157 2020/2021 IEC EN ! SMALL COMPONENTS BOXES HINGED UTILITY BOXES CARBON • Permanent, carbon loaded, conductive material • Include a dissipative PE foam insert (T yp 4550.*) • Lid printed with ESD symbol Par…
156
2020/2021
TRANSPARENT STATIC DISSIPATIVE MATERIALS
DPF-100 POLYESTER FILM
DPF-100 is a transparent static dissipative Polyester film, 2 sides coated.
• Dissipative Polyester film
• Abrasion resistant
• Thickness: 0,1 mm
• Can be used as transparencies for copies
Part Nr. Size Quantity
5235.DPF.100 1220 mm x 100 m 1 roll
5235.DPF.100.A4 DIN A4 100 pcs
5235.DPF.100.Z Custom size on request
DPF-SK 100 SELF-ADHESIVE POLYESTER FILM
DPF SK 100 is a transparent static dissipative, self-adhesive Polyester film. It includes a special
coating on one side and a release film on the other side. It can be applied on flat,
insulative surfaces.
• Dissipative Polyester film
• Self-adhesive
• Abrasion resistant
• Thickness: 0,1 mm
Part Nr. Size Quantity
5235.DPF.SK100 1220 mm x 100 m 1 roll
5235.DPF.SK100.A4 DIN A4 100 pcs
5235.DPF.SK100.Z Custom size on request
157
2020/2021
IEC
EN
!
SMALL COMPONENTS BOXES
HINGED UTILITY BOXES
CARBON
• Permanent, carbon loaded, conductive material
• Include a dissipative PE foam insert (Typ 4550.*)
• Lid printed with ESD symbol
Part Nr. Sizes Foam thickness Quantity
5100.860 55 x 38 x 14 mm 6 mm 100 pcs
5100.861 70 x 45 x 14 mm 8 mm 100 pcs
5100.862 130 x 32 x 14 mm 8 mm 100 pcs
5100.864 77 x 55 x 12 mm 6 mm 100 pcs
5100.865 117 x 90 x 21 mm 14 mm 50 pcs
5100.866 138 x 44 x 14 mm 8 mm 100 pcs
application example
Boxes with soft conductive foam
available on request.
158
2020/2021
IEC
EN
IEC
EN
IEC
EN
5351.1308.014
5351.1308.030 5351.1308.050
5351.1814.080
5351.2212.060
• Black with transparent metallized lid
• Permanent carbon loaded conductive
• Tray compatible size combination
• Spring loaded lid
• Suitable for compartmented box Part Nr. 5150.810
(see page 161)
Part Nr. Inner sizes Quantity
5100.880 16 x 12 x 15 mm small 100 pcs
5100.881 37 x 12 x 15 mm medium 50 pcs
5100.882 40 x 37 x 15 mm big 25 pcs
5100.883 68 x 57 x 15 mm big 10 pcs
• Permanent carbon loaded conductive
• Tray compatible size combination
• Spring loaded lid
• Suitable for compartmented box Part Nr. 5150.810
(see page 161)
Part Nr. Inner sizes Quantity
5100.873 16 x 12 x 15 mm small 100 pcs
5100.874 37 x 12 x 15 mm medium 50 pcs
5100.875 40 x 37 x 15 mm big 25 pcs
5100.876 68 x 57 x 15 mm big 10 pcs
SMD BOXES
CARBON
SMD BOXES
CARBON
SMALL COMPONENTS BOXES
HINGED LID BOXES
CARBON
• Permanent carbon loaded conductive
• Cover and box in one piece
• Hinge and snap closure
Part Nr. Inner sizes
5351.1308.014 130 x 80 x 14 mm
5351.1308.030 130 x 80 x 30 mm
5351.1308.050 130 x 80 x 50 mm
5351.1814.080 178 x 133 x 78 mm
5351.2212.060 221 x 121 x 55 mm
