29
2020/2021
• Storage rack, 3 compartments
• Dissipative powder coating
Delivered without storage bins
Part Nr. Dimensions
1950.LZ.3901 430 x 155 x 310 mm
STORAGE RACK
• Articulated, moveable storage rack holder
700 mm length
• Load bearing capacity: 15 kg
• Dissipative powder coating
Part Nr. Dimensions
1950.LZ.8248 435 x 165 x 120 mm
MOVEABLE STORAGE RACK
• Continously adjustable storage bin holder
• 40 kg load-bearing capacity
• Galvanized steel
Delivered without storage bins
Part Nr. Dimensions
1950.LZ.8328 1200 mm table length
1950.LZ.8322 1250 mm table length
1950.LZ.8323 1500 mm table length
1950.LZ.8329 1600 mm table length
1950.LZ.8324 1750 mm table length
1950.LZ.8325 2000 mm table length
STORAGE BIN HOLDER
• Extra storage rack holder 15 kg load-bearing capacity
• Dissipative powder coating
Delivered without device
Part Nr. Dimensions
1950.LZ.8235 370 x 370 mm
STORAGE RACK HOLDER
WORKSTATION SYSTEMS
application example
sample applicationsample application
30
2020/2021
IEC
EN
B
C D
A
E
F
!
• Integrated task light with LED, approx. 26 W
Luminous Colour 4000 K
Part Nr. Dimension (L x W x H)
1930.TAMETO.SAHQ 956 x 187 x 50 mm
INTEGRATED LED TASK LIGHTELECTRO CONDUITS FOR TABLES
CABINETS – FIXED
Part Nr. Height Drawer height Drawers
A 1950.LC.4133
150 mm 150 mm 1
B 1950.LC.4792
300 mm 3 x 100 mm 3
C 1950.LC.4003
500 mm 1 x 50 / 1 x 150 / 1 x 300 mm 3
D 1950.LC.4882
500 mm 1 x 50 / 1 x 100 / 1 x 150 / 1 x 200 mm 4
E 1950.LC.4002
500 mm 1 x 50 / 3 x 100 / 1 x 150 mm 5
F 1950.LC.4001
500 mm 5 x 100 mm 5
Cabinets (A-F)
• Solid metal construction with conductive grey paint
• Dimensions: 500 x 580 x 360 mm /
500 x 580 x 560 mm (W x D x H)
• Easy opening drawers
• With central lock
• Fixed
• Dissipative powder coating
Suitable only for tables
Part Nr. 1950.LC.XXX
WORKSTATION SYSTEMS
• electro conduit with power outlets 230 V/16A
• Stainless steel - conductive powder coated
• 5 m connecting cable with schuko-plug
For use in Germany
Part Nr. Dimension Schuko-double
power outlet
1950.EL.0058 1200 mm table width 2
1950.EL.0059 1250 mm table width 2
1950.EL.0060 1500 mm table width 3
1950.EL.0061 1600 mm table width 3
1950.EL.0062 1750 mm table width 3
1950.EL.0063 2000 mm table width 3
31
2020/2021
IEC
EN
G H
J
I
M
N
L
K
PARTITIONS FOR DRAWERS
CABINETS – MOBILE
Part Nr. Height Drawer height Drawers
G 1950.LS.1006
500 mm 1 x 50 / 1 x 150 / 1 x 300 mm 3
H 1950.LS.1043
500 mm 1 x 50 / 1 x 100 / 1 x 150 / 1 x 200 mm 4
I 1950.LS.1004
500 mm 5 x 100 mm 5
J 1950.LS.1005
500 mm 1 x 50 / 3 x 100 / 1 x 150 mm 5
K 1950.LS.1003
400 mm 1 x 50 / 2 x 100 / 1 x 150 mm 4
Part Nr. Set Drawer height number of usable
partitions
L
1950.ZB.3011
1 100 – 300 mm 3
M 1950.ZB.3012
2 100 – 300 mm 8
N 1950.ZB.3013
3 100 – 300 mm 15
Cabinets (G-K)
• Solid metal construction with dssipative powder coating
• Dimensions incl. handle: 500 x 640 x 730 mm (W x D x H)
(Part Nr. 1950.LS.1003: 500 x 580 x 620 mm (W x D x H)
• Easy opening drawers
• With central lock
• Moveable
• Suitable for height adjustable workbenches
• Dissipative powder coating
• Galvanized steel systems
• For self assembly
• Adjustable partitions
• Height: 80 mm
• For width 180 – 250 mm
• Up to 450 mm depth
• Continuous height adjustment
Part Nr.
1950.LZ.3590
PC MOUNT
WORKSTATION SYSTEMS
