172 2020/2021 HANDLING AND STORAGE TOTE BOXES DIVIDERS FOR PCB´S sample applications • Permament volume conductive Polypropylene • For standard tote boxes: 600 x 400 mm • Honeycomb profile • Material thickness: 3 mm • Ma…
171
2020/2021
HANDLING AND STORAGE
TOTE BOXES ACCESSORIES
Part Nr. Accessories Type
5310.99.2 Label clamp stainless steel
5310.99.3 Lliding lock, conductive PP, black, conductive
5310.99.1 Snap lock PP, white
5221.4.IDP.250 Label holder IDP-STAT
®
PVC transparent, self-adhesive backing (118 x 80 x 0,25 mm), Qty 10 pcs
front and back made of IDP-STAT
®
fi l m
5221.5.IDP.250.N Label holder IDP-STAT
®
PVC transparent, self-adhesive backing (118 x 74 x 0,25 mm), Qty 10 pcs
front made of IDP-STAT
®
fi lm, back made of insulating fi lm
5221.IDP.700 Document holder IDP-STAT
®
PVC for hanging onto tote boxes
DIN A5, 158 x 210 x 0,7 mm, folded top side 22 mm, Qty 5 pcs
3015.203.075.IDP Holder for KANBAN system IDP-STAT
®
PVC, transparent, (203 x 75 x 0,25 mm), 1 open side, Qty 25 pcs
label holder
application examples
application examples
holder for KANBAN
system
BANDS FOR IC-TUBES
• Dissipative velcro band for IC tubes
Part Nr. Dimension Qty.
3410.710 710 mm length 25 pcs
172
2020/2021
HANDLING AND STORAGE
TOTE BOXES DIVIDERS FOR PCB´S
sample applications
• Permament volume conductive Polypropylene
• For standard tote boxes:
600 x 400 mm
• Honeycomb profile
• Material thickness: 3 mm
• Material weight: 550 g/m²
• High abrasion resistance
• Variable storage system
Standard dividers for tote boxes 600 x 400 x ... mm
Partition sizes: 553 x 353 x 80/120/180 mm (L x W x H)
Cell size: 23 x 20 mm
Rows / max.: 20 x 14 = 280 cells
The individual cell sizes can be modified by removing short and long dividers
Part Nr. Size (L x W x H) Slots
Long dividers for different 600 x 400 mm tote boxes confi guration
5420.553.23.80 553 x 80 x 3 mm 21
5420.553.23.120 553 x 120 x 3 mm 21
5420.553.23.180 553 x 180 x 3 mm 21
Short dividers for different 600 x 400 mm tote boxes confi guration
5420.353.20.80 353 x 80 x 3 mm 15
5420.353.20.120 353 x 120 x 3 mm 15
5420.353.20.180 353 x 180 x 3 mm 15
Custom-made dividers on request
5420.Z.G Customized
Part Nr. Set includes Dimensions
Sets
5420.G1.80 Height: 80 mm
Long divider: 15 (Part Nr.: 5420.553.23.80)
Short divider: 21 (Part Nr.: 5420.353.20.80)
553 x 80 x 3 mm
353 x 80 x 3 mm
5420.G1.120 Height: 120 mm
Long divider: 15 (Part Nr.: 5420.553.23.120)
Short divider: 21 (Part Nr.: 5420.353.20.120)
553 x 120 x 3 mm
353 x 120 x 3 mm
5420.G1.180 Height: 180 mm
Long divider: 15 (Part Nr.: 5420.553.23.180)
Short divider: 21 (Part Nr.: 5420.353.20.180)
553 x 180 x 3 mm
353 x 180 x 3 mm
173
2020/2021
HANDLING AND STORAGE
TOTE BOXES DIVIDERS FOR PCB´S
Sample
• Permament volume conductive Polypropylene
• For standard tote boxes:
400 x 300 mm
• Honeycomb profile
• Material thickness: 3 mm
• Material weight: 550 g/m²
• High abrasion resistance
• Variable storage system
Standard dividers for tote boxes 400 x 300 x ... mm
Partition sizes: 353 x 253 x 80 /120 / 180 mm (L x W x H)
Cell size: 20 x 20 mm
Rows / max.: 10 x 14 = 140 cells
The individual cell sizes can be modified by removing short and long dividers
Part Nr. Size (L x W x H) Slots
Long dividers for different 400 x 300 mm tote boxes confi guration
5420.353.20.80 353 x 80 x 3 mm 15
5420.353.20.120 353 x 120 x 3 mm 15
5420.353.20.180 353 x 180 x 3 mm 15
Short dividers for different 400x x 300 mm tote boxes confi guration
5420.253.20.80 253 x 80 x 3 mm 11
5420.253.20.120 253 x 120 x 3 mm 11
5420.253.20.180 253 x 180 x 3 mm 11
Custom-made dividers on request
5420.Z.G Customized
Part Nr. Set includes Dimensions
Sets
5420.G2.80 Height: 80 mm
Long divider: 11 (Part Nr.: 5420.353.20.80)
Short divider: 15 (Part Nr.: 5420.253.20.80)
353 x 80 x 3 mm
253 x 80 x 3 mm
5420.G2.120 Height: 120 mm
Long divider: 11 (Part Nr.: 5420.353.20.120)
Short divider: 15 (Part Nr.: 5420.253.20.120)
353 x 120 x 3 mm
253 x 120 x 3 mm
5420.G2.180 Height: 180 mm
Long divider: 11 (Part Nr.: 5420.353.20.180)
Short divider: 15 (Part Nr.: 5420.253.20.180)
353 x 180 x 3 mm
253 x 180 x 3 mm
sample applications
