 100 pcs 3715.DR.0810.A 203 x 254 mm 100 pcs 3715.DR.101…

130

2020/2021

IEC

DRY-SHIELD ESD/EMI SHIELDING BAGS

Part Nr. Bag sizes inner dim. Bags per box

3710.DR.0426 102 x 660 mm 100 pcs

3710.DR.0626 152 x 660 mm 100 pcs

3710.DR.0810 203 x 254 mm 100 pcs

3710.DR.1012 254 x 305 mm 100 pcs

3710.DR.1020 254 x 508 mm 100 pcs

3710.DR.1026 254 x 660 mm 100 pcs

3710.DR.1626 406 x 660 mm 100 pcs

3710.DR.1818 457 x 457 mm 100 pcs

• Shielding bag with moisture barrier

• Protection against electrostatic discharge

and electrostatic fields

• Complies with MIL-B81705 Type 1 Class 1

• EMI - Shielding > 40 db

• The moisture barrier property is achieved through the multilayer

construction which includes disspipative

Polyester, Aluminium metallization and dissipative

Polyethylene

• Heat sealable

• Can be used for vacuum packaging applications

• Standard print: Product name, ESD symbol,

barrier bag symbol, Recycling symbol and production date

Custom sizes available on request.

application example

SHIELDING PACKAGING MATERIAL

131

2020/2021

IEC

DRY-SHIELD TYPE A SHIELDING BAGS

Part Nr. Bag sizes inner dim. Bags per unit

3715.DR.0426.A 102 x 660 mm 100 pcs

3715.DR.0626.A 152 x 660 mm 100 pcs

3715.DR.0810.A 203 x 254 mm 100 pcs

3715.DR.1012.A 254 x 305 mm 100 pcs

3715.DR.1020.A 254 x 508 mm 100 pcs

3715.DR.1026.A 254 x 660 mm 100 pcs

3715.DR.1626.A 406 x 660 mm 100 pcs

3715.DR.1818.A 457 x 457 mm 100 pcs

• Shielding bag with moisture barrier

• Protection against electrostatic discharge

and electrostatic fields

• Complies with MIL-B81705 Type 1 Class 1

• EMI - Shielding > 40 dB

• The moisture barrier property is achieved through the multilayer

construction which includes disspipative

Polyester, Aluminium metallization and dissipative

Polyethylene

• Heat sealable

• Can be used for vacuum packaging applications

• Standard print: Product name, ESD symbol,

barrier bag symbol, Recycling symbol and production date

imprinted in wellding rod

• Each unit is sealed in a Highshield

bag

SHIELDING PACKAGING MATERIAL

application example

132

2020/2021

! !

IEC

DESICCANT BAGS – SODA PAPERDESICCANT BAGS – FLEECE BAG

• for highly sensitive products, reduced tear resistance

• Bags will be delivered in the indicated quantity only

• dustproof

Part Nr. Size Quantity

3775.PA.017000 1/6-unit 1.350 pcs

3775.PA.033000 1/3-unit 800 pcs

3775.PA.050000 1/2-unit 720 pcs

3775.PA.101000 1-unit 400 pcs

3775.PA.102000 2-unit 240 pcs

• For very sensitive products

• high tensile strength / dustproof

• Bags will be delivered in the indicated quantity only

Part Nr. Size Quantity

3775.VA.017000 1/6-unit (app. 6 g) 1.350 pcs

3775.VA.033000 1/3-unit (app. 12 g) 800 pcs

3775.VA.050000 1/2-unit (app. 18 g) 720 pcs

3775.VA.101000 1-unit (app. 35 g) 400 pcs

3775.VA.102000 2-unit (app. 70 g) 240 pcs

3775.VA.104000 4-unit (app. 145 g) 120 pcs

HUMIDITY INDICATOR CARDS

Humidity Indicator Cards display the moisture level within

the moisture barrier bags. The Indicator Cards are free of cobalt.

• Each unit is packed in a Dry-Shield-bag

Part Nr. Quantity

3785.0560.CF 5% - 10% - 60%

Relative humidity range

125 pcs

3785.1060.CF 10% - 20% - 30% - 40%

- 50% - 60%

Relative humidity range

200 pcs

To calculate the

required number of

desiccant units (TME)

follow the guidelines

of the DIN 55474

standard.

To calculate the

required number of

desiccant units (TME)

follow the guidelines

of the DIN 55474

standard.

DRY-SHIELD-JEDEC

SHIELDING BAGS

Part Nr. Bag sizes inner dim. Bags per box

3710.DR150.0426 102 x 660 mm 100 pcs

3710.DR150.0626 152 x 660 mm 100 pcs

3710.DR150.1026 254 x 660 mm 100 pcs

3710.DR150.1626 406 x 660 mm 100 pcs

3710.DR150.1818 457 x 457 mm 100 pcs

• Shielding bag with moisture barrier

• Complies with JEDEC-STD-033

• EMI - Shielding > 40 db

• Specially designed for ESD and moisture vapor barrier applica-

tions

• Mulitlayer construction – Nylon, Aluminium and Polyethylene

• Heat sealable

• Can be used for vacuum packaging applications

• Standard print: Product name, ESD symbol, barrier bag symbol,

Recycling symbol and production date

SHIELDING PACKAGING MATERIAL, DESICCANT BAGS, HUMIDITY INDICATOR CARDS
