31
2020/2021
IEC
EN
G H
J
I
M
N
L
K
PARTITIONS FOR DRAWERS
CABINETS – MOBILE
Part Nr. Height Drawer height Drawers
G 1950.LS.1006
500 mm 1 x 50 / 1 x 150 / 1 x 300 mm 3
H 1950.LS.1043
500 mm 1 x 50 / 1 x 100 / 1 x 150 / 1 x 200 mm 4
I 1950.LS.1004
500 mm 5 x 100 mm 5
J 1950.LS.1005
500 mm 1 x 50 / 3 x 100 / 1 x 150 mm 5
K 1950.LS.1003
400 mm 1 x 50 / 2 x 100 / 1 x 150 mm 4
Part Nr. Set Drawer height number of usable
partitions
L
1950.ZB.3011
1 100 – 300 mm 3
M 1950.ZB.3012
2 100 – 300 mm 8
N 1950.ZB.3013
3 100 – 300 mm 15
Cabinets (G-K)
• Solid metal construction with dssipative powder coating
• Dimensions incl. handle: 500 x 640 x 730 mm (W x D x H)
(Part Nr. 1950.LS.1003: 500 x 580 x 620 mm (W x D x H)
• Easy opening drawers
• With central lock
• Moveable
• Suitable for height adjustable workbenches
• Dissipative powder coating
• Galvanized steel systems
• For self assembly
• Adjustable partitions
• Height: 80 mm
• For width 180 – 250 mm
• Up to 450 mm depth
• Continuous height adjustment
Part Nr.
1950.LZ.3590
PC MOUNT
WORKSTATION SYSTEMS
32
2020/2021
• 28 pieces
• For use on the tool holder plate
• Conductive
Part Nr.
1950.LZ.8285
HOOK ASSORTMENT
• Dissipative powder coating
Part Nr. Dimensions
1950.LZ.8276 350 x 1200 mm table length
1950.LZ.8272 350 x 1250 mm table length
1950.LZ.8273 350 x 1500 mm table length
1950.LZ.8281 350 x 1600 mm table length
1950.LZ.8274 350 x 1750 mm table length
1950.LZ.8275 350 x 2000 mm table length
TOOL HOLDER PLATE
• Incl. mouse surface
• double jointed arm
• Dissipative powder coating
Part Nr. Mounting panel
1950.LZ.8200 75 mm (VESA)
1950.LZ.8201 100 mm (VESA)
MONITOR-/KEYBOARD SUPPORT
For all commercially available bottles and cans
• Made of steel wire, coated, not conductive
• W x D 135 x 115 mm
• Bottle max. Ø 90 mm
• Total height: 200 mm
• Incl. 2x mounting screws
Part Nr. Colour
1950.ZB.3573 Grey
BOTTLE HOLDER
WORKSTATION SYSTEMS
33
2020/2021
IEC
EN
IEC
EN
IEC
EN
IEC
EN
355 mm
Conductive chipboard
BENCHTOPS
• Replacements benchtops for upgrading existing
benches in offices and laboratories
• Hard laminate top side bonded with a conductive
glue to a volume conductive chipboard
• Balance hard laminate on the underside
• Available edge: grey ABS
• Standard thickness: 27 mm
Custom sizes and other top side material on request
Part Nr. Colour
1920.Z Light grey
• Shelf unit with 2 or 3 supports, height: 350 mm
• Can be mounted on a benchtop (incl. screws)
• Top side coated with dessipative melamine resin,
depth: 300 mm, thickness: 25 mm
• Dissipative powder coating
• Maximum load 60 kg
Part Nr. Standard dimensions supports
1950.LZ.8333 1200 mm length 2
1950.LZ.8334 1250 mm length 3
1950.LZ.8335 1500 mm length 3
1950.LZ.8336 1600 mm length 3
1950.LZ.8337 1750 mm length 3
1950.LZ.8338 2000 mm length 3
SHELVES
sample application
• Rotary Plate suitable as mounting aid
• 365 x 17 mm stainless steel with 4 x M6 standard threaded
• 330 mm Rotating assembly with stainless steel ball
• Arrest 8 x 45°
• Axial load max. 300kg
• Weight 4 kg
• Grounding via grounding cord with 10 mm snap
• Supplied with dissipative black ECOSTAT
®
anti slip mat
which can be glued to metallic surfaces
Part Nr. dimensions
1955.DT Ø 365 mm, Height: 17 mm
ROTARY PLATE
• Metallic support 40 x 40 x 2 mm
• Reinforced metallic construction
• Conductive grey paint finish
• Benchtop made of conductive chipboard and
static dissipative hard laminate, 27 mm
• Colour: grey
• 4 Swivel-Castors, 2 with brake
Custom sizes available on request!
Part Nr. Standard dimensions (W x D x H)
1950.LC.3941.MOB 800 x 600 x 752 - 952 mm
1950.LC.3941.MOB.ZA Clipboard optional, 800 x 500 mm,
25 mm, melamine resin coated
1950.LC.3941.MOB.SB Cabinet
MOBILE SIDE TABLE
ON WHEELS
WORKSTATION SYSTEMS
Clipboard optional
Cabinet optional
