OPERATIONAL BENEFITS Direct solenoid and solenoid pilot operated valves HOW TO ORDER 69 Consult “Precautions” page 327 before use, installation or service of MAC Valves.. 36 32 37 38 33 34 52 67 46 44 47 42 400 48 92 93 …

100%1 / 280
67
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Individual mounting Series
Direct solenoid and solenoid pilot operated valves
SERIES FEATURES
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
Inline
Series
67
• Patented MACSOLENOID
®
for fastest possible response times
and virtually burn-out proof AC solenoid operation.
• Optional low watt DC solenoids.
• Normally closed or normally open valve function.
• Optional universal spool.
• Internal or external pilot.
• Optional memory spring.
• Checked accumulator.
• Optional pilot exhaust to main valve exhaust.
• May be plugged for 2-way operation.
Inlet (1) Exhaust (3)
Cylinder (2)
Solenoid
Manual operator
4-way pilot with
balanced poppet
Air return
Bonded spool
OPERATIONAL BENEFITS
Direct solenoid and solenoid pilot operated valves
HOW TO ORDER
69
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
36
32
37
38
33
34
52
67
46
44
47
42
400
48
92
93
ISO 1
ISO 2
ISO 3
69
48P
ISO 01
ISO 02
NO Valve
67A-C
X
-AAA-DM-D
XXX
-
XXX
67A-C
X
-BAA-DM-D
XXX
-
XXX
67A-C
X
-AAB-DM-D
XXX
-
XXX
67A-C
X
-BAB-DM-D
XXX
-
XXX
NC Valve
67A-A
X
-AAA-DM-D
XXX
-
XXX
67A-A
X
-BAA-DM-D
XXX
-
XXX
67A-A
X
-AAB-DM-D
XXX
-
XXX
67A-A
X
-BAB-DM-D
XXX
-
XXX
NO Valve
67A-D
X
-AAA-DM-D
XXX
-
XXX
67A-D
X
-BAA-DM-D
XXX
-
XXX
67A-D
X
-AAB-DM-D
XXX
-
XXX
67A-D
X
-BAB-DM-D
XXX
-
XXX
NC Valve
67A-B
X
-AAA-DM-D
XXX
-
XXX
67A-B
X
-BAA-DM-D
XXX
-
XXX
67A-B
X
-AAB-DM-D
XXX
-
XXX
67A-B
X
-BAB-DM-D
XXX
-
XXX
2
1210
13
2
1210
13
2
1210
13
2
12
13
10
Port size
3/4” NPTF
1” NPTF
3/4” NPTF
1” NPTF
Pilot air
Internal
External
Series
67
Function Port size Flow (Max) Individual mounting Series
3/2 NO-NC, 2/2 NO-NC 3/4” - 1” 20.0 C
v
Inline
1. The 4-way pilot develops maximum shifting
force both ways.
2. Memory spring available.
3. Balanced spool, immune to variations of
pressure, also provides high flow.
4. Short stroke with high flow.
5. Bonded spool with minimum friction, shifting
in a glass-like finished bore.
6. Pilot with balanced poppet, high flow, short
and consistent response times.
7. Wiping effect eliminates sticking.
DM-D
XXX
-
XXX
*
SOLENOID OPERATOR
®
Voltage
JA
110/50, 120/60 (2.9W)
JB
220/50, 240/60 (2.9W)
JC
24/60 (2.9W)
FB
24 VDC (1.8W)
DA
24 VDC (5.4W)
DF
24 VDC (12.7W)
Wire length
A
18”
B
24”
J
Connector
Manual operator
1
Non-locking recessed
2
Locking recessed
Electrical connection
KA
Square connector
KD
Square connector with light
JB
Rectangular connector
JD
Rectangular connector with
light
BA
Flying leads
XX X X XX
* Other options available, see page 309.
OPTIONS
67A-
X
X-AAA-DM-D
XXX
-
XXX
Single Operator Double Operator
G Single operator universal spool
H Double operator universal spool
Spool type :
67A-XX-A
X
A-DM-D
XXX
-
XXX
A Standard pilot exhaust
B Pilot exhaust to main exhaust*
C Pilot exhaust out adapter*
* Must use DU pilot. Replace DM with DU
Port configuration :
67A-X
X
-AAA-DM-D
XXX
-
XXX
1 Standard return
2 Standard return with memory spring
(for use with single operator only)
Spool return :
67A-XX-AAA-D
M
-D
XXX
-
XXX
M Pilot exhaust muffled
P Pilot exhaust piped (#10-32)
U Pilot exhaust to main exhaust
Pilot style :
67A-XX-
XAA
-DM-D
XXX
-
XXX
G O-Ring mount
Mounting style :
1010
33 11
1212
SINGLE SOLENOID
APPROX. FOR
DOUBLE SOLENOID
APPROX. FOR
VAC TO 120 PSI
WATTS
ELECTRICAL
MODEL
AUCKLAND,N.Z.
LIEGE,BELGIUM
WIXOM,MI.USA
MODIF.
197.9
226.2
59.0
93.0
10
12
EP
2
51.7
24.0
PILOT
OPTIONAL EXTERNAL
92.018.7
10.5
71.9
24.0
84.8
117.9
138.4
17.6
18
18
10 0
%
10 0
%
10 0
%
10 0
%
MONTHS
WARRANTY
OF
PRODUCTION
TESTED
DIMENSIONS
TECHNICAL DATA
Dimensions shown are metric (mm)
70
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
Series
67
Fluid :
Pressure range :
Lubrication :
Filtration :
Temperature range :
Flow :
Coil :
Voltage range :
Protection :
Power :
Response times :
(with 5.4 W coil)
Compressed air, vacuum, inert gases
Internal Pilot : 20 to 120 PSI
External Pilot : Vacuum to 120 PSI
Not required, if used select a medium aniline point lubricant (between 180°F and 210°F)
40 µ
0°F to 120°F (-18°C to +50°C)
3/4" : (14.5 C
v
) – 1" : (20.0 C
v
)
Class A continuous duty, #22 AWG x 18 lead wires
-15% to +10% of nominal voltage
Consult factory
~ Inrush : 7.6 VA Holding : 4.8 VA
= 12.7 to 1.0 W
Energize : 29 ms
De-energize : 21 ms
• BSPP threadsOptions :
