3-9 AIVEMT -ID Erroe ID Error Name, Description, Cause, and Remedy 400a04 Head Interlock Error Path line detection 3 ----- 400a05 Head Interlock Error Path line detection 2 ----- 400a06 Head Interlock Error Path line det…
3-8
AIVEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
400836 Cutter Error
Cutter axis Time Out(when locating)
-----
400837 Cutter Error
Cutter axis Alarm Detected(During Locating)
-----
400838 Cutter Error
Cutter axis Alarm Detected(During Locating). The cutter axis zeroing was carried
out.
Please check whether there are any errors in a cutter unit.
400839 Cutter Error
Because main circuit of the cutter axis was OFF or the servo was OFF. The feeder
base descent operation was not able to be done.
Please confirm the emergency stop and the safety door.
400901 Tray Interlock Error
Main Power Of
f
-----
400902 Tray Interlock Error
-----
400903 Tray Interlock Error
-----
400904 Tray Interlock Error
-----
400905 Tray Interlock Error
-----
400a01 Head Interlock Error
Head excess pushing detection 3
-----
400a02 Head Interlock Error
Head excess pushing detection 2
-----
400a03 Head Interlock Error
Head excess pushing detection 1
-----
0606-009
3.1 Safety Devices
3-9
AIVEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
400a04 Head Interlock Error
Path line detection 3
-----
400a05 Head Interlock Error
Path line detection 2
-----
400a06 Head Interlock Error
Path line detection 1
-----
400a07 Head Interlock Error
Head Stop
-----
400a08 Head Interlock Error
A brake cannot be taken off during Servo On.
-----
400a09 Head Interlock Error
Nozzle tilting detection 1
Please confirm the nozzle of Nozzle stock 1.
400a0a Head Interlock Error
Nozzle tilting detection 2
Please confirm the nozzle of Nozzle stock 2.
400b01 Feeder preparation complete
The suppressor Mis-set or Disengaged Latch was detected
Safety cover open,please confirm there is no interference with the head and be safe
or turn off the preparation completion of the feeder with the Safety cover opened.
400c01
Nozzle stocker down time out
Nozzle stock unit lower bound detection 1 was not turned on in prescribed time.
Please confirm the lower bound detection 1 sensor of nozzle stock unit.
400c02
Nozzle stocker down time out
Nozzle stock unit lower bound detection 2 was not turned on in prescribed time.
Please confirm the lower bound detection 2 sensor of nozzle stock unit.
400c03 Nozzle stocker down time out
Nozzle stock unit lower bound detection 3 was not turned on in prescribed time.
Please confi
rm the lower bound detection 3 sensor of nozzle stock unit.
400c04 Nozzle stocker down time out
Nozzle stock unit lower bound detection 4 was not turned on in prescribed time.
Please confi
rm the lower bound detection 4 sensor of nozzle stock unit.
0606-009
3.1 Safety Devices
3-10
AIVEMT-ID
0606-009
3.2 Data
Table 4C4
Erroe ID Error Name, Description, Cause, and Remedy
410101 Data Error
Machine data and system data error detected.
-----
410102 Data Error
Auto run start mode setup data error
-----
410103 Data Error
Steps in converted pattern program is more
-----
410104 Data Error
Pattern Program Errors(PECRecog step error)
-----
410105 Data Error
The component library data used by the pattern program data doesn’t exist.
-----
410106 Data Error
The nozzle type data registered in the nozzle data doesn’t exist
-----
410107 Data Error
The nozzle type data registered in the nozzle data doesn’t exist
-----
410201 Mode data Error
Abnormality is found in the production driving beginning mode setting data.
-----
410301 Pattern Program Error
Steps in converted pattern program is more
-----
410302 Pattern Program Error
There are Errors in converted pattern program (PEC recog steps Error).
-----
410303 Pattern Program Error
The converted pattern program is not exist, the data is damaged.
-----
410304 Pattern Program Error
The error is found in the adsorption nozzle number of the conversion pattern
program.
-----
410305 Pattern Program Error
The error is found in the order of adsorption of the conversion system pattern
program.
-----
3.2 Data
