165
2020/2021
IEC
EN
5351.4312.060.992
5351.4317.060.992
IEC
EN
5351.4304.007.992
5351.3213.007.992
5351.6440.007.992
WEZ BLACKLINE
®
– CONDUCTIVE
FUTURA TOTE BOXES
• The new WEZ tote box generation for manual and mechanical
handling. Suitable for any applications and uses.
The new design takes into consideration sophisticated logistical
requirements as well as application of current plastic injection
technologies.
• Hollow corner design in combination with the upper ribbr- rim-
construction offers maximum stability and torsion stiffness.
• Flat bottom with 4-side-chamfer and a tapered roof design, en-
sures smooth transportation on conveyor belts and other materi-
als handling equipments.
• Integrated vertical label holders on all 4 sides for A4 sized
papers.
• Mechanical lifting and moving possible with openings on the
upper rim and compatible with standard available equipment.
Part Nr. Outer Dim. mm
(D x W x H)
Inner Dim. mm
(D x W x H)
Sta-
cked
mm
5351.4312.060.992 400 x 300 x 120 362 x 262 x 115 104
5351.4317.060.992 400 x 300 x 175 362 x 262 x 170 159
5351.6412.060.992 600 x 400 x 120 562 x 362 x 115 104
5351.6417.060.992 600 x 400 x 175 562 x 362 x 170 159
HANDLING AND STORAGE
WEZ BLACKLINE
®
– CONDUCTIVE
STACKABLE TOTE BOXES, VERSION: FLAT BASE
• Permanent, carbon loaded, conductive Polypropylene
• Stackable
• Pallet modular size
• With ESD Symbol
Part Nr. Outer Dim. mm
(D x W x H)
Inner Dim. mm
(D x W x H)
Sta-
cked
mm
5351.2108.007.992 200 x 150 x 100 155 x 106 x 96 83
5351.2113.007.992 200 x 150 x 145 155 x 106 x 142 129
5351.3208.007.992 300 x 200 x 100 254 x 154 x 96 83
5351.3213.007.992 300 x 200 x 145 254 x 154 x 141 128
5351.4304.007.992 400 x 300 x 53 354 x 254 x 49 40
5351.4308.907.992 400 x 300 x 100 354 x 254 x 96 83
5351.4313.907.992 400 x 300 x 145 354 x 254 x 141 128
5351.4320.007.992 400 x 300 x 212 354 x 254 x 208 195
5351.4326.007.992 400 x 300 x 278 354 x 254 x 274 262
5351.4332.007.992 400 x 300 x 320 354 x 254 x 317 303
5351.6404.617.992 600 x 400 x 55 554 x 354 x 41 28
5351.6408.007.992 600 x 400 x 100 554 x 354 x 95 83
5351.6413.007.992 600 x 400 x 145 554 x 354 x 141 128
5351.6420.007.992 600 x 400 x 212 554 x 354 x 208 195
5351.6426.007.992 600 x 400 x 278 554 x 354 x 273 260
5351.6432.007.992 600 x 400 x 320 554 x 354 x 316 303
5351.6440.007.992 600 x 400 x 412 554 x 354 x 407 393
166
2020/2021
IEC
EN
5351.XXX.000.992
5351.XXX.044.992
5351.XXX.032.992
IEC
EN
IEC
EN
WEZ LID – CONDUCTIVE
• Tote boxes stay stackable even when the lids are fitted
WEZ Lids – loose
• Loose lids without fasteners
WEZ Lid with 4 swing latches
• For simple, secure fixing to tote box
WEZ Hinged lid with 2 swing latches
• For simple, secure fixing to tote box
Part-Nr. Dimension mm
WEZ Lids - loose
5351.3200.000.992 300 x 200
5351.4300.000.992 400 x 300
5351.6400.000.992 600 x 400
WEZ Lid with 4 swing latches
5351.3200.044.992 300 x 200
5351.4300.044.992 400 x 300
5351.6400.044.992 600 x 400
WEZ Hinged lid with 2 swing latches
5351.3200.032.992 300 x 200
5351.4300.032.992 400 x 300
5351.6400.032.992 600 x 400
HANDLING AND STORAGE
PAIR OF HINGES
WEZ LIDS
SWING LATCHES
WEZ LIDS
Part Nr. Colour
5351.9980.012.994 Pair of swing latches
for WEZ lids
black
Part Nr. Colour
5351.9980.011.992 Pair of hinges
for WEZ lids
black
167
2020/2021
IEC
EN
5351.3204.390.992
5351.3208.397.992
5351.6426.397.992
WEZ BLACKLINE
®
– CONDUCTIVE
STACKABLE TOTE BOXES, VERSION: FLAT BASE
• Standard version with flat base
• Permanent, carbon loaded, conductive Polypropylene
• Comfortable handle and hinged lid
• 3 standard sizes, in a range of heights
• With ESD Symbol
Part Nr. Outer Dim. mm
(D x W x H)
Inner Dim. mm
(D x W x H)
5351.3204.390.992 300 x 200 x 69 260 x 160 x 39
5351.3208.397.992 300 x 200 x 110 260 x 160 x 95
5351.3213.397.992 300 x 200 x 154 254 x 154 x 139
5351.4304.397.992 400 x 300 x 63 354 x 254 x 58
5351.4308.397.992 400 x 300 x 110 354 x 254 x 95
5351.4313.397.992 400 x 300 x 154 354 x 254 x 139
5351.4320.397.992 400 x 300 x 221 354 x 254 x 206
5351.4326.397.992 400 x 300 x 287 354 x 254 x 272
5351.6408.397.992 600 x 400 x 111 554 x 354 x 95
5351.6413.397.992 600 x 400 x 155 554 x 354 x 139
5351.6420.397.992 600 x 400 x 221 554 x 354 x 206
5351.6426.397.992 600 x 400 x 288 554 x 354 x 272
HANDLING AND STORAGE
• Flexible partitions for individual container division
• Thickness: 3 mm (solid material), volume conductive
Part Nr. Outer Dimensions
mm (W x D x H)
Division
5351.2610.003.992 258 x 100 x 3 mm 23 mm
5351.3610.003.992 358 x 100 x 3 mm 29 mm
5351.5610.003.992 558 x 100 x 3 mm 33 mm
5351.3620.003.992 358 x 200 x 3 mm 64 mm
5351.5620.003.992 558 x 200 x 3 mm 73 mm
WEZ BLACKLINE
®
– DIVIDERS
