2-6
AIVEMT-ID
Warning Codes Display Field A (Scope of Warning Messages)
Display Field B (Details of Warning Messages)
010f20 PCB existence
There is no PCB on the positioning 1conveyor.
010f21 PCB existence
There is no PCB on the central conveyor.
010f22 PCB existence
There is no PCB on the positioning 2conveyor.
010f23 PCB existence
There is no PCB on the inlet and outlet of output cnvr.
010f24 PCB existence
There is no PCB that can be transported.
010f25
PCB existence
Two PCBs were detected on the supply conveyor
. Please remove the PCB of the
conveyor entrance.
010f26 PCB existence
Two PCBs were detected on the discharge conveyor
. Please remove the PCB on
the conveyor.
0606-009
2.2 List of Warning Messages
2-7
AIVEMT-ID
Warning Codes Display Field A (Scope of Warning Messages)
Display Field B (Details of Warning Messages)
011001 Empty Feeder (rear)
Please set the feeder (back) that used by the pattern program.
011101 Empty Feeder (front)
Please set the feeder (front) that used by the pattern program.
011201
Transfer main loop
Press [POWER ON] button to activate Load Power circuit.
011301
Transfer main loop (backup, wide set)
Press [POWER ON] button to activate Load Power circuit.
011401
Zeroing not finish
Perform All zeroing
011501
Feeder communication not finish (rear)
Please wait for a while.
011601 Feeder communication not finish (front)
Please wait for a while.
011701
PCB position
Please position the PCB
011702 PCB position
Please locate the PCB in positioning 1.
011703 PCB position
Please locate the P.C.B in positioning 2.
011801
Data transfer not finish
It cann’t start because data is not set properly.
01
1901 Head irregular comp. confirmation
Please perform all zeroing, turn off a vacuum and remove the component on the
head.
011a01 Nozzle stocker lower limit confirmation
Perform All zeroing.
01
1b01 NL axis zero confirmation
Perform All zeroing.
011c01 Nozzle arrangement confirmation (rear)
The nozzle arrangement of the Current Program and the head (back) is different.
011d01 Nozzle arrangement confirmation (front)
The nozzle arrangement of the Current Program and the head (front) is different.
011e01 Feeder reload (rear)
Please reload the feeder that has shortage of comp.
01
1f01 Feeder reload (front)
Please reload the feeder that has shortage of comp.
0606-009
2.2 List of Warning Messages
2-8
AIVEMT-ID
Warning Codes Display Field A (Scope of Warning Messages)
Display Field B (Details of Warning Messages)
012001 Recycling Conveyor (rear)
Recycling conveyor (back) is filled.
012101 Recycling Conveyor (front)
Recycling conveyor (front) is filled.
012201 Recycling Conveyor (rear)
Comp. Trash Box (rear) is filled.
012301 Recycling Conveyor (front)
Comp. T
rash Box (front) is filled.
012501 Data check
Error was found in internal data of the control. Please change the model or try to
save the system data.
012601 Recycling Conveyor (rear)
Please connect the recycling conveyor (rear).
012701
Recycling Conveyor (front)
Please connect the recycling conveyor (front).
012801 T
ray safety door (rear)
Please close tray door(rear).
012901 Tray safety door (front)
Please close tray door(front).
012a01 Tray shortage Comp (rear)
Please supply comp
012b01 Tray shortage Comp (front)
Please supply comp
012c01 PCB Size X
Please check the PCB size X of pattern program data.
012d01 PCB Size Y
Please check the PCB size
Y of pattern program data.
012e01 Magazine existence,
Type difference
Please check the existence of a magazine, or the number of stages of a magazine.
012f01 Magazine existence,
Type difference
Please check the existence of a magazine, or the number of stages of a magazine.
0606-009
2.2 List of Warning Messages
