124 2020/2021 IEC EN ! CONDUCTIVE P ACKAGING MA TERIAL CARBOST A T ® CUSHION MA TERIAL AND CUSHION SEP ARA TORS Part Nr . Width Length Roll CARBOST A T ® Cushion Material Flat inner and outer layers, 3 layer cushion mate…
123
2020/2021
IEC
EN
!
IEC
EN
CONDUCTIVE PACKAGING MATERIAL
Part Nr. Bag sizes inner dim. Bags per box
3210.150 100 x 150 x 0,08 mm 5000 pcs
3210.151 130 x 200 x 0,08 mm 2500 pcs
3210.152 150 x 225 x 0,08 mm 2500 pcs
3210.153 200 x 250 x 0,08 mm 1500 pcs
3210.154 250 x 300 x 0,08 mm 1000 pcs
3210.155 300 x 400 x 0,08 mm 1000 pcs
3210.156 400 x 500 x 0,08 mm 500 pcs
3210.157 500 x 600 x 0,08 mm 500 pcs
3210.162 350 x 450 x 0,08 mm 1000 pcs
Custom bags, covers and layfl at material
available on request.
CARBOSTAT
®
BAGS
• Permanent, conductive, carbon loaded material
• Protection against electrostatic fields
• Heat sealable
• Recyclable
• Colour: Black
• Standard print: Product name, ESD symbol, Recycling symbol
and production date
Part Nr. Roll width inner dim. Roll length
3230.250 100 x 0,08 mm 500 m
3230.251 130 x 0,08 mm 500 m
3230.252 150 x 0,08 mm 500 m
3230.253 200 x 0,08 mm 500 m
3230.254 250 x 0,08 mm 500 m
3230.255 300 x 0,08 mm 500 m
3230.256 400 x 0,08 mm 250 m
3230.257 500 x 0,08 mm 250 m
3230.258 600 x 0,08 mm 250 m
CARBOSTAT
®
TUBING
• Permanent, conductive, carbon loaded material
• Protection against electrostatic fields
• Heat sealable
• Recyclable
• Colour: Black
• Standard print: Product name, ESD symbol, Recycling symbol
and production date
124
2020/2021
IEC
EN
!
CONDUCTIVE PACKAGING MATERIAL
CARBOSTAT
®
CUSHION MATERIAL AND CUSHION SEPARATORS
Part Nr. Width Length Roll
CARBOSTAT
®
Cushion Material
Flat inner and outer layers, 3 layer cushion material, 160 μm
3250.370 300 mm 100 m 30 m
2
3250.371 400 mm 100 m 40 m
2
3250.372 600 mm 100 m 60 m
2
3250.373 1200 mm 100 m 120 m
2
CARBOSTAT
®
Cushion separators (without print)
3252.550.350 550 x 350 mm (for 600 x 400 mm tote boxes)
3252.350.250 350 x 250 mm (for 400 x 300 mm tote boxes)
tote boxes see pages 165 – 169
• 3 layer cushion material, thickness: 160 μm
• Permanent, conductive, carbon loaded material
• Heat sealable
• Flat inner and outer layers
• Recyclable
• Colour: Black
3 layer = 160 μm
Carbostat
®
2 layer Cushion Material
available on request.
Cushion separator for tote boxes
125
2020/2021
IEC
EN
IEC
EN
!
Part Nr. Width Length Roll
3350.392 300 mm 100 m 30 m
2
3350.393 400 mm 100 m 40 m
2
3350.394 600 mm 100 m 60 m
2
3350.395 1200 mm 100 m 120 m
2
3 layer = 160 μm
3 layer = 160 μm
Custom sizes with or without fl ap
available on request.
HIGHSHIELD
®
CUSHION MATERIAL (WITHOUT PRINT)
Metallized rolls
• Protection against electrostatic discharge and electrostatic fields
• 3 layer cushion material
• Outer layer – HIGHSHIELD film, flat
• Inner layer – PERMASTAT
®
film, flat
• Heat sealable
• Recyclable
Part Nr. Bag Sizes inner dim. Bags per box
3351.0406 100 x 150 mm + 50 mm fl ap 500 pcs
3351.0508 130 x 200 mm + 50 mm fl ap 250 pcs
3351.0609 150 x 225 mm + 50 mm fl ap 250 pcs
3351.0810 200 x 250 mm + 50 mm fl ap 250 pcs
3351.1012 250 x 300 mm + 50 mm fl ap 250 pcs
Delivered only in whole boxes as indicated above
HIGHSHIELD
®
CUSHION POUCHES (WITHOUT PRINT)
Metallized rolls
• Protection against electrostatic discharge and electrostatic fields
• 3 layer cushion material
• Outer layer – HIGHSHIELD film, flat
• Inner layer – PERMASTAT
®
film, flat
• Heat sealable
• Recyclable
SHIELDING PACKAGING MATERIAL
