3-2
AIVEMT-ID
2. Error IDs and Controlled Areas
Basic System of Error IDs
An error ID is expressed by 6 digits (hexadecimal) as follows.
Major Classification of "Operation Axis", "Process Error",
and "Teaching Operation"
Error IDs and Controlled Areas
Table 4C2
Error ID Operation Axis
02
03
04
05
06
07
08
09
0a
0b
0c
0d
0e
0f
10
1
1
12
13
14
15
16
17
18
19
20
Error ID Process Error
40 Safety Devices
41 Data
42 Conveyor
43 Self-Diagnostics 1
44 Self-Diagnostics 2
45 Recognition Communication
46 PEC Recognition
48 Component Recognition
49 Automatic Setup
4a Head-Related Error
4b Others
4c Unit PCB Error Detection
50 Pickup Error
51 Automatic Operation Error
60 Automatic
Teaching
61 Test
FE
System Error
FF Interlock Interrupt
0606-009
2. Error IDs and Controlled Areas
3-3
AIVEMT-ID
3. Error IDs and Remedial Procedures
3.1 Safety Devices
Table 4C3
Erroe ID Error Name, Description, Cause, and Remedy
400101 Load Power Shutoff
The [emergency stop] switch was pressed.
-----
400102 Load Power Shutoff
The air pressure is too low.
-----
400103 Load Power Shutoff
Circuit protector is active.
-----
400104 Load Power Shutoff
-----
400105 Load Power Shutoff
Load Power is OFF
Please check the safety relay (K15) wiring.
400106 Load Power Shutoff
-----
400107 Load Power Shutoff
Load power-on timeout.
-----
400108 Load Power Shutoff
-----
400201 Beam Power Shutoff
-----
400202 Beam Power Shutoff
Load power-on timeout.
-----
400203 Beam Power Shutoff
-----
400301 B Beam Power Shutoff
-----
400302 B Beam Power Shutoff
-----
0606-009
3. Error IDs and Remedial Procedures
3-4
AIVEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
400303 B Beam Power Shutoff
-----
400401 Interlock Error
The [emergency stop] switch was pressed.
-----
400402 Interlock Error
Safety cover opened
Please shut a safety cover and push the [POWER ON] button.
400403 Interlock Error
Safety cover(CV) detected
-----
400404 Interlock Error
Beam XY(Raer) main power off
-----
400405 Interlock Error
Beam XY(front) main power off
-----
400406 Interlock Error
Head (Rear) Nozzle downward detected
The starting point must return.
400407 Interlock Error
Head (Front) Nozzle downward detected
The starting point must return.
400408 Interlock Error
Disengaged Latch (Rear) was detected.
-----
400409 Interlock Error
Disengaged Latch (Front) was detected.
-----
40040a Interlock Error
The suppressor Mis-set (Rear) detected.
Please execute the Warm start.
40040b Interlock Error
The suppressor Mis-set (front) detected.
Please execute the Warm start.
40040c Interlock Error
Component Mis-Pickup(rear) detected
Please remove the factor which is shading the feeder peristome sensor (rear), and
carry out a zero return. (It continues at a warm start)
40040d Interlock Error
Component Mis-Pickup(front) detected
Please remove the factor which is shading the feeder peristome sensor (front), and
carry out a zero return. (It continues at a warm start)
0606-009
3.1 Safety Devices
