2-10
AIVEMT-ID
0606-009
3. Machine Information
3.1 "Machine Information" Window
This window shows various kinds of information while the machine is
running.
Note
The machine does not stop running when this window becomes active.
[2]
[3]
[1]
[4]
Fig. 4B3
[1] Display Field A
Displayed is the outline of the machine information.
[2]
Display Field B
Displayed is the detailed machine information.
[3]
[OK] Button
When pressed, this button closes the "Machine Information" window.
[4]
[Clear Alarm] Button
When pressed, this button cancels an alarm (sound) only.
3. Machine Information
2-11
AIVEMT-ID
3.2 List of Machine Information
Table 4B4
Machine Information
Codes
Display Field A (Scope of Machine Information)
Display Field B (Details of Machine Information)
800301 Warning: Decreasing of Comp. Hdlg. Rate (For Noz.)
Nozzle message rate
800302 Warning: Decreasing of Comp. Hdlg. Rate (For Noz.)
The rate of nozzle adsorption fell. A cycle stop is carried out.
800401 W
arning: Decreasing of Comp. Hdlg. Rate (For Fdr.)
Feeder message rate
800402 Warning: Decreasing of Comp. Hdlg. Rate (For Fdr
.)
The rate of feeder adsorption fell. A cycle stop is carried out.
800601
Alternated Feeder
Comp. Missing (sensor)
800602 Alternated Feeder
Comp. Vertical (sensor)
800603 Alternated Feeder
Comp. Missing (recog.)
800604 Alternated Feeder
Comp. Recog. Error
800605 Alternated Feeder
Shortage of component
800606
Alternated Feeder
Start recovery mode.
800607 Alternated Feeder
Comp.
Thickness (sensor)
800608 Alternated Feeder
Comp. Pickup Diff. (recog.)
800609 Alternated Feeder
Comp. Reverse (recog.)
80060b Alternated Feeder
Feeder Reload Stop (Splicing)
0606-009
3.2 List of Machine Information
2-12
AIVEMT-ID
Machine Information
Codes
Display Field A (Scope of Machine Information)
Display Field B (Details of Machine Information)
800701 Alternated Block
Comp. Missing(sensor)
800702 Alternated Block
Comp. Vertical(sensor)
800703 Alternated Block
Comp. Missing(recog.)
800704 Alternated Block
Comp. Recog. Error
800705 Alternated Block
Shortage of component
800706
Alternated Block
Start recovery mode.
800707 Alternated Block
Comp.
Thickness(sensor)
800708 Alternated Block
Comp. Pickup Diff.(recog.)
800709 Alternated Block
Comp. Reverse(recog.)
800801 Start Auto Recovery Mode
Comp. Missing (sensor)
800802
Start Auto Recovery Mode
Comp. Vertical(sensor)
800803
Start Auto Recovery Mode
Comp. Missing(recog.)
800804
Start Auto Recovery Mode
Comp. Recog. Error
800805 Start Auto Recovery Mode
Shortage of component
800806 Start Auto Recovery Mode
Comp. Thickness (sensor)
800807
Start Auto Recovery Mode
Comp.
Thickness (sensor)
800808 Start Auto Recovery Mode
Comp. Pickup Dif
f. (recog.)
800809 Start Auto Recovery Mode
Comp. Reverse (recog.)
80080b
Start Auto Recovery Mode
Feeder Reload Stop (Splicing)
0606-009
3.2 List of Machine Information
