185 2020/2021 IEC EN ! TRANSPORT SYSTEMS EP A WORKSHOP TROLLEY • Stable steel construction • Dissipative powder coating • T op surface with melanin coating • 2 shelves adjustable in a 500 mm grid • 4 drawers : 1 x 50 / 1…

184

2020/2021

IEC

5390.200

5390.200.SR

• Made of galvanized steel

• For tote boxes transport

• The upper shelf can be assembled in two positions

(horizontal or inclined)

• 4 conductive swivel rubber castors,

Ø 75mm, 2 castors with brake

• Silent and smooth operation

• Overall load bearing up to 150 kg for a uniformly

distributed load

• ESD symbol

Part Nr. Dimension

5390.232.DS 615 x 415 x 505 mm (L x W x H)

Boxes not included

• Made of galvanized steel

• For tote boxes transport

• 4 conductive swivel rubber castors,

Ø 75mm, 2 castors with brake

• Silent and smooth operation

• Overall load bearing up to 150 kg for a

uniformly distributed load

• ESD symbol

Part Nr. Dimension

5390.231 615 x 415 x 135 mm (L x W x H)

5390.ZS 860 mm Pull rod (optional)

• Made of galvanized steel

• Includes 4 swivel rubber castors, 2 with brake

• Conductive castors 100 mm Ø

• Silent and smooth operation

• Overall load bearing up to 150 kg for a uniformly distributed load

• ESD symbol

• Delivered with the handle non mounted

Part Nr. Dimension

5390.1198 610 x 410 mm

TRANSPORT ROLLI

- DOUBLE-DECKER

TRANSPORT ROLLI

FOR TOTE BOXES

UTILITY CART

FOR TOTE BOXES

TRANSPORT ROLLI

FOR TOTE BOXES

• Made of galvanized steel

• Includes 4 swivel rubber castors

• Conductive castors 100 mm Ø

• Silent and smooth operation

• Overall load bearing up to 150 kg

for a uniformly distributed load

• ESD symbol

Part Nr. Dimension Description Castor Colour

5390.200 610 x 410 mm 2 with brake black

5390.800 810 x 610 mm 2 with brake black

5390.200.SR 610 x 410 mm without brake grey

5390.200.SR.S

610 x 410 mm 2 with brake grey

Accessories

5390.ZS 860 mm Pull rod (optional)

TRANSPORT SYSTEMS

185

2020/2021

IEC

TRANSPORT SYSTEMS

EPA WORKSHOP TROLLEY

• Stable steel construction

• Dissipative powder coating

• Top surface with melanin coating

• 2 shelves adjustable in a 500 mm grid

• 4 drawers : 1 x 50 / 1 x 100 / 1 x 150 7 1 x 200

• Each drawer lockable / central lock with a key

• 4 conductive castors: Ø 125 mm

• 2 conductive swivel castors with brake

• Overall load bearing: 250 kg

• ESD symbol

• pre-assembled

Part Nr. Dimensions

5390.LW.1001 1200 x 600 x 815 mm (L x W x H)

Optional coverings

5390.LW.1001.659 Mats for shelf storage (Part Nr. 1452.659.* see page 21)

5390.LW.1001.7300 ECOSTAT

Anti slip mat (Part Nr. 1453.7300.* see page 22)

Other versions

available on request.

The electrostatic dissipative transport rolli collector is the

ideal solution for moving and storing transport rollis safely.

• Made of galvanized steel

• Includes 4 swivel rubber castors, 2 with brake

• Conductive castors Ø 100 mm

• Silent and smooth operation

• Overall load bearing up to 150 kg

• Max. Load: 8 Transport Rollis part no. 5390.200

or 5390.200.SR

• ESD symbol

• For self assembly

Part Nr.

5390.200.WS Transport Rolli Collector

TRANSPORT ROLLI COLLECTOR

• Robust and durable plastic frame made of carbon loaded volume

conductive polypropylene

• For transporting tote boxes

(1 x 600x400 mm or 2 x 400x300 mm)

• Includes 4 swivel rubber castors Ø = 100 mm, 2 with brake

• Silent and smooth operation

• Overall load bearing up to 125 kg

for a uniformly distributed load

• Weight: 4,7 kg

• ESD symbol

• Colour: black

Part Nr.

5390.250 Transport Rolli

TRANSPORT ROLLI

FOR TOTE BOXES

186

2020/2021

IEC

• Stainless steel construction

• 4 conductive castors: Ø 100 mm

• I ncludes 4 swivel rubber castors, 2 castors with brake

• Platform fitted with dissipative ECOSTAT

Anti slip mat

• Overall load bearing: 100 kg for a uniformly distributed load

• ESD symbol

• For self assembly

Part Nr. Dimensions

5390.KW.N 825 x 520 x 950 mm (L x W x H)

UTILITY CART

WITH FOLDABLE HANDLE

• Made of galvanized steel

• Conductive swivel castors

• Rubber castors

• Silent and smooth operation

• 4 conductive swivel castors, 2 with brake

• ESD symbol

• For self assembly

• 1 shelf, fitted with dissipative ECOSTAT

Anti slip mat

• Shelf height: 180 mm

• Overall load bearing up to 125 kg for a uniformly distributed load

• Suitable for PCB racks transport

• castors Ø 100 mm

Part Nr. Dimensions

5390.510.N 950 x 540 x 915 mm (L x W x H)

UTILITY CARTS

3rd shelf optional

• Made of galvanized steel

• Conductive swivel castors

• Rubber castors

• Silent and smooth operation

• 4 conductive swivel castors, 2 with brake

• ESD symbol

• For self assembly

• 2 shelves, fitted with table mats,

• Highest shelf 730 mm

• Overall load bearing up to 150 kg for a uniformly distributed load

• Distance between shelves: 520 mm

• castors Ø 100 mm

• 3rd shelf optional, Distance between shelves: 250 mm

Part Nr. shelf

5390.400 740 x 430 mm

5390.400.A 3rd shelf

UTILITY CART

TRANSPORT SYSTEMS
