Function Port size Flow (Max) Individual mounting Series
OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
39
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
32
3/2 NO-NC # 10-32 - 0.4 C
v
1/4”
O.D. tube receptacle
Manifold base
“plug-in”
1. 3-way valve with 4-way integral pilot.
2. 10 mm valve (stacks on 10.5 mm centers).
3. High flow (up to 0.4 C
v
).
4. Fast, repeatable response times.
5. Maximum shifting forces in both directions.
32B-
XXX
-
X
J
X
-G
XX
P-
XXX
OPTIONS
J Manifold base – Side port
K Manifold base – Bottom port
L Left end manifold base – Side port
M Left end manifold base – Bottom port
N Right end manifold base – Side port
P Right end manifold base – Bottom port
Note : Manifold assemblies consist of (1) left end manifold, (1) right end manifold and middle station manifolds (options "J" or "K").
NO valve
32B-BMA-000-G
XX
P-
XXX
32B-BMB-000-G
XX
P-
XXX
32B-BMA-AJA-G
XX
P-
XXX
32B-BMB-AJB-G
XX
P-
XXX
32B-BMA-EJA-G
XX
P-
XXX
32B-BMB-EJB-G
XX
P-
XXX
NC valve
32B-AMA-000-G
XX
P-
XXX
32B-AMB-000-G
XX
P-
XXX
32B-AMA-AJA-G
XX
P-
XXX
32B-AMB-AJB-G
XX
P-
XXX
32B-AMA-EJA-G
XX
P-
XXX
32B-AMB-EJB-G
XX
P-
XXX
Universal valve
32B-GMB-000-G
XX
P-
XXX
32B-GMB-AJB-G
XX
P-
XXX
32B-GMB-EJB-G
XX
P-
XXX
Port size
Valve less base
# 10-32
1/4” O.D.
Tube receptacle
Pilot air
Internal
External
Internal
External
Internal
External
Note : Above codes are for side port.
Voltage
AA
120 VAC (2.5W)
DA
24 VDC (1.0W)
DC
24 VDC (1.8W)
DD
24 VDC (2.5W)
DF
24 VDC (4.0W)
Manual operator
1
Non-locking recessed
2
Locking recessed
Electrical connection
SA
Base plug-in
SJ
Base plug-in with light
SS
Base plug-in with rectifier & light & ground
G
XX
P-
XXX
*
STANDARD SOLENOID OPERATOR
®
XX X XX
Note : AC voltage requires connector with rectifier.
* Other options available, see page 311.
Latching solenoid also available, see page 43.
Washdown capability is possible, consult factory for modification number.
Base Configuration :
32B-000-
XXX
(i.e. 32B-000-AJA)
Base only :
2
1210
13
2
1210
13
2
1210
13
1/4" IN & EXH COMMONS
PILOT
1/8" EXTERNAL
1"-11 1/2 CONDUIT
Ø 5.3
39.6
10.5 18.5
94.0
68.4
56.7
23.2
20.0
22.0
11.1
9.5
114.0
5.0
4.3
23.7
66.5
10.5
18.5
2
2
10
2
2
10
X
3
1
1010
2
22
2
TYP.
TYP.
TYP.
TYP.
TYP.
TYP.
#10-32 PORT SHOWN
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
40
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series
32
Fluid :
Pressure range :
Pilot pressure :
Lubrication :
Filtration :
Temperature range :
Flow :
Coil :
Voltage range :
Power :
Response times :
(with 4 W coil)
Compressed air, vacuum, inert gases
Internal Pilot : 20 to 120 PSI
External Pilot : Vacuum to 120 PSI
20 to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
# 10-32 : (0.35 C
v
) - 1/4 tube receptacle : (0.40 C
v
)
Class A continuous duty, #22 AWG x 12 base leads
-15% to +10% of nominal voltage
1.0 to 4.0 W
Energize : 5 ms
De-energize : 5 ms
• M5 port • M7 port • 6 mm O.D. tube receptacle
• Inlet/Exhaust Isolator : 28454
Options :
45
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Individual mounting Series
Direct solenoid and solenoid pilot operated valves
SERIES FEATURES
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Inline
Sub-base
non plug-in
Series
37
• Balanced poppet equals consistent high shifting forces.
• Valve shifting forces are consistent and independent of pressure fluctuations.
• High solenoid and return spring forces ensure high speed and precise repeatability.
• Built-in wear compensation - valve stroke is shorter than solenoid stroke.
• Constant high flow maintained throughout the pressure range.
• Exhaust contaminants are isolated from the solenoid.
• Full flow exhaust.
• Universal porting - 6 functions in one valve.
1
3
2
Push pin
Manual operator
Armature
Coil
“D” seal
Poppet
Valve return spring
Pole piece
