112 2020/2021 IEC EN 7500.O.SK.N 7500.O.SK 7500.O.N 7500.O 7500.TG3 7500.TG3.H 7500.TG3.SK IEC EN 7500.O.N TOP GUN TM 3 / TOP GUN TM WITH SIDEKICK (FOOT PEDAL) ORION TM WITH SIDEKICK (FOOT PEDAL) / ORION TM T echnical de…
111
2020/2021
IEC
EN
7520.SIB3.SBP.2R
7520.SIB3.250.RD
7520.SIB3.330.RD
AERO-BODY ION BAR SIB3 RD + CONTROLLER
AIR IONIZERS
Part Nr.
Aero-Body Ion Bar SIB3 RD
7520.SIB3.250.RD 377 mm, 5 emitters
7520.SIB3.330.RD 457 mm, 6 emitters
Accessories
7520.SIB3.SBP.2R Controller for SIB3-250 RD/330 RD
• Suitable for down-stream applications i.e. „laminar airflow boxes“
• Air assistance for various applications
• Pulsed AC high voltage Ionization
• Each tip emits positive and negative ions
• Self-balancing ± 30V
• Control input and alarm output connector
• Power supply 230V/AC via controller
• One controller is suitable for two ion bars
• Adjustments on controller side
• Easy emitter replacement
Controller for SIB3-250 RD/330 RD
• For up to 2 ion bars
• Set-up of bar is done via controller
• Power supply 24V/DC via controller
112
2020/2021
IEC
EN
7500.O.SK.N
7500.O.SK
7500.O.N
7500.O
7500.TG3
7500.TG3.H
7500.TG3.SK
IEC
EN
7500.O.N
TOP GUN
TM
3 / TOP GUN
TM
WITH SIDEKICK (FOOT PEDAL)
ORION
TM
WITH SIDEKICK (FOOT PEDAL) / ORION
TM
Technical description and filter as Top Gun
TM
3.
Part Nr.
7500.O.SK Orion with fl exible neck and foot pedal „side kick“ (included)
7500.O Free mountable air nozzle, remote controlled with electrical activation
7500.O.N Free mountable air nozzle with proximity sensor
7500.O.SK.N Orion with fl exible neck and proximity sensor
AIR IONIZERS
• Quickly neutralizes static charges
• Ergonomically designed features
• Air pressure supply needed between 1 and 6,8 bar
• For use in electronic and cleanroom manufacturing
• Replaceable filter (0,01µ)
• Variable air flow (only Top Gun 3)
• Ionization voltage applied only when the air flows
• Ionization inherently balanced to ± 15 V
• AC technology
• Ozone production: 0,001 ppm
(measured 45 cm in front of the unit)
• AirGun: Dissipative Polycarbonate/ABS
• Connecting cable: Dissipative Polyurethane
• Controller Size: 13,2 x 8,5 x 16,4 cm (W x H x D)
Part Nr.
Top Gun
TM
3
7500.TG3 Standard version, cable length 2,1 m
7500.TG3.42 Special version, cable length 4,2 m
Top Gun
TM
with sidekick
7500.TG3.SK with fl exible neck and foot pedal „side kick“
Filter for TG3 and Orion Qty.
7500.TG3.F Filter 2 pcs
7500.TG3.F.T Special fi lter, Tefl on
®
2 pcs
Accessories
7500.TG3.H Gun hanger
113
2020/2021
IEC
EN
IEC
EN
7500.6115.MS
7500.6115.SWT
7500.O.SK.N
AIRFORCE 6115
• Quickly neutralizes static charges
• Ergonomically designed features
• Triggered by button on the gun grip
• Replaceable emitter module and air filter
• Ionization inherently balanced to ± 30 V
• Easy maintenance
• DC technology (Steady State DC)
• Air pressure supply needed
Includes:
Air gun, Controller 24 V AC, Power supply 230V AC
Applications:
Cleaning of liquid crystal displays (LCD), Lenses, etc.
Neutralizes static charges in the electronics,
optics and pharmaceutical industry.
Part Nr.
7500.6115.PLUS AirForce 6115 with power supply
7500.6115 AirForce 6115 without power supply
7500.6115.N Power supply 230 VAC
7500.6115.SWT Foot pedal AirForce 6115
7500.6115.MS Swivel arm
7500.6115.F Air fi lter cartridge
ECO GUN
• Quickly neutralizes static charges
• Triggered by button on the gun grip
• Piezoceramic high voltage transformer
• High frequency, AC ionisation (HF-AC)
• Easy maintenance
• No power supply needed
• Monitoring of high voltage with LED
• Adjustable air flow by choke valve
• operating pressure: 3 – 5 bar
Application: Cleaning of plastic parts
Part Nr.
7530.IG Eco gun
AIR IONIZERS
