2.17 Lubricating the Cam Lever Air Cylinder Procedure 1. Open the lid of the lubricator with a Phillips driver. 2. Lower the lubricator cover. 3. Visually check the oil level of the oil tank and slowly pour in the oil to…
12. Slowly pour the new lubricating oil into the inlet on the top of the oil cooler.
13. Ensure that the surface of the oil is in the range specified by the level indicator.
Note: Whether the machine is at rest or during operation, the oil level does not normally
change. Immediately after replacing the oil after 3 years or 12,000 hours of
operation, the oil level will drop when operating the machine. Following operation,
add more oil until the level falls within the recommended range.
<CP-732E> <CP-742E><CP-742ME>
C7SM3101
Oil range
Oil cooler
Gauge glass
Level indicator
Cap
Oil inlet
(50)
Part 3 Chapter 2 Lubrication
Edition 2.9 3-2-25 CP-7 series Mechanical Reference
2.17 Lubricating the Cam Lever Air Cylinder
Procedure
1. Open the lid of the lubricator with a Phillips driver.
2. Lower the lubricator cover.
3. Visually check the oil level of the oil tank and slowly pour in the oil to the
lubricator. Be sure not to exceed the upper limit while pouring in the oil.
Note The maximum amount of oil that can be supplied to the lubricator is 75 cc. If the oil
level does not reach the tip of the pipe inside the case, there will be insufficient oil to
lubricate the cylinder.
4. Replace the lubricator cover and attach the oil inlet cap.
5. Check and discard of any accumulated waste oil in the collection bottle.
Cam lever air cylinder
A
A
(52)
B
B
Upper limit
Case
Pipe
Cover
Bottle
Lubricator
Lid
Lower limit
C7SM3084a
Turbine oil + NASKALUBE (*) Every 6 months
T017Eb
Lubrication points
Schedule
Types of lubricant
52
Air cylinder
(*) The lubrication used is a Fuji special blend (Turbine oil + NASKALUBE).
Contact Fuji when placing an order.
Part 3 Chapter 2 Lubrication
Edition 2.9 3-2-26 CP-7 series Mechanical Reference
Lubrication Checklist
T010Ec
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Daphne Exponex No. 2
Multemp LRL3
Daphne Super Multi Oil 32
Daphne Exponex No. 2
Multemp LRL3
Daphne Super Multi Oil 32
Multemp SRL
Daphne Exponex No. 2
Daphne Exponex No. 2
Daphne Exponex No. 2
Daphne Exponex No. 2
Daphne Exponex No. 2
Daphne Exponex No. 2
AFC grease
Daphne Exponex No. 2
AFC grease
Daphne Exponex No. 2
AFC grease
Daphne Exponex No. 2
Daphne Exponex No. 2
Daphne Exponex No. 2
Daphne Exponex No. 2
AFC grease
Daphne Exponex No. 2
Daphne Exponex No. 2
Daphne Exponex No. 2
AFC grease
Every 3 months
Monthly
Every 3 months
Every 3 months
Monthly
Every 3 months
Monthly
Every 6 months
Every 6 months
Every 6 months
Every 6 months
Every 3 months
Every 3 months
Monthly
Monthly
Monthly
Monthly
Monthly
Monthly
Monthly
Every 3 months
Every 3 months
Every 3 months
Monthly
Weekly
Weekly
Monthly
Lubrication points
Schedule
CheckTypes of lubricant
XY-table
Conveyors
Carriers
Tape advance
link
Cam box
Tape cutter
X-axis LM block
X-axis ball screw
X-axis screw cover
Y-axis LM block
Y-axis ball screw
Y-axis screw cover
Z-axis ball screw
Ball screw
Shaft
Lifter guide bar
LM block (742ME, 742E)
LM rail
Cam follower
Tape feed lever
Shaft
Joint
Cam
Cam lever pivot (7 points)
Cam lever bearing
NZ-axis ball screw
NZ-axis LM rail
NZ-axis holder
NZ-axis LM block
-axis connecting pin
Movable cutter
Cam follower
Thrust bearing
