4 Replacing spare parts at the conveyor
4.8 Teaching the PCB sensors
100 Service Manual ASM ProcessLens Dual-lane 09/2018
4.8 Teaching the PCB sensors
► Click on this icon(1) to enter the settings menu.
► Click on Unit Function(2) to enter the settings user menu.
► Switch to operator level Machine service.
► Click on System Test(3) to enter the calibration menu.
► Click on Sensor Calibration(4) to proceed the calibration of the PCB sensor.
