IEC

SHIELDING SHIPPING BOXES

SAFESHIELD

SHIPPING BOXES

• High shielding performance due to highly conductive inner layer

• Inner and outer permanent static dissipative layers

• Good mechanical properties

• Recyclable

• Reusable

• Non-corrosive

• No heavy metals

• Colour: Blue

• Print: ESD and Resy symbols, warning note in German and English

• UV resistant

The Safeshield shipping cardboard boxes provide a high protection against electrostatic discharge and against electrostatic

fields. They are ideal for packing, stocking and shipping ESD sensitive components (ESDS).

Energy test with Safeshield

shipping boxes

according to HBM test me-

thod with 1.000 V

Energy test without

shielding.

• Rugged construction

• Safe transport stacking design

• Closed handholds, with print, delivered flat

Cover:

• Finish with 4-point-gluing

Part Nr. Outer Dim. mm

(D x W x H)

Inner Dim. mm

(D x W x H)

Stacking Box

5510.SB.400.A 385 x 275 x 105 mm 360 x 250 x 100 mm

5510.SB.400.B 385 x 275 x 215 mm 360 x 250 x 210 mm

5510.SB.600.A 575 x 385 x 105 mm 550 x 360 x 100 mm

5510.SB.600.B 575 x 385 x 215 mm 550 x 360 x 210 mm

Cover

5510.SB.43 390 x 280 x 40 mm

5510.SB.64 580 x 390 x 40 mm

SAFESHIELD

STACKING BOX

134

2020/2021

SHIELDING SHIPPING BOXES

SAFESHIELD

SHIPPING BOXES – DELIVERED FLAT

SAFESHIELD

SHIPPING BOXES – DELIVERED FLAT

SAFESHIELD

SHIPPING BOXES – DELIVERED FLAT

SAFESHIELD

SHIPPING BOXES – DELIVERED FLAT

Part Nr. Inner sizes Quantity

5510.903 183 x 127 x 38 mm 100 pcs

Foam inserts for Part Nr. 5510.903

Part Nr. Sizes Proﬁ le Quantity

4903.0.15 178 x 127 x 15 mm ﬂ at 100 pcs

4903.0.20 178 x 127 x 20 mm ﬂ at 100 pcs

4903.1.15 178 x 127 x 15 mm proﬁ le 1:1 100 pcs

4903.1.20 178 x 127 x 20 mm proﬁ le 1:1 100 pcs

• Please order foam inserts separately

• FEFCO-Code 0427

• Please order foam inserts separately

• FEFCO-Code 0427

• Please order foam inserts separately

• FEFCO-Code 0427

• Please order foam inserts separately

• FEFCO-Code 0427

Part Nr. Inner sizes Quantity

5510.904 250 x 191 x 38 mm 100 pcs

Foam inserts for Part Nr. 5510.904

Part Nr. Sizes Proﬁ le Quantity

4904.0.15 250 x 191 x 15 mm ﬂ at 100 pcs

4904.0.20 250 x 191 x 20 mm ﬂ at 100 pcs

4904.1.20 250 x 191 x 20 mm proﬁ le 1:1 100 pcs

Part Nr. Inner sizes Quantity

5510.905 250 x 191 x 64 mm 100 pcs

Foam inserts for Part Nr. 5510.905

Part Nr. Sizes Proﬁ le Quantity

4904.0.15 250 x 191 x 15 mm ﬂ at 100 pcs

4904.0.20 250 x 191 x 20 mm ﬂ at 100 pcs

4904.1.20 250 x 191 x 20 mm proﬁ le 1:1 100 pcs

Part Nr. Inner sizes Quantity

5510.906 267 x 216 x 64 mm 100 pcs

Foam inserts for Part Nr. 5510.906

Part Nr. Sizes Proﬁ le Quantity

4906.0.20 267 x 216 x 20 mm ﬂ at 100 pcs

4906.1.30 267 x 216 x 30 mm proﬁ le 1:1 100 pcs

135

2020/2021

SHIELDING SHIPPING BOXES

SAFESHIELD

SHIPPING BOXES – DELIVERED FLAT

SAFESHIELD

SHIPPING BOXES – DELIVERED FLAT

• Please order foam inserts separately

• FEFCO-Code 0427

• Please order foam inserts separately

• FEFCO-Code 0427

Part Nr. Inner sizes Quantity

5510.910 420 x 220 x 40 mm 100 pcs

Foam inserts for Part Nr. 5510.910

Part Nr. Sizes Proﬁ le Quantity

4910.0.15 420 x 220 x 15 mm ﬂ at 100 pcs

4910.1.20 420 x 220 x 20 mm proﬁ le 1:1 100 pcs

Part Nr. Inner sizes Quantity

5510.911 400 x 300 x 65 mm 100 pcs

Foam inserts for Part Nr. 5510.911

Part Nr. Sizes Proﬁ le Quantity

4911.0.20 400 x 300 x 20 mm ﬂ at 80 pcs

4911.1.30 400 x 300 x 30 mm proﬁ le 1:1 50 pcs

SAFESHIELD

SHIPPING BOXES – DELIVERED FLAT

• open, delivered flat without foam

• FEFCO-Code 0427

• PU foam: Profile 1:1

Part Nr. Inner sizes Quantity compatible

foam inserts

5510.912 250 x 191 x 110 mm 100 pcs 4904.1.20

5510.913 300 x 300 x 100 mm 100 pcs 4913.1.20

5510.914 330 x 180 x 70 mm 100 pcs 4914.1.20

5510.915 380 x 320 x 60 mm 100 pcs 4915.1.20

5510.916 393 x 300 x 90 mm 100 pcs 4916.1.20

5510.917 420 x 220 x 65 mm 100 pcs 4910.1.20

5510.918 490 x 460 x 80 mm 100 pcs 4918.1.20

SAFESHIELD

SHIPPING BOXES – DELIVERED FLAT

• open, delivered flat

• FEFCO-Code 0423

Part Nr. Inner sizes Quantity

5510.095 630 x 95 x 95 mm 100 pcs

5510.195 630 x 195 x 95 mm 100 pcs
