142

2020/2021

PAPER TAPE

TAPE DISPENSER

IDP-STAT

PVC ADHESIVE TAPE

• Environment friendly

• Biodegradable

• For manual and automatic tape dispensers

• Low charge surface

• Core diameter: 76 mm

Part Nr. Width Length

2800.T.3866.DE 38 mm 66 m

2800.T.5066.DE 50 mm 66 m

• Permanent, static dissipative surface

• ESD symbol

• Core diameter: 76 mm

• Low charging

Part Nr. Width Length

2820.5066.IDP 50 mm 66 m

• Made of metal

• Tape width up to 50 mm

• Core diameter: 76 mm

• Dissipative black paint finish

• ESD symbol

• Grounding via conductive foam gliders

Part Nr. Dimensions

2890.A.50 225 x 63 x 95 mm (W x D x H)

• Made of ABS

• Tape width up to 25 mm

• Core diameter: 76 mm

• Permanent conductive, carbon loaded

• Incl. 10 mm snap as Earth Bonding Point (EBP)

• ESD symbol

• incl. grounding cord

Part Nr. Dimensions

2890.A.25 215 x 110 x 85 mm (W x D x H)

ADHESIVE TAPES

143

2020/2021

The Polyimide masking tape has a high heat resistance and is used

mainly as masking tape for PCB soldering processes.

• Heat resistance: 230° C

• Very good chemical resistance

• Low charging property

• Backing: insulative

• Core diameter: 76 mm

Part Nr. Width Length

2823.1033.HR 10 mm 33 m

2823.2033.HR 20 mm 33 m

2823.2533.HR 25 mm 33 m

• Material: Polypropylene

• Low charging

• ESD Symbol

• Core diameter: 76 mm

Part Nr. Width Length

2820.3462.12 12 mm 36 m

2820.3462.18 18 mm 36 m

2820.3462.24 24 mm 36 m

2820.3462.48 48 mm 36 m

POLYIMIDE MASKING TAPE ADHESIVE GRID TAPE

ADHESIVE TAPES

PVC ADHESIVE TAPE

• PVC tape

• Permanent, static dissipative surface

• Low charging

• Colour: yellow with ESD symbol

• Core diameter: 76 mm

Part Nr. Width Length

2820.12733.Y 12,7 mm 33 m

2820.25433.Y 25,4 mm 33 m

WARNING ADHESIVE TAPE

• Static dissipative Cellophane, transparent

• Low charging

• ESD Symbol

• Used for marking rejected items

• Core diameter: 76 mm

Part Nr. Width Length

2820.1966 19 mm 66 m

2820.4866 48 mm 66 m

144

2020/2021

2822.1.5025

2822.2.5066

2822.3.5033

FLOOR MARKING TAPES

Part Nr. Sizes Quantity

2822.1.5025 Thickness: 0,3 mm, PVC 25 m per roll

2822.2.5066 Thickness: 0,07 mm, PP 66 m per roll

Dissipative version

2822.3.5033 Thickness: 0,14 mm, PVC 33 m per roll

• self-adhesive, width: 50 mm

• Cellulose Tape

• Transparent

• Low charging

• Core diameter: 76 mm

Part Nr. Width Length

2820.CT.25 25 mm 50 m

ADHESIVE TAPE TRANSPARENTALUMINIUM TAPE

• Self-adhesive aluminium tape can be used for grounding the

conductive back of floor mats instead of using a snap system

Part Nr. Width Length

2821.AL.50 50 mm 50 m

sample application

ADHESIVE TAPES
