141
2020/2021
Sicherheitssiegel - Zerstört sich beim Entfernen!
Security seal - Breaks apart on removal!
Elektrostatisch gefährdete Bauelemente
Electrostatic Sensitive Devices (ESDS)
ESD PACKAGING WARNING LABELS
SELF-ADHESIVE PACKAGING WARNING LABELS
• Self-adhesive, – paper on roll, = PVC
• (D = German, E = English, F = French, DE = German/English, DEF = German/English/French)
Part Nr. Sizes Quantity Core diameter
2850.3675.D 36 x 75 mm 1000 pcs per roll Ø 40 mm
2850.3675.E 36 x 75 mm 1000 pcs per roll Ø 40 mm
2850.6 Ø 6 mm (for boards) 4000 pcs per roll Ø 76 mm
2850.26105.DE 26 x 105 mm 1000 pcs per roll Ø 40 mm
2850.26138.DEF 26 x 138 mm 1000 pcs per roll Ø 40 mm
2850.12.5 side length: 12,5 mm 1000 pcs per roll Ø 76 mm
SECURITY SEAL
• Special Security PE seal which breaks apart on removal
• Self-adhesive
• Two languages „German/English“
• Core diameter 40 mm
Part Nr. Sizes Quantity
2850.SEC 26 x 105 mm 1000 pcs per roll
sample application
142
2020/2021
PAPER TAPE
TAPE DISPENSER
TAPE DISPENSER
IDP-STAT
®
PVC ADHESIVE TAPE
• Environment friendly
• Biodegradable
• For manual and automatic tape dispensers
• Low charge surface
• Core diameter: 76 mm
Part Nr. Width Length
2800.T.3866.DE 38 mm 66 m
2800.T.5066.DE 50 mm 66 m
• Permanent, static dissipative surface
• ESD symbol
• Core diameter: 76 mm
• Low charging
Part Nr. Width Length
2820.5066.IDP 50 mm 66 m
• Made of metal
• Tape width up to 50 mm
• Core diameter: 76 mm
• Dissipative black paint finish
• ESD symbol
• Grounding via conductive foam gliders
Part Nr. Dimensions
2890.A.50 225 x 63 x 95 mm (W x D x H)
• Made of ABS
• Tape width up to 25 mm
• Core diameter: 76 mm
• Permanent conductive, carbon loaded
• Incl. 10 mm snap as Earth Bonding Point (EBP)
• ESD symbol
• incl. grounding cord
Part Nr. Dimensions
2890.A.25 215 x 110 x 85 mm (W x D x H)
ADHESIVE TAPES
143
2020/2021
The Polyimide masking tape has a high heat resistance and is used
mainly as masking tape for PCB soldering processes.
• Heat resistance: 230° C
• Very good chemical resistance
• Low charging property
• Backing: insulative
• Core diameter: 76 mm
Part Nr. Width Length
2823.1033.HR 10 mm 33 m
2823.2033.HR 20 mm 33 m
2823.2533.HR 25 mm 33 m
• Material: Polypropylene
• Low charging
• ESD Symbol
• Core diameter: 76 mm
Part Nr. Width Length
2820.3462.12 12 mm 36 m
2820.3462.18 18 mm 36 m
2820.3462.24 24 mm 36 m
2820.3462.48 48 mm 36 m
POLYIMIDE MASKING TAPE ADHESIVE GRID TAPE
ADHESIVE TAPES
PVC ADHESIVE TAPE
• PVC tape
• Permanent, static dissipative surface
• Low charging
• Colour: yellow with ESD symbol
• Core diameter: 76 mm
Part Nr. Width Length
2820.12733.Y 12,7 mm 33 m
2820.25433.Y 25,4 mm 33 m
WARNING ADHESIVE TAPE
• Static dissipative Cellophane, transparent
• Low charging
• ESD Symbol
• Used for marking rejected items
• Core diameter: 76 mm
Part Nr. Width Length
2820.1966 19 mm 66 m
2820.4866 48 mm 66 m
