Wolfgang-Warmbier-Katalog-2020-2021-en.pdf - 第12页

12 2020/2021 IEC EN 1806.HG 1806.RB 1806.AZ ! ECOST A T ® FLOORING ECOST A T ® -DF CENTRA-NV Hard-wearing Polyamide flooring material on r olls, specially designed for the electronic industry . Constant electrostatic dis…

2020/2021

IEC

1305.7004

ECOSTAT

FLOORING

ECOSTAT

-DF PR-2.0

WELDING ROD

Adhesive see page 15

Quick-Lift adhesive

tape see page 15

ACCESSORIES

Part Nr. Size Colour

1300.7004 4 mm x 100 m / Roll ca. RAL 7004

High performance PVC flooring material on rolls, specially designed for the electronic industry. Constant electrostatic discharge capability under

use of suitable conductive adhesives.

• Material: PVC single-layered

• Thickness: 2 mm

• Conductive backing

• Electrostatic dissipative flooring

• Insulation resistance for personnel safety acc. to DIN VDE 0100-410

• Satin mat surface with long-term sealing

• Easy maintenance

• High abrasion resistance

• Suitable for forklift traffic when used fiber-reinforced adhesive,

recommendation: Wulff Supra-Strong LF

• Available on rolls

Part Nr. Standard Sizes Colour

1305.7004 2,0 m x 20 m Grey, ca. RAL 7004

Installation in

double-cut

technique

conductive

backing

Instructions for use

2020/2021

IEC

1806.HG 1806.RB 1806.AZ

ECOSTAT

FLOORING

ECOSTAT

-DF CENTRA-NV

Hard-wearing Polyamide flooring material on rolls, specially designed for the electronic industry.

Constant electrostatic dissipative properties, using a special conductive glue, Thomsit T412 and a conductive finish, Thomsit R762.

• Electrostatic dissipative Polyamide flooring

• Easy maintenance

• 100 % Polyamide with conductive fiber

• High abrasion resistance

• Available on rolls

Other colours on request!

Part Nr. Sizes Colour

1806.HG 2,0 m x 25 - 35 m Light grey

1806.RB 2,0 m x 25 - 35 m Royal blue

1806.AZ 2,0 m x 25 - 35 m Anthracite

CONDUCTIVE FINISH AND ADHESIVE

FOR CENTRA NV

Conductive glue

For Ecostat

-DF CENTRA-NV Polyamide

Consumption: app. 450 g/m

Part Nr. Pail

1280.T412 14 kg

Conductive finish

Alternative to copper band

Consumption: app. 150 g/m

Part Nr. Pail

1280.R762 10 kg

Instructions for use

Grounding box

see page 76

Aluminium tape

see page 144

ACCESSORIES

2020/2021

IEC

1310.PF.701 .R

1310.PF.701 .RES

ECOSTAT

SELF-LAYING FLOORING

ECOSTAT

-CF PUZZLE 8.5

INTERLOCKING SYSTEM

Tip: Laying with soft-head hammer

Interlocking system

Flooring material for „do it yourself“ floor laying

• Two layer material

• Volume conductive

• Abrasion resistant

• Conductive, elastic backing

• Backing with waffle structure for installation

on problematic substrates (e.g. residual moisture)

• Suitable for chair castors

• Suitable for forklift traffic

• Reusable

• Self-laying (without glue)

• Easy handling using tools for woodwork

• Colour: grey

Part Nr. Standard Size Quantity

Puzzle tile

1310.PF.701 469 x 469 x 8,5 mm 12 pieces

(2,64 sqm)

1310.PF.ESD 469 x 469 x 8,5 mm

with ESD symbol

1 piece

Transition (optional) – self-adhesive

1310.PF.701 .R 1220 x 65 mm 1 piece

Corner (optional) – self-adhesive

1310.PF.701 .RES 711 x 65 mm 2 pieces

conductive

backing

Instructions for use
