170 2020/2021 IEC EN IEC EN IEC EN IEC EN HANDLING AND STORAGE Part Nr . Outer Dimensions 5310.43 400 x 300 mm top cover 5310.64 600 x 400 mm top cover 5310.43.PU 400 x 300 mm lid with soft dissipative PU foam, pink Part…
169
2020/2021
IEC
EN
IEC
EN
!
IDP-STAT
®
TOTE BOXES
• Permanent, static dissipative Polypropylene
• Made of Inherently Dissipative Polymer (IDP-STAT
®
)
• Stackable
• Pallet modular size
• With ESD Symbol, Recycling symbol and LOT Nr.
• Closed grip
See also page 137/138 for foams
Other sizes available on request!
width
depth
height
HANDLING AND STORAGE
Part Nr. Outer Dimensions
mm (W x D x H)
Inner Dimensions
mm (W x D x H)
Stacked
red
5311.R.05 300 x 200 x 120 270 x 170 x 117 106
5311.R.10.L* 400 x 300 x 120 355 x 255 x 115 104
5311.R.14 400 x 300 x 170 355 x 255 x 165 152
5311.R.20.L* 400 x 300 x 220 355 x 255 x 217 204
5311.R.31 400 x 300 x 320 355 x 255 x 317 304
5311.R.24 600 x 400 x 120 555 x 355 x 115 104
5311.R.34 600 x 400 x 170 555 x 355 x 165 152
5311.R.42 600 x 400 x 220 555 x 355 x 215 204
* Light-Version
Part Nr. Outer Dimensions
mm (W x D x H)
Inner Dimensions
mm (W x D x H)
Stacked
yellow
5311.Y.05 300 x 200 x 120 270 x 170 x 117 106
5311.Y.10.L* 400 x 300 x 120 355 x 255 x 115 104
5311.Y.14 400 x 300 x 170 355 x 255 x 165 152
5311.Y.20.L* 400 x 300 x 220 355 x 255 x 217 204
5311.Y.31 400 x 300 x 320 355 x 255 x 317 304
5311.Y.24 600 x 400 x 120 555 x 355 x 115 104
5311.Y.34 600 x 400 x 170 555 x 355 x 165 152
5311.Y.42 600 x 400 x 220 555 x 355 x 215 204
* Light-Version
COLLAPSIBLE BOXES AND TOP COVER
• Permanent, carbon loaded, conductive Polypropylene
• Foldable
• Side walls closed
• Height folded: about 70 mm
• 68 % space saving when folded
• With ESD Symbol
Part Nr. Outer Dim. (W x D x H) Inner Dim. (W x D x H)
Collapsible Boxes
5300.FB.L 600 x 400 x 220 mm 570 x 370 x 210 mm
5300.FB.S 400 x 300 x 220 mm 370 x 270 x 210 mm
Top cover Description
5310.43.A 400 x 300 mm
5300.FB.64.N
600 x 400 mm with 3 strapping grooves
170
2020/2021
IEC
EN
IEC
EN
IEC
EN
IEC
EN
HANDLING AND STORAGE
Part Nr. Outer Dimensions
5310.43 400 x 300 mm top cover
5310.64 600 x 400 mm top cover
5310.43.PU 400 x 300 mm lid
with soft dissipative PU foam, pink
Part Nr. 4930.1.43
5310.64.PU 600 x 400 mm lid
with soft dissipative PU foam, pink
Part Nr. 4930.1.64
5310.43.PU.S 400 x 300 mm lid
with soft conductive PU foam, black
Part Nr. 4470.1.43
5310.64.PU.S 600 x 400 mm lid
with soft conductive PU foam, black
Part Nr. 4470.1.64
TOP COVER IDP-STAT
®
TOP COVER
• Made of Inherently Dissipative Polymer (IDP-STAT
®
)
Part Nr. Outer Dimensions Colour
5311.Y.43 400 x 300 mm top cover yellow
5311.Y.64 600 x 400 mm top cover yellow
5311.R.43 400 x 300 mm top cover red
5311.R.64 600 x 400 mm top cover red
HINGED LID
hinge
Part Nr. Outer Dimensions
5310.32.A 300 x 200 mm
5310.43.A 400 x 300 mm
5310.64.A 600 x 400 mm
TOP COVER
Part Nr. Outer Dimensions Colour
5310.32.S 300 x 200 mm top cover black
5311.R.32.S 300 x 200 mm top cover red
5311.Y.32.S 300 x 200 mm top cover yellow
5310.43.S 400 x 300 mm top cover black
171
2020/2021
HANDLING AND STORAGE
TOTE BOXES ACCESSORIES
Part Nr. Accessories Type
5310.99.2 Label clamp stainless steel
5310.99.3 Lliding lock, conductive PP, black, conductive
5310.99.1 Snap lock PP, white
5221.4.IDP.250 Label holder IDP-STAT
®
PVC transparent, self-adhesive backing (118 x 80 x 0,25 mm), Qty 10 pcs
front and back made of IDP-STAT
®
fi l m
5221.5.IDP.250.N Label holder IDP-STAT
®
PVC transparent, self-adhesive backing (118 x 74 x 0,25 mm), Qty 10 pcs
front made of IDP-STAT
®
fi lm, back made of insulating fi lm
5221.IDP.700 Document holder IDP-STAT
®
PVC for hanging onto tote boxes
DIN A5, 158 x 210 x 0,7 mm, folded top side 22 mm, Qty 5 pcs
3015.203.075.IDP Holder for KANBAN system IDP-STAT
®
PVC, transparent, (203 x 75 x 0,25 mm), 1 open side, Qty 25 pcs
label holder
application examples
application examples
holder for KANBAN
system
BANDS FOR IC-TUBES
• Dissipative velcro band for IC tubes
Part Nr. Dimension Qty.
3410.710 710 mm length 25 pcs
