HANDLING AND STORAGE

TOTE BOXES DIVIDERS FOR PCB´S

Sample

• Permament volume conductive Polypropylene

• For standard tote boxes:

400 x 300 mm

• Honeycomb profile

• Material thickness: 3 mm

• Material weight: 550 g/m²

• High abrasion resistance

• Variable storage system

Standard dividers for tote boxes 400 x 300 x ... mm

Partition sizes: 353 x 253 x 80 /120 / 180 mm (L x W x H)

Cell size: 20 x 20 mm

Rows / max.: 10 x 14 = 140 cells

The individual cell sizes can be modified by removing short and long dividers

Part Nr. Size (L x W x H) Slots

Long dividers for different 400 x 300 mm tote boxes conﬁ guration

5420.353.20.80 353 x 80 x 3 mm 15

5420.353.20.120 353 x 120 x 3 mm 15

5420.353.20.180 353 x 180 x 3 mm 15

Short dividers for different 400x x 300 mm tote boxes conﬁ guration

5420.253.20.80 253 x 80 x 3 mm 11

5420.253.20.120 253 x 120 x 3 mm 11

5420.253.20.180 253 x 180 x 3 mm 11

Custom-made dividers on request

5420.Z.G Customized

Part Nr. Set includes Dimensions

Sets

5420.G2.80 Height: 80 mm

Long divider: 11 (Part Nr.: 5420.353.20.80)

Short divider: 15 (Part Nr.: 5420.253.20.80)

353 x 80 x 3 mm

253 x 80 x 3 mm

5420.G2.120 Height: 120 mm

Long divider: 11 (Part Nr.: 5420.353.20.120)

Short divider: 15 (Part Nr.: 5420.253.20.120)

353 x 120 x 3 mm

253 x 120 x 3 mm

5420.G2.180 Height: 180 mm

Long divider: 11 (Part Nr.: 5420.353.20.180)

Short divider: 15 (Part Nr.: 5420.253.20.180)

353 x 180 x 3 mm

253 x 180 x 3 mm

sample applications

174

2020/2021

• Permanent, carbon loaded, conductive Polypropylene

• Half euro pallet size 800 x 600 x 150 mm

• Perforated support surface

• Stackable

• 3 skids

• Dynamic load up to 400 kg

• Static load up to 800 kg

• Weight: 3,8 kg

• ESD-Symbol

Part Nr. Outer dimensions

5395.400.S 800 x 600 x 150 mm

TRANSPORT PALLET

HANDLING AND STORAGE

CONDUCTIVE CASE

• Permanent conductive carbon loaded Polypropylene

Part Nr. Description Inner dimensions (L x W x H)

5100.K42.N black conductive

case, with foam

insert

240 x 170 x 42 mm

5100.K53 black conductive

case

340 x 250 x 53 mm

TOTE BOXES SEPARATORS

• Permanent, carbon loaded, conductive Polypropylene

Part Nr. Outer dimensions

5401.0253 353 x 253 x 3 mm with 2 cut edges

5401.0353 553 x 353 x 3 mm with 2 cut edges

Separator, carbon loaded conductive Polypropylene with 3 mm Polyethylene foam (glued together), with 2 cut edges

5425.0353.0553.PE 553 x 353 x 6 mm

5425.0253.0353.PE 353 x 253 x 6 mm

sample application

Custom sizes available on request.

175

2020/2021



HANDLING AND STORAGE

• Variable stacking of frames

• Frames with 4 corner hinges, foldable

• Material: conductive PS, carbon loaded

• Dimension: 1200 x 800 x 200 mm

• Weight: about 5,2 kg

• With ESD Symbol

Part Nr. Outer dimensions Inner dimensions

5395.AR 1200 x 800 x 200 mm 1140 x 745 x 200 mm

STACKABLE FRAME FOR PALLETS

• Dimension: 1200 x 800 x 155 mm

• Permanent, carbon loaded, conductive Polypropylene

• Euro pallet size 1200 x 800 x 155 mm

• Static load up to 7.500 kg

• Dynamic load up to 2.500 kg

• Closed top surface with 10 mm frame

• Weight: approx. 15 kg

• ESD-Symbol

• Suitable for the stackable frames 5395.AR

• Shelf load: 500 kg

Part Nr. Outer dimensions

5395.PAL 1200 x 800 x 155 mm

TRANSPORT PALLET

CLOSED TOP SURFACE

• Permanent, carbon loaded, conductive Polypropylene

• Pallet can be reinforced with 3 calvanized metal pipes

• Euro pallet size 1200 x 800 x 150 mm

• Static load up to 4.000 kg

• Dynamic load up to 1.000 kg

• ESD-Symbol

• Stackable

• Weight: 11 kg

• With 7 mm frame

• Shelf load without pipes: 400 kg

with pipes: 800 kg

Part Nr. Outer dimensions Description

5395.800 1200 x 800 x 150 mm Transport pallet

5395.800.MS 3 metal pipes

TRANSPORT PALLET LOAD-BEARING PROPERTIES

Transport pallets have different load-bearing properties:

• Dynamic load:

During the transport with a fork lift.

• Static load:

When storing the pallets on a solid ground.

• Shelf load:

When storing the pallets in a shelf.

dynamic

static

shelf load
