315 Consult “Precautions” page 327 before use, installation or service of MAC Valves.. OPTIONS Codification table for voltages / Manual operators / Electrical connections - Solenoid valves 37 & 47 Series OPTIONS AVAI…
314
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
1. VOLTAGE
G-XX X-X XX
VOLTAGE
DC
24 VDC (1.8 W)
DD
24 VDC (2.5 W)
DE
24 VDC (3.0 W)
DF
24 VDC (4.0 W)
DJ
12 VDC (1.8 W)
DK
12 VDC (2.5 W)
DM
12 VDC (3.0 W)
DN
12 VDC (4.0 W)
2. WIRE LENGTH
G-XX X-X XX
WIRE LENGTH
0
No lead wire (use only with "KJ" & "KM" elecrical
connectors)
A
18"
B
24"
C
36"
D
48"
E
72"
F
96"
G
120"
H
144"
3. MANUAL OPERATOR
G-XX X-X XX
MANUAL OPERATOR
1
Non-locking recessed
2
Locking recessed
3
Non-locking extended
4
Locking extended
4. ELECTRICAL CONNECTION
G-XX X-X XX
ELECTRICAL CONNECTION
BA
Flying leads
BB
BA with ground wire
BC
BA with light parallel to leads
BD
BA with light parallel to leads & ground wire
BE
BA with suppression diode
BF
BA with suppression diode & ground wire
BG
BA with suppression diode plus light parallel to leads
BH
BA with suppression diode plus light parallel to leads &
ground wire
*BN
BA with suppression diode plus blocking diode
*BP
BA with suppression diode plus blocking diode & ground
wire
*BR
BA with suppression diode plus blocking diode & light
parallel to leads
*BS
BA with suppression diode plus blocking diode & light
parallel to leads & ground wire
BT
BA with light on top
BU
BA with light on top & ground wire
BV
BA with suppression diode plus light on top
BW
BA with suppression diode plus light on top & ground wire
*BX
BA with suppression diode plus blocking diode & light on top
*BY
BA with suppression diode plus blocking diode & light on
top & ground wire
G-XX X-X XX
SOLENOID PLUG-IN CONNECTOR WITH LEADS
GA
MAC JAC Solenoid plug-in
GB
MAC JAC Solenoid plug-in w/Diode
GC
MAC JAC Solenoid plug-in w/MOV
GD
MAC JAC Solenoid plug-in w/LED
GE
MAC JAC Solenoid plug-in w/Diode & LED
GF
MAC JAC Solenoid plug-in w/MOV & LED
GG
MAC JAC Solenoid plug-in w/Rectifier
GH
MAC JAC Solenoid plug-in w/Rectifier & LED
KA
Plug-in wire assembly
KB
KA with ground wire
KE
KA with suppression diode
KF
KA with suppression diode & ground wire
KJ
Plug-in housing without wire assembly
('KA' without wire assembly)
KM
Plug-in housing without wire assembly
('KB' without wire assembly)
*KN
KA with suppression diode plus blocking diode
*KP
KA with suppression diode plus blocking diode & ground wire
KT
KA with light on top
KU
KA with light on top & ground wire
KV
KA with suppression diode plus light on top
KW
KA with suppression diode plus light & ground wire
*KX
KA with suppression diode plus blocking diode & light on top
*KY
KA with suppression diode plus blocking diode & light on
top & ground wire
Note: Blocking diode is located in the lead wire
315
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
Codification table for voltages / Manual operators / Electrical connections
- Solenoid valves 37 & 47 Series
OPTIONS AVAILABLE FOR
H XX X-X XX
1 2 3 4
VALVE CODE
®
316
Consult “Precautions” page 327 before use, installation or service of MAC Valves..
OPTIONS
1. VOLTAGE
H-XX X-X XX
VOLTAGE
AA
120/50, 120/60 (6.7 W)
(use connector with rectifier)
AB
220/50, 220/60 (5.6 W)
(use connector with rectifier)
AC
240/50, 240/60 (5.8 W)
(use connector with rectifier)
AD
24/50, 24/60 (7.8 W)
(use connector with rectifier)
DA
24 VDC (5.2 W)
DB
24 VDC (2.4 W)
DC
24 VDC (1.8 W)
DD
24 VDC (1.0 W)
DF
12 VDC (5.2 W)
DG
12 VDC (2.4 W)
DH
12 VDC (1.8 W)
DJ
12 VDC (1.0 W)
DL
120 VDC (6.3 W)
2. WIRE LENGTH
H-XX X-X XX
WIRE LENGTH
0
No lead wire (use with "MJ, MM & K Type connectors)
A
18"
B
24"
C
36"
D
48"
E
72"
F
96"
G
120"
H
144"
3. MANUAL OPERATOR
H-XX X-X XX
MANUAL OPERATOR
0
No operator
1
Non-locking recessed
2
Locking recessed
3
Non-locking extended
4
Locking extended
4. ELECTRICAL CONNECTION
H-XX X-X XX
ELECTRICAL CONNECTION
BA
Flying leads
BB
BA with ground wire
BC
BA with light
BD
BA with light & ground wire
BE
BA with suppression diode
BF
BA with suppression diode & ground wire
BG
BA with suppression diode plus light
BH
BA with suppression diode plus light & ground wire
*BN
BA with suppression diode plus blocking diode
*BP
BA with suppression diode plus blocking diode & ground wire
*BR
BA with suppression diode plus blocking diode & light
*BS
BBA with suppression diode plus blocking diode & light &
ground wire
BK
BA with full wave rectifier
H-XX X-X XX
BL
BA with full wave rectifier & ground wire
BT
BA with full wave rectifier plus light
BU
BA with full wave rectifier plus light & ground wire
H-XX X-X XX
PLUG-IN CONNECTOR
FA
Base plug-in
FB
FA with ground wire
FC
FA with light
FD
FA with light & ground wire
FE
FA with suppression diode
FF
FA with suppression diode & ground wire
FG
FA with suppression diode & light
FH
FA with suppression diode plus light & ground wire
FK
FA with full wave rectifier
FL
FA with full wave rectifier & ground wire
*FN
FA with suppression diode plus blocking diode
*FP
FA with suppression diode plus blocking diode & ground wire
*FR
FA with suppression diode plus blocking diode plus light
*FS
FA with suppression diode plus blocking diode & light &
ground wire
FT
FA with full wave rectifier plus light
FU
FA with full wave rectifier plus light & ground wire
MA
Solenoid plug-in wire assembly
MB
MA with ground wire
MC
MA with light
MD
MA with light & ground wire
ME
MA with suppression diode
MF
MA with suppression diode & ground wire
MG
MA with suppression diode plus light
MH
MA with suppression diode plus light & ground wire
MK
MA with full wave rectifier
ML
MA with full wave rectifier & ground wire
*MN
MA with suppression diode plus blocking diode
*MP
MA with suppression diode plus blocking diode & ground wire
*MR
MA with suppression diode plus blocking diode & light
*MS
MA with suppression diode plus blocking diode & light &
ground wire
MT
MA with full wave rectifier plus light
MU
MA with full wave rectifier plus light & ground wire
MJ
Plug-in housing without wire assembly ('MA' option
without wire assembly)
MM
Plug-in housing without wire assembly ('MB' option
without wire assembly)
KA
Mini square connector
KB
KA with suppression diode
KC
KA with M.O.V.
KD
KA with light
KE
KA with light & suppression diode
KF
KA with light & M.O.V.
KJ
Mini square connector – male only
KK
KJ with suppression diode
KL
KJ with M.O.V.
KM
KA with full wave rectifier
KN
KA with full wave rectifier & M.O.V.
KP
KA with full wave rectifier & light
KR
KA with full wave rectifier plus light & M.O.V.
KS
KJ with full wave rectifier
* Blocking diode is located in the lead wire
