130 2020/2021 IEC EN ! DR Y -SHIELD ESD/EMI SHIELDING BAGS Part Nr . Bag sizes inner dim. Bags per box 3710.DR.0426 102 x 660 mm 100 pcs 3710.DR.0626 152 x 660 mm 100 pcs 3710.DR.0810 203 x 254 mm 100 pcs 3710.DR.1012 25…
129
2020/2021
IEC
EN
HIGHSHIELD
®
– TYPE A
RECLOSABLE
• Shielding bag,“metal in“ construction
• Protection against electrostatic discharge and electrostatic fields
• Outer layer - dissipative Polyester
• Inner layer - dissipative Polyethylene
• Aluminium metallized
• Zip lock
• Standard print: Product name, ESD symbol, Recycling symbol
• Production date „MMYYYY“ stamped in welding seam
• Each unit is sealed in a Highshield
®
bag
Part Nr. Bag sizes inner dim. Bags per unit
3325.WV.0305.A 76 x 127 mm 100 pcs
3325.WV.0406.A 102 x 152 mm 100 pcs
3325.WV.0508.A 127 x 203 mm 100 pcs
3325.WV.0610.A 152 x 254 mm 100 pcs
3325.WV.0810.A 203 x 254 mm 100 pcs
3325.WV.0812.A 203 x 305 mm 100 pcs
3325.WV.1012.A 254 x 305 mm 100 pcs
3325.WV.1014.A 254 x 356 mm 100 pcs
3325.WV.1216.A 305 x 406 mm 100 pcs
3325.WV.1218.A 305 x 457 mm 100 pcs
3325.WV.1418.A 356 x 457 mm 100 pcs
3325.WV.1818.A 457 x 457 mm 100 pcs
SHIELDING PACKAGING MATERIAL
Sealed packing unit
130
2020/2021
IEC
EN
!
DRY-SHIELD ESD/EMI SHIELDING BAGS
Part Nr. Bag sizes inner dim. Bags per box
3710.DR.0426 102 x 660 mm 100 pcs
3710.DR.0626 152 x 660 mm 100 pcs
3710.DR.0810 203 x 254 mm 100 pcs
3710.DR.1012 254 x 305 mm 100 pcs
3710.DR.1020 254 x 508 mm 100 pcs
3710.DR.1026 254 x 660 mm 100 pcs
3710.DR.1626 406 x 660 mm 100 pcs
3710.DR.1818 457 x 457 mm 100 pcs
• Shielding bag with moisture barrier
• Protection against electrostatic discharge
and electrostatic fields
• Complies with MIL-B81705 Type 1 Class 1
• EMI - Shielding > 40 db
• The moisture barrier property is achieved through the multilayer
construction which includes disspipative
Polyester, Aluminium metallization and dissipative
Polyethylene
• Heat sealable
• Can be used for vacuum packaging applications
• Standard print: Product name, ESD symbol,
barrier bag symbol, Recycling symbol and production date
Custom sizes available on request.
application example
SHIELDING PACKAGING MATERIAL
131
2020/2021
IEC
EN
DRY-SHIELD TYPE A SHIELDING BAGS
Part Nr. Bag sizes inner dim. Bags per unit
3715.DR.0426.A 102 x 660 mm 100 pcs
3715.DR.0626.A 152 x 660 mm 100 pcs
3715.DR.0810.A 203 x 254 mm 100 pcs
3715.DR.1012.A 254 x 305 mm 100 pcs
3715.DR.1020.A 254 x 508 mm 100 pcs
3715.DR.1026.A 254 x 660 mm 100 pcs
3715.DR.1626.A 406 x 660 mm 100 pcs
3715.DR.1818.A 457 x 457 mm 100 pcs
• Shielding bag with moisture barrier
• Protection against electrostatic discharge
and electrostatic fields
• Complies with MIL-B81705 Type 1 Class 1
• EMI - Shielding > 40 dB
• The moisture barrier property is achieved through the multilayer
construction which includes disspipative
Polyester, Aluminium metallization and dissipative
Polyethylene
• Heat sealable
• Can be used for vacuum packaging applications
• Standard print: Product name, ESD symbol,
barrier bag symbol, Recycling symbol and production date
imprinted in wellding rod
• Each unit is sealed in a Highshield
®
bag
SHIELDING PACKAGING MATERIAL
application example
