SPN11 – IONIZING NOZZLE
sample application
AIR IONIZERS
• Quickly neutralizes static charges in machines
• High frequency, AC ionisation (HF-AC)
• Compact Piezoceramic high voltage transformer
• Power supply 24V DC / 100-240V AC with wall mounting transformer
• Emitter points: tungsten
• Easy maintenance
• Compact size
• Self balancing ± 15V
• Ozone generation < 0,001 ppm, measured 15 cm in front of the unit
• Red LED high voltage failure alarm
• Different stainless steel available
• Alarm output
Size: 2,9 cm x 6,8 cm x 7,7 cm (W x H x D)
Includes: SPN-11, power supply 230V AC / 24V DC
Part Nr.
7520.HF.SPN11 Ionizing Nozzle SPN11
7520.HF.SPN11.S Ionizing Nozzle SPN11 with proximity sensor
Optional Length Air holes Pitch
7520.HF.SPN11.B1 Nozzle/Tube
Material: stainless steel, Cleanroom compatible
267,5 mm 42 10 mm
7520.HF.SPN11.B2 Nozzle/Tube
Material: stainless steel, Cleanroom compatible
217,5 mm 16 10 mm
7520.HF.SPN11.B3 Nozzle/Tube
Material: stainless steel, Cleanroom compatible
217,5 mm 31 5 mm
7520.HF.SPN11.B4 Nozzle/Tube
Material: stainless steel, Cleanroom compatible
367,5 mm 31 10 mm
7520.HF.SPN11.E ELBOW Coupling
90˚ angle, Material: stainless steel, Cleanroom compatible
58 mm
7520.HF.SPN11.T Tube air nozzle (4mm), for 6 mm hose
7520.HF.SPN11.D1 90˚ nozzle
(with proximity sensor)
115
2020/2021
IEC
EN
BRUSHES
DISSIPATIVE BRUSHES – NYLON
Part Nr. Size Description
6104.Y.103 12,5 mm Flat hard brush
6104.Y.104 19 mm Flat hard brush
6104.Y.105 25 mm Flat hard brush
6104.Y.106 38 mm Flat hard brush
6104.Y.107 50 mm Flat hard brush
6104.Y.200 3 mm Round hard brush
6104.Y.201 6 mm Round hard brush
6104.Y.9001 30 mm Hard brush
6104.Y.9002 60 mm Hard brush
6104.Y.4000 80 mm Hard brush
6104.Y.1200 17 mm Hard brush key ring
Our range of static dissipative brushes allows thorough cleaning of
ESD-sensitive assemblies without the danger of high charges gene-
rated by conventional brushes. The high resilient, permanent static
dissipative Nylon 6.12 bristles will allow a controlled static dissipation
to ground. Includes the ESD Symbol.
116
2020/2021
IEC
EN
BRUSHES
CONDUCTIVE BRUSHES – NATURAL BRISTLES
Part Nr. Size Description
6100.103 12,5 mm Flat hard brush
6100.104 19 mm Flat hard brush
6100.105 25 mm Flat hard brush
6100.106 38 mm Flat hard brush
6100.107 50 mm Flat hard brush
6100.200 3 mm Round hard brush
6100.201 6 mm Round hard brush
6100.9001 30 mm Hard brush
6100.9002 60 mm Hard brush
6100.1001 140 mm Flat soft brush
6100.4000 80 mm Hard brush
6100.1200 25 mm Soft brush
key ring
Our range of conductive brushes allows thorough cleaning of ESD
sensitive assemblies without the danger of high charges generated
by conventional brushes. They consist of a conductive plastic handle
and bristles made of highly conductive fibers which will dissipate any
charges by corona discharge, due to their small diameter. Natural hair
is mixed with the conductive fibers to provide the desired stiffness.
Includes the ESD Symbol.
