28 2020/2021 ! • 4 sides selection • Anodized aluminium profile 45 x 45 mm continously adjustable height, profile length 1950 mm • Usable height app. 1500 mm • Flexible repositionning system • Cross connecting ba…
27
2020/2021
IEC
EN
IEC
EN
WORKSTATION SYSTEMS
• Metallic support 40 x 40 x 2 mm
• Reinforced metallic construction
• Workbench adjustable height between 750 and 950 mm
• Conductive grey paint finish
• Benchtop made of conductive chipboard and
static dissipative hard laminate
• Includes 1 earth connecting box
with 2 x 10 mm snaps and 1 x 4 mm banana plug socket
• Not mounted
Part Nr. Standard dimensions (W x D x H)
1950.LC.3906 1200 x 800 x 750 - 950 mm
1950.LC.3036 1250 x 800 x 750 - 950 mm
1950.LC.3056 1500 x 800 x 750 - 950 mm
1950.LC.3916 1600 x 800 x 750 - 950 mm
1950.LC.3086 1750 x 800 x 750 - 950 mm
1950.LC.3116 2000 x 800 x 750 - 950 mm
WORKBENCHES WITH HARD LAMINATE
HEIGHT ADJUSTABLE VERSION
• Shelf unit with 2 or 3 supports, height: 350 mm
• Can be mounted on a benchtop (incl. screws)
• Top side coated with dessipative melamine resin,
depth: 300 mm, thickness: 25 mm
• Dissipative powder coating
• Maximum load 60 kg
Part Nr. Standard dimensions supports
1950.LZ.8333 1200 mm length 2
1950.LZ.8334 1250 mm length 3
1950.LZ.8335 1500 mm length 3
1950.LZ.8336 1600 mm length 3
1950.LZ.8337 1750 mm length 3
1950.LZ.8338 2000 mm length 3
SHELVES
28
2020/2021
!
• 4 sides selection
• Anodized aluminium profile 45 x 45 mm
continously adjustable height, profile length 1950 mm
• Usable height app. 1500 mm
• Flexible repositionning system
• Cross connecting bar
• Sliding rail frame
• Sliding rail
• Height: 2100 mm
Part Nr. Dimensions
1950.LC.8311 1200 mm table length
1950.LC.8312 1250 mm table length
1950.LC.8313 1500 mm table length
1950.LC.8314 1600 mm table length
1950.LC.8315 1750 mm table length
1950.LC.8316 2000 mm table length
ALUMINIUM POSTS 2100
• Additional sliding rail for equipment installation
Part Nr. Dimensions
1950.LZ.3898 1200 mm table length
1950.LZ.3892 1250 mm table length
1950.LZ.3893 1500 mm table length
1950.LZ.3899 1600 mm table length
1950.LZ.3894 1750 mm table length
1950.LZ.3895 2000 mm table length
ADDITIONAL SLIDING RAIL
• Continously adjustable shelf, with front edge
195 / 345 / 495 mm depth available
• Load bearing capacity: 40 kg
• Dissipative powder coating
for 345 mm depth
Part Nr. Dimensions
1950.LZ.8308 1200 mm table length
1950.LZ.8302 1250 mm table length
1950.LZ.8303 1500 mm table length
1950.LZ.8309 1600 mm table length
1950.LZ.8304 1750 mm table length
1950.LZ.8305 2000 mm table length
CONTINOUSLY ADJUSTABLE SHELF
• Galvanized sliding hanger
20 kg load-bearing capacity
• Width 80 mm
Part Nr.
1950.LZ.3406
GALVANIZED SLIDING HANGER
WORKSTATION SYSTEMS
Suitable only for
tables on page 27
29
2020/2021
• Storage rack, 3 compartments
• Dissipative powder coating
Delivered without storage bins
Part Nr. Dimensions
1950.LZ.3901 430 x 155 x 310 mm
STORAGE RACK
• Articulated, moveable storage rack holder
700 mm length
• Load bearing capacity: 15 kg
• Dissipative powder coating
Part Nr. Dimensions
1950.LZ.8248 435 x 165 x 120 mm
MOVEABLE STORAGE RACK
• Continously adjustable storage bin holder
• 40 kg load-bearing capacity
• Galvanized steel
Delivered without storage bins
Part Nr. Dimensions
1950.LZ.8328 1200 mm table length
1950.LZ.8322 1250 mm table length
1950.LZ.8323 1500 mm table length
1950.LZ.8329 1600 mm table length
1950.LZ.8324 1750 mm table length
1950.LZ.8325 2000 mm table length
STORAGE BIN HOLDER
• Extra storage rack holder 15 kg load-bearing capacity
• Dissipative powder coating
Delivered without device
Part Nr. Dimensions
1950.LZ.8235 370 x 370 mm
STORAGE RACK HOLDER
WORKSTATION SYSTEMS
application example
sample applicationsample application
