115
2020/2021
IEC
EN
BRUSHES
DISSIPATIVE BRUSHES – NYLON
Part Nr. Size Description
6104.Y.103 12,5 mm Flat hard brush
6104.Y.104 19 mm Flat hard brush
6104.Y.105 25 mm Flat hard brush
6104.Y.106 38 mm Flat hard brush
6104.Y.107 50 mm Flat hard brush
6104.Y.200 3 mm Round hard brush
6104.Y.201 6 mm Round hard brush
6104.Y.9001 30 mm Hard brush
6104.Y.9002 60 mm Hard brush
6104.Y.4000 80 mm Hard brush
6104.Y.1200 17 mm Hard brush key ring
Our range of static dissipative brushes allows thorough cleaning of
ESD-sensitive assemblies without the danger of high charges gene-
rated by conventional brushes. The high resilient, permanent static
dissipative Nylon 6.12 bristles will allow a controlled static dissipation
to ground. Includes the ESD Symbol.
116
2020/2021
IEC
EN
BRUSHES
CONDUCTIVE BRUSHES – NATURAL BRISTLES
Part Nr. Size Description
6100.103 12,5 mm Flat hard brush
6100.104 19 mm Flat hard brush
6100.105 25 mm Flat hard brush
6100.106 38 mm Flat hard brush
6100.107 50 mm Flat hard brush
6100.200 3 mm Round hard brush
6100.201 6 mm Round hard brush
6100.9001 30 mm Hard brush
6100.9002 60 mm Hard brush
6100.1001 140 mm Flat soft brush
6100.4000 80 mm Hard brush
6100.1200 25 mm Soft brush
key ring
Our range of conductive brushes allows thorough cleaning of ESD
sensitive assemblies without the danger of high charges generated
by conventional brushes. They consist of a conductive plastic handle
and bristles made of highly conductive fibers which will dissipate any
charges by corona discharge, due to their small diameter. Natural hair
is mixed with the conductive fibers to provide the desired stiffness.
Includes the ESD Symbol.
117
IEC
EN
CONDUCTIVE BRUSHES – NYLON
Part Nr. Size Description
6103.B.103 12,5 mm Flat hard brush
6103.B.104 19 mm Flat hard brush
6103.B.105 25 mm Flat hard brush
6103.B.106 38 mm Flat hard brush
6103.B.107 50 mm Flat hard brush
6103.B.200 3 mm Round hard brush
6103.B.201 6 mm Round hard brush
6103.B.4000 80 mm Hard brush
6103.B.9001 30 mm Hard brush
6103.B.9002 60 mm Hard brush
In contrast to conventional brushes, when using this conductive
brush assortment, static charges on ESD sensitive PCBs can be
minimized. The durable, permanently conductive bristles made of
nylon 6.12 ensure a controlled charge dissipation.
BRUSHES
