AIVEMT -ID 0909-010 5.2 List of Important Servicing Parts 1-63 T able 4A15-1 Block Name Product Name Part No. Part Name Q'ty Recommended Y ears Note (a) Exploded View Remarks Head Section Slip Ring 223C0201 (630 125…

AIVEMT-ID

0909-010

5.2 List of Important Servicing Parts

1-62

5.2 List of Important Servicing Parts

Listed below are the parts for which maintenance work is required in several

years. The list below is provided for your reference.

Note

Since replacement work of important service parts requires highly

sophisticated technique, consult our service personnel for details

Table 4A15

Block

Name

Product Name Part No. Part Name Q'ty

Recommended

Years

Note (a)

Exploded

View

Remarks

Head

Section

Solenoid Valve 23D10009

(630 141 4539)

ACCESSORY,

48 3 Fig. M-6

Nozzle Shaft

Assembly Nozzle

Shaft Diffusion Plate

(Small)

022L0005

(630 146 4565)

222L0702

(630 127 3235)

213D1166

(630 127 7660)

ASSY,

GUIDE, LINEAR

DISK

Sets

(1)

――― Fig. M-6

Hexagon Socket

Head Bolts M2×6

221A0121

(630 008 3057)

BOLT, HEX-SCT 96 ――― Fig. M-6

For Nozzle Shaft

Attachment

Note (b)

O Ring for Nozzle

Shaft

SO-010-19

226A0187

(630 125 6382)

SEAL 96 2 Fig. M-6

O Ring for Nozzle

Shaft

SO-010-21

226A0105

(630 055 3253)

SEAL 48 2 Fig. M-6

Spring for Nozzle

Shaft

222M1300

(630 125 1417)

SPRING, COMP 48 ――― Fig. M-6

Packing for Nozzle

DYR-3

226A0189

(630 127 3792)

SEAL 96 2 Fig. M-6

O Ring for Filter

SO-006-12

226A0127

(630 076 5090)

SEAL 144 2 Fig. M-6

Linear Measure

Sensor

Linear Measure

Sensor Light Emitter

23G00302

(630 157 4943)

23G00308

(630 161 8654)

SENSOR, PELEC

4Sets ――― Fig. M-6

Outer Diffusion Plate 213D1169

(630 128 2763)

DISK 4 ――― Fig. M-6

Inner Diffusion Plate 213D1167

(630 127 7677)

DISK 4 ――― Fig. M-6

Hexagon Socket

Head Bolt M1.6 × 4

221A0332

(630 129 7064)

BOLT, HEX-SCT 28 ――― Fig. M-6

For Diffusion Plate

Attachment

Note (b)

Top Block 211G4547

(630 145 0018)

BLOCK 48 ――― Fig. M-6

Cam Follower (φ2.5) 222M0134

(630 125 0328)

CAMFOLLOWER 48 ――― Fig. M-6

Hexagon Socket

Head Bolt M1.6 × 3

221A0331

(630 129 7057)

BOLT, HEX-SCT 96 ――― Fig. M-6

For Top Block

Attachment

Note (b)

Sensor PM-L24 23G10059

(630 080 5369)

SENSOR,


4 3 Fig. M-4

Sensor PM-F24 23G10087

(630 125 0878)

SENSOR,


20 3 Fig. M-2,3

AIVEMT-ID

0909-010

5.2 List of Important Servicing Parts

1-63

Table 4A15-1

Block

Name

Product Name Part No. Part Name Q'ty

Recommended

Years

Note (a)

Exploded

View

Remarks

Head

Section

Slip Ring 223C0201

(630 125 0441)

COUPLING 4 2 Fig. M-5

Servo Motor 4M150293

(630 177 8198)

MOTOR,

AC-SERVO

4 2 Fig. M-2

Main

Body

Section

Touch Screen

Controller

4U260238

(630 123 7169)

EQUIPMENT 1 3 Fig. FA-1

Vacuum Pump 224A0042

(630 154 7978)

VACUUM, PUMP 2 ――― Fig. B-3

Transfer

Section

Transfer Pulley 223Q0564

(630 127 2733)

PULLEY, TIMING 24 5 Fig. N-10

Fig. NX-4

Transfer Pulley 223M0050

(630 123 6537)

PULLEY, FLAT 16 5 Fig. N-10

Fig. NX-4

Transfer Belt 223L0260

(630 123 6773)

BELT, TIMING 2 3 Fig. N-10

Transfer Belt 223L0261

(630 123 6780)

BELT, TIMING 4 3 Fig. N-10

Transfer Belt 223L0262

(630 123 6797)

BELT, TIMING 4 3 Fig. NX-4

Note

(a) The numbers entitled "Recommended Years" indicate the referential

values.

(b) Do not reuse the bolts detached for maintenance.
