161 2020/2021 IEC EN IEC EN ! SMALL COMPONENTS BOXES COMP ARTMENTED BOXES COMP ARTMENTED BOXES • Permanent, carbon loaded, conductive material • 6 compartments • Stackable Part Nr . Outer Dimensions 5150.831 266 x …
160
2020/2021
IEC
EN
IEC
EN
• Permanent, carbon loaded, conductive material
• 6 compartments
• Stackable
Part Nr. Outer Dimensions
5150.830 273 x 265 x 187 mm (W x D x H)
6 compartments
drawer dimensions: 261 x 238 x 20 mm
830 box compartment layout - permanent conductive, black
Part Nr. Inner Dimension Compartments
5150.830.A 61 x 56 mm 16
5150.830.B 82 x 36 mm 18
5150.830.C 34 x 36 mm 42
COMPARTMENTED BOXES
COMPARTMENTED BOXES
• Permanent, carbon loaded, conductive material
• 4 compartments
• Stackable
Part Nr. Outer Dimensions
5150.815 266 x 365 x 305 mm (W x D x H)
4 compartments
drawer dimensions: 250 x 340 x 62 mm
815 box compartment layout - permanent conductive, black
Part Nr. Inner Dimension Compartments
5150.815.A 116 x 160 mm 4
5150.815.B 75 x 105 mm 9
5150.815.C 75 x 160 mm 6
SMALL COMPONENTS BOXES
161
2020/2021
IEC
EN
IEC
EN
!
SMALL COMPONENTS BOXES
COMPARTMENTED BOXES
COMPARTMENTED BOXES
• Permanent, carbon loaded, conductive material
• 6 compartments
• Stackable
Part Nr. Outer Dimensions
5150.831 266 x 365 x 305 mm (W x D x H)
6 compartments
drawer dimensions: 250 x 340 x 40 mm
831 box compartment layout - permanent conductive, black
Part Nr. Inner Dimension Compartments
5150.831.B 75 x 160 mm 6
5150.831.D 77 x 79 mm 12
5150.831.G 45 x 63 mm 25
• Permanent, carbon loaded, conductive material
• 6 compartments
• Stackable
Part Nr. Outer Dimensions
5150.810 265 x 355 x 205 mm (W x D x H)
6 compartments
drawer dimensions: 250 x 340 x 22 mm
Suitable for the SMD boxes
described on page 158.
162
2020/2021
IEC
EN
IEC
EN
1760 mm
470 mm
HANDLING AND STORAGE
Width
Depth
Height
Depth
Width
Height
CAROUSEL STORAGE SYSTEM
• Galvanized steel
• Empty carousel for 12 storage racks 150/1200 series
• Dimension: 1760 x 470 x 470 mm
• Includes a grounding cord
Part Nr. Outer Dimensions
5380.LK.1 1760 x 470 x 470 mm
STORAGE RACKS
• Galvanized Steel
• Outer dimensions: 306 x 552 x 150 mm (W x H x D)
• Empty carousel for 12 storage racks
Part Nr. Content Inner Dimension
5380.LK.1.24 24 bins 85 x 55 x 135 mm (W x H X D)
5380.LK.1.48 48 bins 63 x 35 x 135 mm (W x H X D)
5380.LK.1.60 60 bins 50 x 35 x 135 mm (W x H X D)
Storage rack with 60 bins.
