36 2020/2021 1930.SNL.D4 1930.TEVISIO.784 1930.TEVISIO.D3.5 1930.SNL.LED 1930.K / 1930.K.2 sample application EP A-T ASK LIGHTING MAGNIFIER TEVISIO-LED Part Nr . 1930.TEVISIO.784 EP A task lighting magniﬁ er TEVISIO – mo…

2020/2021

IEC

C D

CABINETS – FIXED

ACCESSORIES FOR MELAMINE RESIN COATED WORKBENCHES

Overview page

Additional sliding rail 28

Galvanized sliding hanger 28

Continously adjustable shelf 28

Moveable storage rack 29

Storage rack 29

Storage rack holder 29

Storage bin holder 29

Metallic cable conduit 30

Overview page

Integrated task light 30

Cabinets 31

Partitions for drawers 31

PC mount 31

Tool Holder Plate 32

Monitor- /Keyboard Support 32

Shelves 33

Cabinets (A-D)

• Solid metal construction with conductive grey paint

• Dimensions: 500 x 580 x 360 mm /

500 x 580 x 560 mm (W x D x H)

• Easy opening drawers

• With central lock

• Fixed

Part Nr. Height Drawer height Drawers

A 1950.LZ.4562

300 mm 1 x 100 / 1 x 200 mm 2

B 1950.LZ.4662

300 mm 1 x 50 / 1 x 100 / 1 x 150 mm 3

C 1950.LZ.4762

500 mm 1 x 50 / 1 x 100 / 1 x 150 / 1 x 200 mm 4

D 1950.LZ.4812

500 mm 3 x 100 / 1 x 200 mm 4

WORKSTATION SYSTEMS

Suitable only for tables

Part Nr. 1950.LU.XXX

application examples

2020/2021

1930.SNL.D4

1930.TEVISIO.784

1930.TEVISIO.D3.5

1930.SNL.LED

1930.K /

1930.K.2

sample application

EPA-TASK LIGHTING MAGNIFIER TEVISIO-LED

Part Nr.

1930.TEVISIO.784 EPA task lighting magniﬁ er TEVISIO – mounting arm: 784 mm

1930.TEVISIO.984 EPA task lighting magniﬁ er TEVISIO – mounting arm: 984 mm

1930.TEVISIO.D3.5 Snap on Lense for TEVISIO

1930.K Mounting clamp, span: 0-65 mm

1930.K.2 Mounting clamp, span: 65-135 mm

• Simple operation with multi-function switch

• Light segments separately switchable to three different light

scenarios

• Lighting intensity 6000 lx at only 14 W power consumption

• Made of static dissipative material

• Continuously dimmable down to 10 %

• 3.5 diopter lens Ø 153 mm, with special conductive coating

• Grounding with 10 mm snap

• Power supply: 100-240 V, 50/60Hz, 3,8 m cord

• Fitted with 48 multichip LEDs

• 3 D joint, light head can be positioned in all planes

• Mounting: with mounting clamp

Snap on Lense for TEVISIO 784 and 984:

• 7 diopter of TEVISIO in combination with snap on lense

EPA-TASK LIGHTING MAGNIFIER SNLQ-LED ESD

Part Nr.

1930.SNL.LED Task lighting magniﬁ er SNLQ LED

1930.K Mounting clamp, span 0-65 mm

1930.K.2 Mounting clamp, span 65-135 mm

1930.SNL.D4 Snap on Lense for SNLQ LED

• LED technology (maintenance-free)

• Made of static dissipative materials

• 3 diopter stadium shaped lens 175 x 105 mm

• Glass magnifier, with special conductive coating

• Segment switching for detection of finest structures and faults

• LED 12W/230V / colour 4000K

• Extendes reach ideal for ESD workstations

• Mounting: with mounting clamp

• ESD symbol

Snap on Lense for SNLQ LED:

• Made of static dissipative materials to snap onto the

magnifier SNLQ LED

• 7 diopter of SNLQ LED in combination with snap on lense

• Glass magnifier, specially coated

WORKSTATION SYSTEMS

2020/2021

EPA WORK PLACE LIGHTING TANEO LED

Part Nr.

1930.TANEO.STZL TANEO, 24 LED's

1930.K Mounting clamp, span 0-65 mm

1930.K.2 Mounting clamp, span 65-135 mm

• Made of static dissipative material

• Colour temperature 4.000 K to 5.000 K

• Continuously dimmable down to 10%

• 30 % energy savings

• Grounding with 10 mm snap

• Power supply: 100-240 V, 50/60Hz

• Mounting: with mounting clamp

without swivel arm (SARL)

with swivel arm (SARKL)

EPA WORK PLACE LIGHTING TANEO LED

Part Nr.

1930.TANEO.SARL TANEO without swivel arm, 24 LEDs

1930.TANEO.SARKL TANEO with swivel arm, 12 LEDs

• Chassis made of aluminum with ESD coating

• Colour temperature 4.700 to 5.300 K

• Continuously dimmable down to 10%

• 30 % energy savings

• Power supply: 100-240 V, 50/60Hz

• Mounting: with mounting bracket (horizontal)

EPA WORK PLACE LIGHTING TAMETO LED

Part Nr.

1930.TAMETO.SAHKQ TAMETO, 2 LED modules

• Chassis made of aluminum and plastic with ESD coating

• Colour temperature 4.000 K, approx. 23 W

• Rocker switch

• Power supply: 220-240 V, 50/60Hz

• Mounting: with mounting bracket

WORKSTATION SYSTEMS
