3-6 AIVEMT -ID Erroe ID Error Name, Description, Cause, and Remedy 400421 Interlock Error L1 axis (Rear) Interlock Detected. Please confirm the nozzle has not fallen when you push the beam by the hand. Confirm of Path line…
3-5
AIVEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
40040e Interlock Error
CB Alarm XY(Rear) Detected
-----
40040f Interlock Error
CB Alarm XY(Front) Detected
-----
400410 Interlock Error
CB Error (Conveyor/Wutter) Detected
-----
400411 Interlock Error
CB Alarm (CPU2) Detected
-----
400412 Interlock Error
CB Alarm (DC24) Detected
-----
400413 Interlock Error
Air pressure Drop detected
-----
400414 Interlock Error
CB Alarm (Vacuum Pump)
-----
400415 Interlock Error
The urgent stop reserve input was input.
Turning on the power supply again then the emergency stop must be pushed, and
the starting point must return later.
400416 Interlock Error
NL axis (Front) Interlock Detected. Please confirm the nozzle has not fallen when
you push the beam by the hand.
The starting point must return.
400417 Interlock Error
NL axis(Rear) Interlock Detected. Please confi
rm the nozzle has not fallen when
you push the beam by the hand.
The starting point must return.
400418 Interlock Error
L1 axis(Front) Interlock Detected. Please confirm the nozzle has not fallen when
you push the beam by the hand.
Confirm of Path line/Head excess pushing detection.
400419
Interlock Error
L2 axis(Front) Interlock Detected. Please confirm the nozzle has not fallen when
you push the beam by the hand.
Confirm of Path line/Head excess pushing detection.
400420 Interlock Error
L3 axis (Front) Interlock Detected. Please confi
rm the nozzle has not fallen when
you push the beam by the hand.
Confirm of Path line/Head excess pushing detection.
0606-009
3.1 Safety Devices
3-6
AIVEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
400421 Interlock Error
L1 axis (Rear) Interlock Detected. Please confirm the nozzle has not fallen when
you push the beam by the hand.
Confirm of Path line/Head excess pushing detection.
400422 Interlock Error
L2 axis (Rear) Interlock Detected. Please confirm the nozzle has not fallen when
you push the beam by the hand.
Confirm of Path line/Head excess pushing detection.
400423 Interlock Error
L3 axis (Rear) Interlock Detected. Please confi
rm the nozzle has not fallen when
you push the beam by the hand.
Confirm of Path line/Head excess pushing detection.
400501 Lightning Surge W
arning
Lightning Surge Protector works; L201,L202,L203. Please turn on the load power
supply after resetting error.
-----
400502 Lightning Surge Warning
-----
400503 Lightning Surge Warning
-----
400504 Lightning Surge Warning
-----
400505 Lightning Surge Warning
-----
400601 Servo Alarm
Servo Alarm Detected
-----
400602 Servo Alarm
All Beam alarm reseting API Error
-----
0606-009
3.1 Safety Devices
3-7
AIVEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
400701 Zero Return
Beam XY zeroing Error
-----
400702 Zero Return
When beam XY (Rear) starting zeroed, the standard mark gap was generated.
Please start up the power supply.
400703 Zero Return
When beam XY (Front) starting zeroed, the standard mark gap was generated.
Please start up the power supply.
400704 Zero Return
When beam XY (Rear) starting zeroed, recognition error of a standard mark was
generated.
-----
400705 Zero Return
When beam XY (Front) starting zeroed, recognition error of a standard mark was
generated.
-----
400801 Cutter Error
Cutter Alarm Detected (waveform Data setting)
-----
400802 Cutter Error
Cutter Alarm Detected (Zeroing)
-----
400803 Cutter Error
Cutter axis Time Out (Start zero)
-----
400804 Cutter Error
Cutter axis Time Out(Zero)
-----
400805 Cutter Error
Cutter axis zero finished
-----
400806 Cutter Error
Cutter axis Alarm Detection(Start Locating)
-----
0606-009
3.1 Safety Devices
