3-33 AIVEMT -ID 3.1 1 Automatic Operation Error T able 4C13 Erroe ID Error Name, Description, Cause, and Remedy 510101 Auto Run Error API Error Please push the [emergency stop] button and return. 510201 Auto Run Error Pa…
3-32
AIVEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
500d01 Comp. Missing (Sensor) After Chuck
-----
500e01 Comp. Missing (Sensor) Before Mount
-----
0606-009
3.10 Pickup Error
3-33
AIVEMT-ID
3.11 Automatic Operation Error
Table 4C13
Erroe ID Error Name, Description, Cause, and Remedy
510101 Auto Run Error
API Error
Please push the [emergency stop] button and return.
510201 Auto Run Error
Pattern program error
Please modify the pattern program.
510202 Auto Run Error
Component Library
Please modify the comp. Library.
510203 Auto Run Error
Operation Mode Error
-----
510204 Auto Run Error
The system setting data is abnormal.
-----
510301 Auto Run Error
JOB time-out during processing.
Please push the [emergency stop] button and return.
510302 Auto Run Error
JOB control Error
-----
510501 Auto Run Error
The recognition result response Error. (Before placement)
-----
510502 Auto Run Error
The recognition result response Error. (After placement)
-----
510601 Auto Run Error
Feeder Alarm
-----
510602 Auto Run Error
Feeder Error (Feed Timeout)
-----
510603 Auto Run Error
Pickup Error
-----
0606-009
3.11 Automatic Operation Error
3-34
AIVEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
510701 Auto Run Error
-----
510703 Auto Run Error
Head Mis-Pickup Detection
Please do the comp. discard operation
510801 Auto Run Error
Warm Start Error
Please position the PCB
510901 Auto Run Error
Comp.Vertical
-----
510902 Auto Run Error
Comp.Missing (Sensor)
-----
510903 Auto Run Error
Comp.recog.Error
-----
510904 Auto Run Error
Comp. Missing (Recog.)
-----
510a01 Auto Run Error
Pocket recog error
-----
510b01 Auto Run Error
Master bad mark detection is abnormal.
-----
510b02 Auto Run Error
Bad mark detection is abnormal.
-----
0606-009
3.11 Automatic Operation Error
