13 2020/2021 IEC EN 1310.PF .701 .R 1310.PF .701 .RES ECOST A T ® SELF-LA YING FLOORING ECOST A T ® -CF PUZZLE 8.5 INTERLOCKING SYSTEM Tip: Laying with soft-head hammer Interlocking system Flooring material for „do it yo…
12
2020/2021
IEC
EN
1806.HG 1806.RB 1806.AZ
!
ECOSTAT
®
FLOORING
ECOSTAT
®
-DF CENTRA-NV
Hard-wearing Polyamide flooring material on rolls, specially designed for the electronic industry.
Constant electrostatic dissipative properties, using a special conductive glue, Thomsit T412 and a conductive finish, Thomsit R762.
• Electrostatic dissipative Polyamide flooring
• Easy maintenance
• 100 % Polyamide with conductive fiber
• High abrasion resistance
• Available on rolls
Other colours on request!
Part Nr. Sizes Colour
1806.HG 2,0 m x 25 - 35 m Light grey
1806.RB 2,0 m x 25 - 35 m Royal blue
1806.AZ 2,0 m x 25 - 35 m Anthracite
CONDUCTIVE FINISH AND ADHESIVE
FOR CENTRA NV
Conductive glue
For Ecostat
®
-DF CENTRA-NV Polyamide
Consumption: app. 450 g/m
2
Part Nr. Pail
1280.T412 14 kg
Conductive finish
Alternative to copper band
Consumption: app. 150 g/m
2
Part Nr. Pail
1280.R762 10 kg
Instructions for use
Grounding box
see page 76
Aluminium tape
see page 144
ACCESSORIES
13
2020/2021
IEC
EN
1310.PF.701 .R
1310.PF.701 .RES
ECOSTAT
®
SELF-LAYING FLOORING
ECOSTAT
®
-CF PUZZLE 8.5
INTERLOCKING SYSTEM
Tip: Laying with soft-head hammer
Interlocking system
Flooring material for „do it yourself“ floor laying
• Two layer material
• Volume conductive
• Abrasion resistant
• Conductive, elastic backing
• Backing with waffle structure for installation
on problematic substrates (e.g. residual moisture)
• Suitable for chair castors
• Suitable for forklift traffic
• Reusable
• Self-laying (without glue)
• Easy handling using tools for woodwork
• Colour: grey
Part Nr. Standard Size Quantity
Puzzle tile
1310.PF.701 469 x 469 x 8,5 mm 12 pieces
(2,64 sqm)
1310.PF.ESD 469 x 469 x 8,5 mm
with ESD symbol
1 piece
Transition (optional) – self-adhesive
1310.PF.701 .R 1220 x 65 mm 1 piece
Corner (optional) – self-adhesive
1310.PF.701 .RES 711 x 65 mm 2 pieces
conductive
backing
Instructions for use
14
2020/2021
IEC
EN
1250.7004.R
2250.790.2
1250.670 / 1250.680
!
ECOSTAT
®
SELF-LAYING FLOORING
Flooring material for „do it yourself“ floor laying
• Two layer material
• Volume conductive
• Abrasion resistant
• Elastic
• Suitable for chair castors, depending on floor substrate
• Reusable
• Conductive backing
• Self-laying (without glue)
• Rounded edges
• 2 x 10 mm snap
• Incl. Grounding Cord with protective cap, 10 mm
snap/4 mm ring terminal, 1 Mohm safety resistor,
4,5 m length (Part Nr. 2250.790.2, see page 74)
ECOSTAT
®
– STANDARD FLOOR MAT
ECOSTAT
®
– FLOORING
ACCESSORIES
Quick-Lift adhesive
tape see page 15
Grounding box
see page 76
ESD-Floor-Cleaner
see page 199
conductive
backing
conductive
backing
Part Nr. Standard Size Thickness Colour
ECOSTAT
®
Mega – Kautschuk
1250.670.R 1,45 m x 10 m 2 mm Grey
1250.670.Z Custom sizes on request 2 mm Grey
1250.680.R.2 1,22 m x 10 m 3,5 mm Grey
1250.680.Z Custom sizes on request 3,5 mm Grey
ECOSTAT
®
PR – 2.0 PVC
1250.7004.R 2,0 m x 9 m 2 mm Grey
1250.7004.Z Custom sizes on request 2 mm Grey
Part Nr. Standard Size Thickness Colour
ECOSTAT
®
Mega – Rubber
1250.671 1450 x 1650 mm 2 mm Grey
1250.672 1450 x 2500 mm 2 mm Grey
1250.681 1220 x 1650 mm 3,5 mm Grey
1250.682 1220 x 2500 mm 3,5 mm Grey
ECOSTAT
®
PR – 2.0 PVC
1250.7004.L 1500 x 2000 mm 2 mm Grey
