71
2020/2021
IEC
EN
IEC
EN
IEC
EN
WRIST STRAPS
Adjustable, elastic, with silver impregnated threads
interwoven on the inside, hypoallergenic
Part Nr. Colour Connection
2050.750.3 Light blue 3 mm snap
2050.750.7 Light blue 7 mm snap
2050.750.10 Light blue 10 mm snap
2051.750.3 Dark blue 3 mm snap
2051.750.10 Dark blue 10 mm snap
STAINLESS STEEL BAND
DISPOSABLE WRIST STRAP
Expandable, adjustable band with an insulated shock resistant ex-
terior, protects the wearer from electrical shocks, hypoallergenic
Part Nr. Colour Connection Size
2052.750.5.3 Black 3 mm snap adjustable
2052.750.5.10 Black 10 mm snap adjustable
Dissipative Nylon wrist strap, ideal for visitors and one time use
applications.
• Sizes: length 1,5 m, width 12,5 mm
• Black wrist strap with a looped end
• Metal clip for ground connection
• Do not use with voltages above 250 V
Part Nr. Qty.
2060.5410.K 1 box = 100 pieces
PERSONNEL GROUNDING
72
2020/2021
2100.752.*
2101.780.3.10
2100.751.*
2101.751.3.2
IEC
EN
IEC
EN
2101.780.3.10
2100.752.*
2100.751.*
COIL CORDS
• Lightweight 2,4 m coil cords
• 10 mm snaps
Part Nr. Colour Connection
2 x 1 Mohm resistors, length: 2,4 m
2100.752.3.10 Light blue 3/10 mm snap
2100.752.7.10 Light blue 7/10 mm snap
2100.752.10.10 Light blue 10/10 mm snap
2101.752.3.10 Black 3/10 mm snap
2101.752.10.10 Black 10/10 mm snap
2 x 1 Mohm resistors, length: 3,6 m
2101.752.3.10.1 Black 3/10 mm snap
1 Mohm resistors, length: 2,4 m
2100.751.3 Light blue
3 mm snap/
banana plug
2100.751.7 Light blue
7 mm snap/
banana plug
2100.751.10 Light blue
10 mm snap/
banana plug
2101.751.3 Black
3 mm snap/
banana plug
2101.751.10 Black
10 mm snap/
banana plug
MINI COIL CORDS
• Ultralight weight
• 2,4 m length
Part Nr. Colour Connection
2 x 1 Mohm resistors
2101.780.3.10 * Black 3/10 mm snap
2101.780.3 Black
3 mm snap/
banana plug
1 Mohm resistors
2101.751.3.2 Black
3 mm snap/angled 4 mm
socket for 3M system
PERSONNEL GROUNDING
73
2020/2021
7100.181
7100.181.H
7100.181.K
7100.181.K.M
7100.181.C
SAFETY PIPS
Continuous wrist strap monitor
Test method: Impedance capacitive measurement
Test range: 1 MOhm ...(100 pF + 2 MOhm) OK
HI-Fail > 5 Mohm
LO-Fail < 400 kohm
Signal: Audible and visible (7100.181)
+ visible and via relay output (7100.181.K)
Part Nr.
7100.181 Safety Pips with a 10 mm snap (battery operated)
incl. calibration certifi cate
7100.181.K Safety Pips with relay output, 10 mm snap
Operation: 230 VAC power supply
incl. calibration certifi cate
7100.181.C Calibration Unit for Safety Pips / Safety Pips K
incl. calibration certifi cate
7100.181.103 Power supply 230V AC for 7100.181 retrofi t
7100.181.H Mounting bracket for Safety Pips
7100.181.K.M Additional module with 3 LED’s (two colours: red and green),
for Safety Pips K with about 2 m connecting cable
application example
GROUNDING ACCESSORIES
