Direct solenoid and solenoid pilot operated valves 169 36 32 37 38 33 34 52 67 46 44 47 42 400 48 92 93 ISO 1 ISO 2 ISO 3 69 48P ISO 01 ISO 02 Consult “Precautions” page 327 before use, installation or service of MAC Val…

100%1 / 280
33.0
15.0
141.6
1/8" N.P.T.F. PILOT
PORT 3 PLACES
B
A
57.0
TYP.
35.5
TYP.
33.0
TYP.
11.5
TYP.
27.0
TYP.
39.0
TYP.
70.0
TYP.
105.0
TYP.
143.6
TYP.
1/2" NPTF
3HOLES
BOTH ENDS
37.5
203.73
182.38
DOUBLE SOLENOID
SINGLE SOLENOID
10.55
19.05
33.5
19.05
33.5
19.05
10.55
64.70
TYP.
22.80
TYP.
OPTIONAL BOTTOM
PORTS 3/8" & 1/2"
6.3 DIA
4 MTG. HOLES
87.50
TYP.
31.5
TYP.
A
IN
EX
CONDUIT
A A
A
B
EP EP
EP
EB
EA
B
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
168
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series
93
Fluid :
Pressure range :
Lubrication :
Filtration :
Temperature range :
Flow :
Coil :
Voltage range :
Protection :
Power :
Response times :
(with 5.4 W coil)
Compressed air, vacuum, inert gases
Internal Pilot: 20 to 120 PSI
External Pilot: Vacuum to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
3/8” : (3.4 C
v
) - 1/2” : (3.8 C
v
)
Class A continuous duty, #22 AWG x 18 base leads
-15% to +10% of nominal voltage
Consult factory
~ Inrush 7.6 VA Holding: 4.8 VA
= 1 to 12.7 W
Energize : 13 ms
De-energize : 10 ms
• BSPP thread • Sandwich regulator (see ‚regulators‘ section)
• Sandwich flow controls FC93A-AA (screwdriver slot adjustment), FC93A-AB (locking knob adjustment)
• Pilot valve: DM-DxxP-xxx • Valve to base pressure seal: 16622
• Pilot valve pressure seal: 16542 • Mounting screws valve to base (x4): 35249
• Inlet/exh. Isolator disc: N-93008 • Valve blanking plate: M-93002
Options :
Spare parts :
#
B
1
71.6
2
105.1
3
138.6
4
172.1
5
205.6
6
239.1
7
272.6
8
306.1
9
339.6
10
373.1
DIM.
3/8"
1/2"
A
47.66
49.32
Direct solenoid and solenoid pilot operated valves
169
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series
93
OPTIONS FOR
NON PLUG
-IN AND
INLINE VALVES
93A-XXX-XXX-
DM
-D
XXX
-
XXX
DM pilot exhaust muffled
DP pilot exhaust piped (#10-32)
DU pilot exhaust to main exhaust
Base only :
* Must use DU pilot. Main valve exhaust cannot be restricted.
Pilot style :
- Manifold base
Valve function
- Individual base
Pilot exhaust
93A-000-XXX (i.e. 93A-000-BAG)
93A-000-XXX (i.e. 93A-000-BJG)
93A-
L
XX-XXX-XX-D
XXX
-
XXX
L for single operator, single pressure with memory spring
N for single operator, dual pressure with memory spring
R for single operator universal spool (ext. pilot only)
S for double operator universal spool (ext. pilot only)
93A-XXX-X
J
X-XX-D
XXX
-
XXX
J side ports
K bottom ports
Manifold sub-base
Port configuration :
Individual sub-base
93A-XXX-X
A
X-XX-D
XXX
-
XXX
A side ports (3/8” & 1/2" only)
B bottom ports (1/4” & 3/8" only)
C side & bottom ports (1/4" & 3/8” only)
D side inlet & exhaust with bottom
cylinder ports (1/4" & 3/8” only)
93A-X
B
X-XXX-XX-D
XXX
-
XXX
B standard pilot exhaust
D pilot exhaust to main valve exhaust*
Direct solenoid and solenoid pilot operated valves
170
Consult “Precautions” page 327 before use, installation or service of MAC V
alves..
Series
93
OPTIONS FOR
PLUG
-I N VALVES
93A-XXX-XX
A
-XX-D
XX
P-
XXX
A internal pilot no light
B internal pilot single light
C internal pilot double light
D external pilot no light
E external pilot single light
F external pilot double light
Base/manifold int./ext. pilot
93A-XXX-XXX-
DM
-D
XX
P-
XXX
DM pilot exhaust mued
DP pilot exhaust piped (#10-32)
DU pilot exhaust to main exhaust
Base only :
* Must use DU pilot. Main valve exhaust cannot be restricted.
(Note: bases are wired for double solenoid valves)
Pilot style :
- Manifold base
Valve function
- Individual base
Pilot exhaust
93A-000-XXX (i.e. 93A-000-BAA)
93A-000-XXX (i.e. 93A-000-BJA)
93A-
L
XX-XXX-XX-D
XX
P-
XXX
L for single operator, single pressure with memory spring
N for single operator, dual pressure with memory spring
R for single operator universal spool (ext. pilot only)
S for double operator universal spool (ext. pilot only)
93A-XXX-X
J
X-XX-D
XX
P-
XXX
J side ports
K bottom ports
Manifold sub-base
Port conguration :
Individual sub-base
93A-XXX-X
A
X-XX-D
XX
P-
XXX
A side ports (3/8” & 1/2" only)
B bottom ports (1/4” & 3/8" only)
C side & bottom ports (1/4" & 3/8” only)
D side inlet & exhaust with bottom
cylinder ports (1/4" & 3/8” only)
93A-X
A
X-XXX-XX-D
XX
P-
XXX
A standard pilot exhaust
C pilot exhaust to main valve exhaust*
Body electrical
93A-XX
A
-XXX-XX-D
XX
P-
XXX
A no light
B light(s)
