18 2020/2021 14 mm IEC EN ! Custom sizes available on request ECOST A T ® ANTI-F A TIGUE MA TS „EASY ST ANDING“ Anti-fatigue mats with optional yellow bevelled edges or with interlocking system Part Nr . Standard Sizes C…
17
2020/2021
IEC
EN
1330.PF.06 .R
1330.PF.06 .RES
ECOSTAT
®
SELF-LAYING FLOORING
Flooring material for „do it yourself“ floor laying
• Two layer material (Puzzle)
• Volume conductive
• Abrasion resistant
• Conductive backing
• Suitable for chair castors
• Suitable for forklift traffic
• Reusable
• Self-laying (without glue)
• Easy handling using tools for woodwork
• Colour: grey
Part Nr. Standard Size Quantity
Puzzle tile
1330.PF.06 635 x 635 x 6 mm 6 pieces
(2,42 qm)
1330.PF.ESD 635 x 635 x 6 mm
with ESD symbol
1 piece
Transition (optional)
1330.PF.06.R 635 x 310 mm 1 piece
Corner (optional)
1330.PF.06.RES 310 x 310 mm 1 piece
ECOSTAT
®
-DF PUZZLE-6.0
DOVETAIL JOINT
dovetail joint
conductive
backing
Instructions for use
18
2020/2021
14 mm
IEC
EN
!
Custom sizes available on request
ECOSTAT
®
ANTI-FATIGUE MATS
„EASY STANDING“
Anti-fatigue mats with optional yellow
bevelled edges or with interlocking system
Part Nr. Standard Sizes Colour
1306.B1.0650.0950 650 x 950 x 13 mm incl. 2 x 10 mm snap Black
1306.B1.Z Custom size on request Black
Static dissipative Anti-Fatigue material, for use in EPA´s with hard floors, improves worker comfort and productivity.
• Static dissipative PUR material
• Ergonomic
• Soft and Elastic
• Dome cell structure
• Improved standing comfort
• Heat and sound absorbent
• Improved Anti-Fatigue properties
• Possible extension by glueing
• Blister diameter: 14 mm
• Class B1
• Anti-skid and shock absorbent
• Bevel sides
• 10 mm snap connection
• Standard mats sizes
Custom sizes available on request
ECOSTAT
®
ANTI-FATIGUE MATS
19
2020/2021
8 mm
IEC
EN
1307.B1.Q970.*
1307.B1.0650.0650.VC
1307.B1.0650.*
!
ECOSTAT
®
ANTI-FATIGUE MATS
Grounding box
see page 76
ECOSTAT
®
ANTI-FATIGUE MATS
„EASY WALKING“
Part Nr. Standard Sizes Colour
1307.B1.0650.0940.VE End tile: 650 x 940 x 13 mm incl. 10 mm snap Black
1307.B1.0650.0910.VM Middle tile: 650 x 910 x 13 mm Black
1307.B1.0650.0650.VC Corner tile: 650 x 650 x 13 mm incl. 10 mm snap Black
1307.B1.Q970.Q635.VE End tile: 970 x 635 x 13 mm incl. 10 mm snap Black
1307.B1.Q970.Q610.VM Middle tile: 970 x 610 x 13 mm Black
1307.B1.Z Custom size on request Black
2821.AL.50 self-adhesive aluminium tape, 50 m/roll
Static dissipative Anti-Fatigue material, for use in EPA´s with hard floors, improves worker comfort and productivity.
• Static dissipative PUR material
• Ergonomic
• Soft and Elastic
• Dome cell structure
• Improved standing comfort
• Heat and sound absorbent
• Improved Anti-Fatigue properties
• Interlocking mats for large area, easy extension
• Custom size available on request
• Smallest configuration: 2 end tiles
• Blister diameter: 8 mm
• Class B1
• Anti-skid and shock absorbent
• Bevel sides
• 10 mm snap connection
• Standard mats sizes
Custom sizes available on request
application example
2821.AL.50
Alternative grounding
possible with a self-
adhesive aluminium tape
