183 2020/2021 2000 2500 ! HANDLING AND STORAGE SHEL VING SYSTEM Stability and flexibility are the key concepts behind our galvanized steel shelving system. The system is easy to assemble and may be extended in either dir…
182
2020/2021
5366.550.350.L
5366.550.350.TB
• Made of dissipative PE hard foam
• Permanent, static dissipative, carbon loaded foam
• Cross linked, closed cell
• Abrasion resistant, non-corrosive
• 25 slots / width of slots: 3 mm / length of slots: 12 mm
• Two cut edges
Part Nr. Dimensions
4550.25.0255.LP 355 x 255 x 25 mm
• Permanent black conductive Polypropylene
• Capacity: 25 boards
• Distance between two slots: app 9,5 mm
Part Nr. Outer Dimensions (L x W x H)
5366.210.S 210 x 275 x 95 mm, 3 mm slot
5366.350.L 350 x 270 x 130 mm, 2,4 mm slot
FOAM PCB HOLDERCONDUCTIVE PCB RACK
• Permanent, carbon loaded, dissipative Polypropylene
• For storage of printed circuit boards
• Capacity: Long side up to 29 PCB’s, short side up to 19 PCB’s
• Naps 14 mm, quadratic
• Distance between naps 3 mm
Part Nr.
5366.550.350.L 557 x 357 x 22mm
5366.550.350.TB Carrying handle
• Permanent, carbon loaded, dissipative Polypropylene
• For storage of printed circuit boards
• Capacity: Long side up to 19 PCB’s, short side up to 13 PCB’s
• Naps Ø 15 mm
• Distance between naps 1,8 mm
Part Nr. Dimensions
5366.350.250.G 357 x 257 x 14 mm
DISSIPATIVE PCB HOLDER DISSIPATIVE PCB HOLDER
application example
HANDLING AND STORAGE
183
2020/2021
2000 2500
!
HANDLING AND STORAGE
SHELVING SYSTEM
Stability and flexibility are the key concepts behind our galvanized
steel shelving system.
The system is easy to assemble and may be extended in either
direction.
• Posts made of profiled steel 30 x 30 mm
• Rugged galvanized steel shelves
• Shelves thickness - 40 mm
• Adjustable at 50 mm increments
• Stackable
• Shelves width: 970 mm
• Shelves depth: 400 / 500 / 600 mm
• Posts length: 2000 / 2500 mm
• Load-bearing capacity: 100 kg
Height in mm:
Do it yourself system
Width in mm: 1030 1000 1030 1000
Description: Standard shelf Optional shelf Standard shelf Optional shelf
Number of shelves: 5 5 6 6
Depth in mm Shelf load-bearing Part Nr.
400 100 kg 5370.RB.1111 5370.RB.1131 5370.RB.1171 5370.RB.1191
500 100 kg 5370.RB.1112 5370.RB.1132 5370.RB.1172 5370.RB.1192
600 100 kg 5370.RB.1113 5370.RB.1133 5370.RB.1173 5370.RB.1193
Side and back wire enclosure panels on request
Optional
Part Nr. for shelf - Part Nr.
Side plates made of galvanized steel, 0,75 mm thickness
5370.RB.1111.SP.A 5370.RB.1111
5370.RB.1112.SP.A 5370.RB.1112
5370.RB.1113.SP.A 5370.RB.1113
Back plates made of galvanized steel, 0,75 mm thickness
5370.RB.BP.A 5370.RB.1111
5370.RB.1112
5370.RB.1113
Single shelves
5370.RB.400.SH 5370.RB.1111
5370.RB.500.SH 5370.RB.1112
5370.RB.600.SH 5370.RB.1113
184
2020/2021
IEC
EN
IEC
EN
IEC
EN
IEC
EN
5390.200
5390.200.SR
• Made of galvanized steel
• For tote boxes transport
• The upper shelf can be assembled in two positions
(horizontal or inclined)
• 4 conductive swivel rubber castors,
Ø 75mm, 2 castors with brake
• Silent and smooth operation
• Overall load bearing up to 150 kg for a uniformly
distributed load
• ESD symbol
Part Nr. Dimension
5390.232.DS 615 x 415 x 505 mm (L x W x H)
Boxes not included
• Made of galvanized steel
• For tote boxes transport
• 4 conductive swivel rubber castors,
Ø 75mm, 2 castors with brake
• Silent and smooth operation
• Overall load bearing up to 150 kg for a
uniformly distributed load
• ESD symbol
Part Nr. Dimension
5390.231 615 x 415 x 135 mm (L x W x H)
5390.ZS 860 mm Pull rod (optional)
• Made of galvanized steel
• Includes 4 swivel rubber castors, 2 with brake
• Conductive castors 100 mm Ø
• Silent and smooth operation
• Overall load bearing up to 150 kg for a uniformly distributed load
• ESD symbol
• Delivered with the handle non mounted
Part Nr. Dimension
5390.1198 610 x 410 mm
TRANSPORT ROLLI
- DOUBLE-DECKER
TRANSPORT ROLLI
FOR TOTE BOXES
UTILITY CART
FOR TOTE BOXES
TRANSPORT ROLLI
FOR TOTE BOXES
• Made of galvanized steel
• Includes 4 swivel rubber castors
• Conductive castors 100 mm Ø
• Silent and smooth operation
• Overall load bearing up to 150 kg
for a uniformly distributed load
• ESD symbol
Part Nr. Dimension Description Castor Colour
5390.200 610 x 410 mm 2 with brake black
5390.800 810 x 610 mm 2 with brake black
5390.200.SR 610 x 410 mm without brake grey
5390.200.SR.S
610 x 410 mm 2 with brake grey
Accessories
5390.ZS 860 mm Pull rod (optional)
TRANSPORT SYSTEMS
