8 IC Head SIPLACE 80S/F/G Service M anual Edition 01/97 8 - 26
SIPLACE 80S/F/G Service Manual 8 IC Head
Edition 01/97
8 - 25
Fig. 8.5.3 Check the vacuum generator
Key to Fig. 8.5.3
1 Collet bush PK-3 2 O-ring 3 x 1
3 O-ring 5 x 1.5 4 Vacuum nozzle for IC head
5 O-ring 8 x 1 6 Silencer
7 Collet bush PK-3 8 Hose coupling T-PK-3
9 Nipple with male threaded end 10 Hose coupling T-PK-3
A Remove spacer
8
6
1
7
5
9
10
4
3
2
A
8 IC Head SIPLACE 80S/F/G Service Manual
Edition 01/97
8 - 26
SIPLACE 80S/F/G Service Manual 8 IC Head
Edition 01/97
8 - 27
8.6 Measure Nozzle Changer
8.6.1 Tools, Equipment
8.6.2 Determine X/Y-Coordinates of the Nozzle Garages
●
Select the following menu sequence from the SITEST program:
Functions
↵
Nozzle changer
↵
Nozzle changer IC head
↵
Calibrate nozzle changer complete
8.6.3 Determine Nozzle Pick-Up Angle
The nozzle pick-up angle is the angle at which the nozzle is removed from the garage.
●
Connect the test box as described in the Adjusting Instructions.
●
Place a nozzle on the nozzle support (spring steel sheet).
●
Deactivate the dr axis.
●
Manually turn the sleeve until the nozzle can be moved into the garage.
●
Read the corresponding dr axis value on the test box.
●
Divide the value determined by two and enter this value in the menu. As a rule the values should be about
9500.
PLEASE NOTE
It is generally sufficient to determine the value for one nozzle and then to use this value for the other noz-
zles.
The values in the test program for ’pick-up at d pos. or ’lock in place at d pos.‘ are used only to pick-up or
set down the nozzles correctly. They are not saved. In the menu item ’Pick-up angle’ the value will be
stored in the file Real.Ma.
8.6.4 Determine Pick-Up Height
●
Select the following menu sequence from the SITEST program:
Functions
↵
Nozzle changer
↵
Nozzle changer IC head
↵
Pick-up or return nozzle. The correct pick-up
height is determined by picking up and returning the nozzle.
From item number
SITEST program V
≥
203.000
Nozzle removal tool 00311448-01
Test box
Adjusting Instructions
