33 2020/2021 IEC EN IEC EN IEC EN IEC EN 355 mm Conductive chipboard BENCHTOPS • Replacements benchtops for upgrading existing benches in offices and laboratories • Hard laminate top side bonded with a conductive glue to…

2020/2021

• 28 pieces

• For use on the tool holder plate

• Conductive

Part Nr.

1950.LZ.8285

HOOK ASSORTMENT

• Dissipative powder coating

Part Nr. Dimensions

1950.LZ.8276 350 x 1200 mm table length

1950.LZ.8272 350 x 1250 mm table length

1950.LZ.8273 350 x 1500 mm table length

1950.LZ.8281 350 x 1600 mm table length

1950.LZ.8274 350 x 1750 mm table length

1950.LZ.8275 350 x 2000 mm table length

TOOL HOLDER PLATE

• Incl. mouse surface

• double jointed arm

• Dissipative powder coating

Part Nr. Mounting panel

1950.LZ.8200 75 mm (VESA)

1950.LZ.8201 100 mm (VESA)

MONITOR-/KEYBOARD SUPPORT

For all commercially available bottles and cans

• Made of steel wire, coated, not conductive

• W x D 135 x 115 mm

• Bottle max. Ø 90 mm

• Total height: 200 mm

• Incl. 2x mounting screws

Part Nr. Colour

1950.ZB.3573 Grey

BOTTLE HOLDER

WORKSTATION SYSTEMS

2020/2021

IEC

355 mm

Conductive chipboard

BENCHTOPS

• Replacements benchtops for upgrading existing

benches in offices and laboratories

• Hard laminate top side bonded with a conductive

glue to a volume conductive chipboard

• Balance hard laminate on the underside

• Available edge: grey ABS

• Standard thickness: 27 mm

Custom sizes and other top side material on request

Part Nr. Colour

1920.Z Light grey

• Shelf unit with 2 or 3 supports, height: 350 mm

• Can be mounted on a benchtop (incl. screws)

• Top side coated with dessipative melamine resin,

depth: 300 mm, thickness: 25 mm

• Dissipative powder coating

• Maximum load 60 kg

Part Nr. Standard dimensions supports

1950.LZ.8333 1200 mm length 2

1950.LZ.8334 1250 mm length 3

1950.LZ.8335 1500 mm length 3

1950.LZ.8336 1600 mm length 3

1950.LZ.8337 1750 mm length 3

1950.LZ.8338 2000 mm length 3

SHELVES

sample application

• Rotary Plate suitable as mounting aid

• 365 x 17 mm stainless steel with 4 x M6 standard threaded

• 330 mm Rotating assembly with stainless steel ball

• Arrest 8 x 45°

• Axial load max. 300kg

• Weight 4 kg

• Grounding via grounding cord with 10 mm snap

• Supplied with dissipative black ECOSTAT

anti slip mat

which can be glued to metallic surfaces

Part Nr. dimensions

1955.DT Ø 365 mm, Height: 17 mm

ROTARY PLATE

• Metallic support 40 x 40 x 2 mm

• Reinforced metallic construction

• Conductive grey paint finish

• Benchtop made of conductive chipboard and

static dissipative hard laminate, 27 mm

• Colour: grey

• 4 Swivel-Castors, 2 with brake

Custom sizes available on request!

Part Nr. Standard dimensions (W x D x H)

1950.LC.3941.MOB 800 x 600 x 752 - 952 mm

1950.LC.3941.MOB.ZA Clipboard optional, 800 x 500 mm,

25 mm, melamine resin coated

1950.LC.3941.MOB.SB Cabinet

MOBILE SIDE TABLE

ON WHEELS

WORKSTATION SYSTEMS

Clipboard optional

Cabinet optional

2020/2021

IEC

• Metallic support, 50 x 40 mm with 2 rugged frames

• Workbench adjustable height between 763 and 873 mm

• Dissipative powder coating

• Benchtop made of conductive chipboard and

static dissipative melamine resin

• Includes 1 earth connecting box

with 2 x 10 mm snaps and 1 x 4 mm banana plug socket

• Suitable for light mechanical work

• Not mounted

Part Nr. Standard dimensions (W x D x H)

Standard table

1950.LU.4018 1000 x 800 x 763 – 873 mm

1950.LU.4038 1250 x 800 x 763 – 873 mm

1950.LU.4058 1500 x 800 x 763 – 873 mm

1950.LU.4088 1750 x 800 x 763 – 873 mm

1950.LU.4118 2000 x 800 x 763 – 873 mm

Extension table (Standard table required!)

1950.LU.6018 1000 x 800 x 763 – 873 mm

1950.LU.6038 1250 x 800 x 763 – 873 mm

1950.LU.6058 1500 x 800 x 763 – 873 mm

1950.LU.6088 1750 x 800 x 763 – 873 mm

1950.LU.6118 2000 x 800 x 763 – 873 mm

WORKBENCHES MELAMINE RESIN COATED

HEIGHT ADJUSTABLE VERSION

ALUMINIUM POSTS

Suitable only for tables

Part Nr. 1950.LU.XXX

WORKSTATION SYSTEMS

• 4 sides selection

• Anodized aluminium profile 45 x 45 mm

continously adjustable height, profile length 1950 mm

• Usable height app. 1500 mm

• Flexible repositioning system

• Cross connecting bar

• Sliding rail frame

• Sliding rail

• Height: 2100 mm

Part Nr. Dimensions suitable for

table width

1950.LU.8312 1235 x 655 x 1950 mm 1250 mm

1950.LU.8313 1485 x 655 x 1950 mm 1500 mm

1950.LU.8315 1735 x 655 x 1950 mm 1750 mm

1950.LU.8316 1985 x 655 x 1950 mm 2000 mm
