HANDLING AND STORAGE
Width
Depth
Height
Depth
Width
Height
CAROUSEL STORAGE SYSTEM
• Galvanized steel
• Empty carousel for 12 storage racks 150/1200 series
• Dimension: 1760 x 470 x 470 mm
• Includes a grounding cord
Part Nr. Outer Dimensions
5380.LK.1 1760 x 470 x 470 mm
STORAGE RACKS
• Galvanized Steel
• Outer dimensions: 306 x 552 x 150 mm (W x H x D)
• Empty carousel for 12 storage racks
Part Nr. Content Inner Dimension
5380.LK.1.24 24 bins 85 x 55 x 135 mm (W x H X D)
5380.LK.1.48 48 bins 63 x 35 x 135 mm (W x H X D)
5380.LK.1.60 60 bins 50 x 35 x 135 mm (W x H X D)
Storage rack with 60 bins.
163
2020/2021
IEC
EN
HANDLING AND STORAGE
STORAGE BINS – CONDUCTIVE
• Permanent, carbon loaded, conductive Polypropylene
Part Nr. Outer Dim. (D x W x H) Inner Dim. (D x W x H) Stacked pcs per box rail suspension
5320.FA3Z 350 x 200 x 145 mm 280 x 182 x 127 mm 127 mm 12 X
5320.FA4 235 x 145 x 125 mm 180 x 127 x 108 mm 108 mm 25 X
5320.FA5 175 x 100 x 75 mm 129 x 87 x 67 mm 67 mm 42 X
5320.2 500 x 300 x 200 mm 425 x 280 x 183 mm 183 mm 6 –
5320.3 350 x 200 x 200 mm 280 x 182 x 185 mm 185 mm 8 –
5320.3Z 350 x 200 x 145 mm 280 x 182 x 127 mm 127 mm 12 –
5320.4 235 x 145 x 125 mm 180 x 127 x 108 mm 108 mm 27 X
5320.5 175 x 100 x 75 mm 129 x 87 x 67 mm 67 mm 40 X
5320.6 95 x 100 x 50 mm 60 x 87 x 44 mm 44 mm 50 X
5320.6D 95 x 100 x 50 mm 60 x (2 x 43) x 44 mm 44 mm 50 X
(5320.2 and 5320.3 include a handle).
application example
• with separator
Back with recessed grip, models with X
with additional rail suspension
Easy extraction due to rounded corners
Depth
Width
Height
164
2020/2021
IEC
EN
!
HANDLING AND STORAGE
IDP-STAT
®
STORAGE BINS – DISSIPATIVE
Other sizes and colours available on request!
• Permanent, static dissipative Polypropylene
• Made of Inherently Dissipative Polymer (IDP-STAT
®
)
• Stackable
• Colour: red, yellow
• With ESD Symbol, Recycling symbol and LOT-No.
Part Nr. Outer Dim. (D x W x H) Inner Dim. (D x W x H) Stacked pcs per box rail suspension
red
5321.R.3Z 350 x 200 x 145 mm 280 x 182 x 127 mm 127 mm 12 –
5321.R.4 235 x 145 x 125 mm 180 x 127 x 108 mm 108 mm 27 X
5321.R.5 175 x 100 x 75 mm 129 x 87 x 67 mm 67 mm 40 X
5321.R.6 95 x 100 x 50 mm 60 x 87 x 44 mm 44 mm 50 X
yellow
5321.Y.3Z 350 x 200 x 145 mm 280 x 182 x 127 mm 127 mm 12 –
5321.Y.4 235 x 145 x 125 mm 180 x 127 x 108 mm 108 mm 27 X
5321.Y.5 175 x 100 x 75 mm 129 x 87 x 67 mm 67 mm 40 X
5321.Y.6 95 x 100 x 50 mm 60 x 87 x 44 mm 44 mm 50 X
Labels for storage bins
Part Nr. for Part Nr. Dimensions Qty.
5320.2.ET 5320.2 82 x 42 mm 100 pcs
5320.3.ET 5320.3 79 x 43 mm 100 pcs
5320.3Z.ET 5320.3Z / 5321.R.3Z / 5321.Y.3Z 79 x 30 mm 100 pcs
5320.4.ET 5320.4 / 5321.R.4 / 5321.Y.4 80 x 29 mm 100 pcs
5320.5.ET 5320.5 / 5321.R.5 / 5321.Y.5 79 x 20 mm 100 pcs
5320.6.ET 5320.6 / 5321.R.6 / 5321.Y.6 79 x 13 mm 100 pcs
5320.FA2.3.ET 5320.FA2 / 5320.FA3 98 x 43 mm 100 pcs
5320.FA3Z.ET 5320.FA3Z 101 x 30 mm 100 pcs
5320.FA4.ET 5320.FA4 74 x 23 mm 100 pcs
5320.FA5.ET 5320.FA5 53 x 15 mm 100 pcs
