3-28 AIVEMT -ID 3.8 Head-Related Errors T able 4C10 Erroe ID Error Name, Description, Cause, and Remedy 4A0101 Head Zero Return NL axis zeroing Error . Please confirm the nozzle has not fallen when you push the beam by th…
3-27
AIVEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
49070e Nozzle set up
The remains nozzle was detected on the head. The nozzle cannot be set to this
position.
Please confirm the nozzle has not adhered to the position. Moreover, please clean
the line sensor when not adhering.
49070f Nozzle set up
The placed nozzle was undetectable on the head.
Please confirm whether the nozzle has adhered to the position.
490710
Nozzle set up
The receipt nozzle was undetectable on the head.
Please confirm whether the nozzle has adhered to the position.
490711
Nozzle set up
The remains nozzle was detected on the head.
Please confirm the nozzle has not adhered to the position. Moreover
, please clean
the line sensor when not adhering.
490712 Nozzle set up
The linear measure error occurred in the head nozzle existence check.
Please confirm the nozzle arrangement, and execute the level teaching.
490713
Nozzle set up
The nozzle exchange sequence error occurred.
Please confirm the nozzle arrangement.
490714 Nozzle set up
The nozzle placement in nozzle stocker is dif
ferent from the nozzle data.
Please confirm the nozzle placement.
490715
Nozzle set up
It failed in nozzle ID detection.
Please confirm the nozzle ID.
490716
Nozzle set up
Time-out of close nozzle stocker operation.
Nozzle st
ocker was
opened for safety. Please confirm whether there is no rise to the
surface and the nozzle is not in opening and shutting caught state.
0606-009
3.7 Automatic Setup
3-28
AIVEMT-ID
3.8 Head-Related Errors
Table 4C10
Erroe ID Error Name, Description, Cause, and Remedy
4A0101 Head Zero Return
NL axis zeroing Error. Please confirm the nozzle has not fallen when you push the
beam by the hand.
Please check error on a “MAINT-DVC CHK- MOTOR” screen.
4A0102
Head Zero Return
HL axis zeroing Error. Please confirm the nozzle has not fallen when you push the
beam by the hand.
Please check error on a “MAINT-DVC CHK- MOTOR” screen.
4A0103
Head Zero Return
L1 axis zeroing Error. Please confirm the nozzle has not fallen when you push the
beam by the hand.
Please check error on a “MAINT-DVC CHK- MOTOR” screen.
4A0104 Head Zero Return
L2 axis zeroing Error. Please confirm the nozzle has not fallen when you push the
beam by the hand.
Please check error on a “MAINT
-DVC CHK- MOTOR” screen.
4A0105 Head Zero Return
L3 axis zeroing Error. Please confirm the nozzle has not fallen when you push the
beam by the hand.
Please check error on a “MAINT
-DVC CHK- MOTOR” screen.
0606-009
3.8 Head-Related Errors
3-29
AIVEMT-ID
3.9 Others
Table 4C11
Erroe ID Error Name, Description, Cause, and Remedy
4b0101 Head Mis-Pickup Detection
Auto Run can’t be performed with the Mis-Pickup Component on the head.
-----
4b0201 Feeder communication Error.
Communication with the feeder has error.
Please check the number of component remain.
4b0202 Feeder communication Error.
Communication with the feeder has error
. (System error)
-----
4b0203 Feeder Alarm
Feeder Alarm. Please confirm the feeder and the component.
-----
4b0301 Feeder Base
The feeder base detection was turned off while the cutter was working.
-----
4b0302 Feeder Unclamp Timeout
The feeder unclamp operation was not completed within predetermined time.
-----
4b0303 Feeder Base
Feeder operation errors
Please check after removing feeder in case using tape feeder. Please check part of
supply in case using tray.
4b0304 Feeder Base
The feeder clamp operation was not completed within predetermined time.
-----
4b0401 Recycling Conveyor
The recycling conveyer (back) was filled.
Please push a manual switch, and remove parts on the recycling conveyer.
4b0402 Recycling Conveyor
The recycling conveyer (front) was filled.
Please push a manual switch, and remove parts on the recycling conveyer.
4b0403 Recycling Conveyor
The recycling conveyer (back) motor operation time out.
There is a possibility a problem in the motor wiring. Please check the motor wiring.
Please begin the production.
4b0404 Recycling Conveyor
The recycling conveyor (front) motor operation time out.
There is a possibility a problem in the motor wiring. Please check the motor wiring.
Please begin the production.
4b0405 Recycling Conveyor
Component trash Box (back) was fi
lled
Please open the safety door
, and empty the comp abandonment box.
0606-009
3.9 Others
