6 2020/2021 ESD PROTECTED AREA (EP A) Marking of an Electrostatic Protected Area (EP A) Personnel Grounding T ester for testing „wrist strap grounding sys- tem“ and “Person…
5
2020/2021
IEC
EN
Since 1998 the company Wolfgang Warmbier
maintains a Quality Control System certifi ed by
the DQS GmbH.
QUALITY CONTROL SYSTEM
Recommended international standards:
IEC 61340-5-1
Electrostatics – Part 5-1: Protection of electronic devices from electrostatic phenomena
– General requirements –
IEC/TR 61340-5-2
Electrostatics – Part 5-2:
Protection of electronic devices from electrostatic phenomena
– User guide –
IEC 61340-5-3
Electrostatics – Part 5-3
Protection of electronic devices from electrostatic phenomena –
Properties and requirements classification for packaging intended for
discharge electrostatic sensitive devices
symbols used throughout this catalogue to define products in compliance with
IEC 61340-5-1 / IEC 61340-5-3.
All PERMASTAT
®
products are intended only for ESD protection in industrial electronic production.
For the latest information about all ESD standards see www.warmbier.com/esd-standards
ABOUT ESD
ABOUT ESD, QUALITY CONTROL SYSTEM
Scope:
Consulting, manufacturing and supply
of static control material and systems,
calibration of ESD test instruments.
Further informations
about standards
Download certificates
6
2020/2021
ESD PROTECTED AREA (EPA)
Marking of an Electrostatic Protected Area (EPA)
Personnel Grounding Tester for testing „wrist strap grounding sys-
tem“ and “Person footwear system”
Conductive or dissipative flooring system for personnel grounding
over “Person footwear system”, grounding of ESD chairs, ESD
transport carts etc.
ESD shoes, heel grounder or toe grounder for „Personnel Groun-
ding“
Wrist strap system for grounding of personnel in seating position
ESD garments are shielding the electrostatic fields of the normal
clothing
ESD chairs minimize the chargeability of personnel when getting up
and additionally ground a person when sitting down
ESD Workstation with dissipative bench top and dissipative shelves
Galvanized steel shelving system will secure, when grounded
properly, the dissipation of charges from conductive or dissipative
transport systems and packaging
Utility Cart with 4 conductive castors
ESD packaging (conductive, dissipative and/or ESD
shielding) is needed for a proper transport of electronic compo-
nents and boards within and outside an EPA.
Storage racks are used to store ESDS (Electrostatic Sensitive
Devices)
Ionisers can neutralise electrostatic charges on process relevant
isolators
ESD safe office equipment like ring binders and lighting magnifiers
prevent the danger of electrostatic fields at workstations
Test and measurement equipment is used for verification of
all the different ESD items within an EPA
ESD protected area (sample configuration)
ESD PROTECTED AREA (EPA)
EPA-Video
7
2020/2021
TRAINING AND CUSTOMER SERVICES
TRAINING
• Consulting, planning of ESD protected areas
• ESD Audits
• ESD training
• ESD workshops
Training Center
Showroom
Laboratory
We offer ESD training on-site and also at our own
Warmbier Training Center.
See dates and registration form on our website:
www.warmbier.com
CUSTOMER SERVICES
ESD training dates
