185 Consult “Precautions” page 327 before use, installation or service of MAC Valves.. Individual mounting Series Direct solenoid and solenoid pilot operated valves SERIES FEA TURES 36 32 37 38 33 34 52 67 46 44 47 42 40…

100%1 / 280
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
184
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Ø 6.3 TYP (2)
PORTS
OPTIONAL BOTTOM
CONDUIT
1/2" NPSM
111.3
56.3
45.7
17.8
36.2
5.3
38.6
77.4
57.5
13.6
33.5
100.2
105.5
69.5
45.5
21.5
25.8
23.3
15.8
15.3
16.0
107.8
67.3
57.5
45.5
33.5
22.7
147.5
P
1
3
5
3
2
1
4
5
14
Series
ISO 1
Fluid :
Pressure range :
Pilot pressure :
Lubrication :
Filtration :
Temperature range :
Flow :
Coil :
Voltage range :
Protection :
Power :
Response times :
(with 5,4 W coil)
Compressed air, vacuum, inert gases
Internal pilot: 20 to 120 PSI
External pilot : vacuum to 120 PSI
Single/double operator : 20 to 120 PSI, 3 positions : 30 to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
3/8": (1.8 C
v
) – 1/4": (1.6 C
v
)
Class A continuous duty, #22 AWG x 12 base leads
-15% to +10% of nominal voltage
Consult factory
~ Inrush 7.6 VA Holding: 4.8 VA
= 1 to 12.7 W
Energize :10 ms
De-energize : 9 ms
• Sandwich flow controls: FCP1A-AA (screwdriver slot adjustment)
FCP1A-AB (locking knob adjustment)
• Sandwich regulator, see ‚Regulators‘ section
• Pilot valve: DMB-DxxP-xxx • Valve to base pressure seal: 16661
Options :
Spare parts :
5
3
1
2
24
12
4
COND
3
5
1
20.9
32.2
29.7
40.5
127.0
6.9
26.0
32.2
41.0
108.5
20.2
38.5
65.5
90.7
92.0
132.8
115.2
159.3
24.0
12.0
15.0
42.0
15.0
25.4
46.2
70.7
90.3
15.990.5
15.5
28.0
32.0
52.0
13.0
13.7
28.0
40.0
52.0
CONDUIT
1" NPSM
TYP(3)
3/8" COMMONS
EXTERNAL PILOT 1/8"
OPTIONAL COMMON
PORTS
OPTIONAL BOTTOM
(2) MTG HOLES
Ø 6.3 THRU
Individual base Manifold base
185
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Individual mounting Series
Direct solenoid and solenoid pilot operated valves
SERIES FEATURES
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
ISO 2
• Plug-in (5599/2) and non plug-in (5599/1) models.
• 2-position, single or double operator. (Solenoid or Remote Air)
• 3-position, double solenoid, open center, closed center, and pressure center.
• Extended or recessed manual operators.
• Single pressure and dual pressure.
• Individual base or add-a-unit manifold base.
• Plug-in, sandwich, single and dual pressure regulators for both individual and manifold valves.
3214 5
Manual operator
Large spool diameter
Air return
Balanced 4-way poppet
Internal pilot supply
Bonded spool
External pilot
supply
External pilot
supply
Valve only –
No base
non “plug-in”
Conform to
ISO 5599/1
Valve only –
No base
“plug-in”
Conform to
ISO 5599/2
Valve only –
No base
“plug-in”
Conform to
ISO 5599/2
Valve only –
No base
non “plug-in”
Conform to
ISO 5599/1
Manifold mounting
OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
187
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Series
ISO 2
Function Port size Flow (Max) Individual/Manifold mounting Series
5/2, 5/3 3/8” - 1/2” 3.0 C
v
Valve only –
No base
non “plug-in”
Conform to
ISO 5599/1
1. Unique patented Macsolenoid® for fastest
possible response times and virtually burn-
out proof AC solenoid operation.
2. Balanced poppet 4-way pilot valve provides
maximum shifting forces, precise
repeatability and consistent operation.
3. MAC spool and bore combination wipes
away contamination, eliminates sticking and
allows for use on non-lube service.
4. Large spool area for maximum shifting forces
even at minimum operating pressure.
5. Very high flow in a compact package.
6. Plug-in design of valves, bases and
regulators for modular assembly and ease of
maintenance.
7. Internal or external pilot operation.
Manifolds supplied with common external
pilot.
8. Air only return. Optional memory spring is
also available.
9. Optional low wattage DC solenoid down to
1.0 watt.
DM-D
XXX
-
XXX
*
SOLENOID OPERATOR
®
Voltage
JA
110/50, 120/60
JB
220/50, 240/60
JC
24/50, 24/60
FB
24 VDC (1.8W)
DA
24 VDC (5.4W)
DF
24 VDC (12.7W)
Lead wire length
A
18” (Flying leads)
B
24” (Flying leads)
J
Connector
Manual operator
1
Non-locking recessed
2
Locking recessed
Electrical connection
KA
Square connector
KD
Square connector with light
JB
Rectangular connector
JD
Rectangular connector with light
BA
Flying leads
XX X X XX
* Other options available, see page 309.
Note: ISO series, valve and base are ordered separately, see page 235 for base code.
5/2
Single operator
MV-B2A-AAAA-DM-D
XXX
-
XXX
MV-B2A-AAAB-DM-D
XXX
-
XXX
5/2
Double operator
MV-B2A-ABAA-DM-D
XXX
-
XXX
MV-B2A-ABAB-DM-D
XXX
-
XXX
5/3
Closed center
MV-B2A-AEAA-DM-D
XXX
-
XXX
MV-B2A-AEAB-DM-D
XXX
-
XXX
5/3
Open center
MV-B2A-AFAA-DM-D
XXX
-
XXX
MV-B2A-AFAB-DM-D
XXX
-
XXX
414 2 12
513
414 2 12
513
414 2 12
5
1
3
414 2 12
5
1
3
Pilot air
Internal
External "12" end
SINGLE PRESSURE MODELS
5/2
Single operator
MV-B2A-ACAD-DM-D
XXX
-
XXX
MV-B2A-ACAE-DM-D
XXX
-
XXX
MV-B2A-ACAB-DM-D
XXX
-
XXX
5/2
Double operator
MV-B2A-ADAD-DM-D
XXX
-
XXX
MV-B2A-ADAE-DM-D
XXX
-
XXX
MV-B2A-ADAB-DM-D
XXX
-
XXX
5/3
Pressure center
MV-B2A-AGAD-DM-D
XXX
-
XXX
MV-B2A-AGAE-DM-D
XXX
-
XXX
MV-B2A-AGAB-DM-D
XXX
-
XXX
Pilot air
Internal pilot From port #3
Internal pilot From port #5
External pilot From "12" end
DUAL PRESSURE MODELS
14 12
5
1
3
414 2 12
513
414 2 12
513
OPTIONS
Valve function :
MV-B2A-A
X
XX-XX-D
XXX
-
XXX
J for single operator universal spool (ext. pilot only)
K for double operator universal spool (ext. pilot only)
Pilot style :
MV-B2A-AXXX-
DM
-D
XXX
-
XXX
DM Pilot exhaust muffled
DP Pilot exhaust piped (#10-32)
Spool return :
MV-B2A-AX
A
X-XX-D
XXX
-
XXX
A Standard return
B Memory spring return
