SMALL COMPONENTS BOXES
HINGED UTILITY BOXES
CARBON
• Permanent, carbon loaded, conductive material
• Include a dissipative PE foam insert (Typ 4550.*)
• Lid printed with ESD symbol
Part Nr. Sizes Foam thickness Quantity
5100.860 55 x 38 x 14 mm 6 mm 100 pcs
5100.861 70 x 45 x 14 mm 8 mm 100 pcs
5100.862 130 x 32 x 14 mm 8 mm 100 pcs
5100.864 77 x 55 x 12 mm 6 mm 100 pcs
5100.865 117 x 90 x 21 mm 14 mm 50 pcs
5100.866 138 x 44 x 14 mm 8 mm 100 pcs
application example
Boxes with soft conductive foam
available on request.
158
2020/2021
IEC
EN
IEC
EN
IEC
EN
5351.1308.014
5351.1308.030 5351.1308.050
5351.1814.080
5351.2212.060
• Black with transparent metallized lid
• Permanent carbon loaded conductive
• Tray compatible size combination
• Spring loaded lid
• Suitable for compartmented box Part Nr. 5150.810
(see page 161)
Part Nr. Inner sizes Quantity
5100.880 16 x 12 x 15 mm small 100 pcs
5100.881 37 x 12 x 15 mm medium 50 pcs
5100.882 40 x 37 x 15 mm big 25 pcs
5100.883 68 x 57 x 15 mm big 10 pcs
• Permanent carbon loaded conductive
• Tray compatible size combination
• Spring loaded lid
• Suitable for compartmented box Part Nr. 5150.810
(see page 161)
Part Nr. Inner sizes Quantity
5100.873 16 x 12 x 15 mm small 100 pcs
5100.874 37 x 12 x 15 mm medium 50 pcs
5100.875 40 x 37 x 15 mm big 25 pcs
5100.876 68 x 57 x 15 mm big 10 pcs
SMD BOXES
CARBON
SMD BOXES
CARBON
SMALL COMPONENTS BOXES
HINGED LID BOXES
CARBON
• Permanent carbon loaded conductive
• Cover and box in one piece
• Hinge and snap closure
Part Nr. Inner sizes
5351.1308.014 130 x 80 x 14 mm
5351.1308.030 130 x 80 x 30 mm
5351.1308.050 130 x 80 x 50 mm
5351.1814.080 178 x 133 x 78 mm
5351.2212.060 221 x 121 x 55 mm
159
2020/2021
IEC
EN
IEC
EN
IEC
EN
5150.381.F02
5150.381.F12
5150.381.F17
5150.381
5150.381.F20
5150.380
5150.380.F09
5150.380.F15 5150.380.F24
5150.367
5150.367.F54
5150.367.F72
5150.381.F20
5150.381.F17
5150.381
5150.380
5150.380.F24
5150.367
5150.367.F54
5150.367.F72
5150.380.F15
SMALL COMPONENTS BOXES
HINGED LID BOXES
CARBON
HINGED LID BOXES
CARBON
• Permanent carbon loaded conductive
• Hinged lid with snap closure
Part Nr. Inner sizes
5150.380 185 x 108 x 10 mm
Box compartment layout
Part Nr. Inner sizes Compartments
5150.380.F09 59 x 33 mm 9
5150.380.F15 35 x 33 mm 15
5150.380.F24 28 x 24 mm 24
HINGED LID BOXES
CARBON
• Permanent carbon loaded conductive
• Hinged lid with snap closure
Part Nr. Inner sizes
5150.381 185 x 108 x 29 mm
Box compartment layout
Part Nr. Inner sizes Compartments
5150.381.F02 93 x 81 mm 2
5150.381.F12 45 x 25 mm 12
5150.381.F17 20 x 30 / 80 x 30 mm 16 + 1
5150.381.F20 20 x 30 mm 20
• Permanent carbon loaded conductive
• Hinged lid with slide closure
Part Nr. Inner sizes
5150.367 295 x 164 x 16 mm
Box compartment layout
Part Nr. Inner sizes Compartments
5150.367.F54 28 x 23 mm 54
5150.367.F72 20 x 22 mm 72
