4-22
AIVEMT-ID
3.6 Nozzle Recognition Errors
Z
A
B CC DDD
Detailed Classification: Detailed Classification
Small Classification: Small Classification
Middle Classification
0: Nozzle Recognition (Nozzle Missing)
1: Nozzle Recognition (Coarse Recognition Error)
2: Nozzle Recognition (Coarse Recognition Error)
3: Nozzle Recognition (Detailed Recognition Error)
8: Nozzle Recognition (Inspection Error)
9: Nozzle Recognition (Judgement Error)
E: Nozzle Recognition (Other Errors)
Large Classification (7)
Classification Criteria
Notice
When an error ID other than the described ones is issued, contact
our service personnel for some advice.
Table 4D9
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 7 0 ** 001 Nozzle not detected.
0 7 1
** 001 Nozzle not detected.
0 7 2
** 001 Nozzle not detected.
0 7 2
** 002 Nozzle not detected.
0 7 3
** 101 Edge not detected.
0 7 3
** 102 Nozzle not detected.
(Cause 1) Abnormal Nozzle Attachment
(Cause 2) The nozzle type data is abnormal.
(Remedy 1) Attach the correct nozzle.
(Remedy 2)
Check the nozzle type data. If necessary, correct it.
0 7 8 ** 101 Nozzle size has exceeded the allowable range.
0 7 8
** 102 Nozzle size has exceeded the allowable range.
0 7 8
** 201 Check error
0 7 8
** 202 Check error
(Cause 1) The attached nozzle is different from the nozzle specified in the
placement head/nozzle data.
(Cause 2) The nozzle type data is abnormal.
(Remedy 1)
Attach the correct nozzle.
(Remedy 2) Check the nozzle type data. If necessary, correct it.
0606-009
3.6 Nozzle Recognition Errors
4-23
AIVEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 7 8 ** 301 Nozzle position has exceeded the allowable range.
0 7 8
** 302 Nozzle position has exceeded the allowable range.
0 7 8
** 303 Nozzle position has exceeded the allowable range.
0 7 8
** 304 Nozzle position has exceeded the allowable range.
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
0 7
9 * * * * * Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
0 7
E ** 001 Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
1 7
* * * * * * Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
0606-009
3.6 Nozzle Recognition Errors
4-24
AIVEMT-ID
3.7 Character Recognition Errors
Z
A
B CC DDD
Detailed Classification: Detailed Classification
Small Classification: Small Classification
Middle Classification
0: Character Recognition (Nozzle Missing)
1: Character Recognition (Coarse Recognition Error)
2: Character Recognition (Detailed Recognition Error)
8: Character Recognition (Inspection Error)
9: Character Recognition (Judgement Error)
E: Character Recognition (Other Errors)
Large Classification (8)
Classification Criteria
Notice
When an error ID other than the described ones is issued, contact
our service personnel for some advice.
Table 4D10
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 8 0 ** 001 The nozzle is not stored.
(Cause) The nozzle is not stored.
(Remedy) Store the nozzle.
0 8
1 ** 001 The locator mark cannot be detected.
0 8 2
** 001 There are characters that cannot be detected.
(Cause 1) The direction of the nozzle attachment is wrong.
(Cause 2) The diffusion plate is dirty.
(Remedy 1)
Attach the nozzle in the correct direction.
(Remedy 2) Clean the diffusion plate.
0 8 E ** 001 Others.
(Cause) Self-Diagnostics Error Message.
(Remedy) Contact our service personnel for details.
1 8
* * * * * * Others.
(Cause) Self-Diagnostics Error Message.
(Remedy) Contact our service personnel for details.
0606-009
3.7 Character Recognition Errors
