6 − 92
■
■■
■ When the system performs the continuous production and starts production after
re-clamping a board
Information on the
PWB transport path
obtained when
production was
interrupted
Whether there is a board
on the PWB transport
path
Image of the PWB transport condition
Step
No.
Whether to
resume
production
Production
operation
Left Right Left Right Left Right
Operation after you press
the <START> key
①
Yes
Yes
After a board is clamped again, the
system resumes the production
without loading a board before
starting production
②
Yes
None
Error
③
None
Yes
Error
④
None
None
Not selectable
⑤
Yes Yes
No
information
No
information
After re-clamping a board, the
system performs the continuous
production without loading any
board (Be careful).
⑥
Yes
Yes
Error
⑦
Yes
None
After a board is clamped again, the
system resumes the production
without loading a board before
starting production
⑧
None
Yes
Error
⑨
None
None
Not selectable
⑩
Yes None
No
information
No
information
After re-clamping a board, the
system performs the continuous
production without loading any
board (Be careful).
⑪
Yes
Yes
Error
⑫
Yes
None
Error
⑬
None
Yes
After a board is clamped again, the
system resumes the production
without loading a board before
starting production
⑭
None
None
Not selectable
⑮
None Yes
No
information
No
information
After re-clamping a board, the
system performs the continuous
production without loading any
board (Be careful).
⑯
Yes
Yes
⑰
Yes
None
⑱
None
Yes
Error (No board)
⑲
None
None
Not selectable
⑳
Yes
Production
after a
board is
clamped
(when you
select
“Re-clamp
current
PWB”)
None None
No
information
No
information
Error (No board)
6 − 93
■
■■
■
When the system starts production after re-clamp current PWB without performing the
continuous production
Information on the
PWB transport path
obtained when
production was
interrupted
Whether there is a board
on the PWB transport
path
Image of the PWB transport condition
Step
No.
Whether to
resume
production
Production
operation
Left Right Left Right Left Right
Operation after you press
the <START> key
①
Yes
Yes
②
Yes
None
③
None
Yes
Not selectable
However, this type of production is
selectable when the system
resumes the suspended production.
In this case, the system operates in
the same manner as it does when
there is no PWB transport path
information as described below.
④
None
None
⑤
Yes Yes
No
information
No
information
After re-clamping a board, the
system performs the continuous
production without loading any
board (Be careful).
⑥
Yes
Yes
⑦
Yes
None
⑧
None
Yes
Not selectable
However, this type of production is
selectable when the system
resumes the suspended production.
In this case, the system operates in
the same manner as it does when
there is no PWB transport path
information as described below.
⑨
None
None
⑩
Yes None
No
information
No
information
After re-clamping a board, the
system performs the continuous
production without loading any
board (Be careful).
⑪
Yes
Yes
⑫
Yes
None
⑬
None
Yes
Not selectable
However, this type of production is
selectable when the system
resumes the suspended production.
In this case, the system operates in
the same manner as it does when
there is no PWB transport path
information as described below.
⑭
None
None
⑮
None Yes
No
information
No
information
After re-clamping a board, the
system performs the continuous
production without loading any
board (Be careful).
⑯
Yes
Yes
⑰
Yes
None
⑱
None
Yes
Not selectable
However, this type of production is
selectable when the system
resumes the suspended production.
In this case, the system operates in
the same manner as it does when
there is no PWB transport path
information as described below.
⑲
None
None
⑳
No
Production
after a
board is
clamped
(when you
select
“Re-clamp
current
PWB”)
None None
No
information
No
information
Error (No board)
6 − 94
(2) If a board is located on the PWB transport path when you select “Load a new PWB”,
and the system ejects it
◇
If you have interrupted production (regardless of whether the system is to use a
continuous production file)
①
If both of the stations have just finished producing PWBs in Simultaneous
Production mode and boards are located on both of the stations
IN station (a PWB has been produced) OUT station (a PWB has been produced)
↓
IN station ( a board can be ejected.) OUT station ( a board can be ejected.)
• The system moves boards located on both of the stations to the next
processes respectively.
②
Immediately after only the IN station is used to produce a PWB (after only the IN
station is used for production or the IN station is used for production in Sequential
and Mix mode)
IN station (a PWB has been produced) OUT station (no board)
↓
IN station ( a board can be ejected.) OUT station (no board)
• The system moves a board on the IN station to the next process.
③
Immediately after only the OUT station is used to produce a PWB (after only the
OUT station is used for production or the OUT station is used for production in
Sequential and Mix mode, or after a board loading time-out error occurs in
Simultaneous Production mode and so only the OUT station is used for
production)
IN station (no board) OUT station (a PWB has been produced)
↓
IN station (no board) OUT station ( a board can be ejected.)
• The system moves a board on the OUT station to the next process.
